- Page 1 OPERATION AND PARTS MANUAL MODEL HBC19A MODEL HBC25A REBAR CUTTER (PORTABLE ELECTRIC) Revision #4 (03/30/09) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
-
Page 2: Table Of Contents
HBC19A Rebar Cutter Assembly ..... 18-21 HBC25A Rebar Cutter Assembly ..... 22-25 Tools ..............26-27 Wiring Diagram ............. 28 Terms and Conditions Of Sale — Parts ....29 PAGE 2 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) -
Page 3: Suggested Spare Parts
6415730 .... CARBON BRUSH (FOR HBC19A) 6402510 .... CARBON BRUSH (FOR HBC25A) H9T4495400 ..BLADE, SET OF 2 (FOR HBC19A) H9T4495500 ..BLADE, SET OF 2 (FOR HBC25A) HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 15... -
Page 4: Nameplate And Decals
5. Always adjust and tighten spacing bolt before cutting. 6. Keep fingers away from cutting edges during operation. 7. To prevent electrical shock, do not use cutter when damp. PAGE 16 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) - Page 5 QTY. REMARKS 8006660 SAFETY WARNING DECAL 8006670 OPERATING INSTRUCTIONS DECAL 8006680 MQ LOGO NAMEPLATE ............1 ..CONTACT MQ PARTS DEPT. 8001180 BOX WARNING DECAL HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 17...
-
Page 6: Hbc19A Rebar Cutter Assembly
HBC19A — REBAR CUTTER ASSEMBLY 54 55 NOTES ITEM 50, SPRING HOLDER REPLACED BY O-RING S/N 300281 AND ABOVE PAGE 18 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) - Page 7 SEAL WASHER (DRAINING/REFILLING) 7411070 STOP RING H28 (RTW28) H9T4344700 NEEDLE HOLDER H9B12410A0 NEEDLE BEARING H9B6080000 BEARING 608 4601570 LINER B H9T4344800 MAGNET 6505300 O-RING S-4 HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 19...
- Page 8 HBC19A — REBAR CUTTER ASSEMBLY 17 18 54 55 NOTES ITEM 50, SPRING HOLDER REPLACED BY O-RING S/N 300281 AND ABOVE PAGE 20 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09)
- Page 9 BOLT HB8 X 25 (BAR HOLDER) H9HW080100 WASHER HW8 H9T4390000 BUSHING H9T43899N1 OIL LEVELER SACK 3505510 PROTECTIVE COVER 6013530 MOTOR ASSEMBLY ........... 1 ..INCLUDES ITEMS W/ # HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 21...
-
Page 10: Hbc25A Rebar Cutter Assembly
HBC25A — REBAR CUTTER ASSEMBLY 57 58 NOTES ITEM 52, SPRING HOLDER REPLACED BY O-RING S/N 400361 AND ABOVE PAGE 22 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) - Page 11 H6HW060100 WASHER HW6 H5RTW30000 STOP RING H30 (RTW30) H5T4438500 NEEDLE HOLDER H9B12410A0 NEEDLE BEARING H9B6080000 BEARING 608 4601590 LINER B H9T4344800 MAGNET 6505300 O-RING S-4 HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 23...
- Page 12 HBC25A — REBAR CUTTER ASSEMBLY 57 58 NOTES ITEM 52, SPRING HOLDER REPLACED BY O-RING S/N 400361 AND ABOVE PAGE 24 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09)
- Page 13 SPRING WASHER 6 6415020 WASHER 6 4500540 SHIELD ............... 1 ..S/N 400301 AND ABOVE 6014150 MOTOR ASSEMBLY ..........1 ..INCLUDES ITEMS W/ # HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 25...
-
Page 14: Tools
24 MM 3 MM 4 MM 17 MM 19 MM 5 MM 6 MM HYDRAULIC ALLEN WRENCHES 4 MM 5 MM 6 MM 8 MM PAGE 26 — HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) - Page 15 CYLINDER RING (TOOL), HBC19A ....1 ..NOT PROVIDED W/ UNIT 9004040 CYLINDER RING (TOOL), HBC25A ....1 ..NOT PROVIDED W/ UNIT 8101050 WOODEN BOX, HBC25A 8101060 WOODEN BOX, HBC19A HBC19A/HBC25A REBAR CUTTER • OPERATION AND PARTS MANUAL — REV. #4 (03/30/09) — PAGE 27...
