BP-VG4090FE-SOLO-V2
Bitspower Nebula VGA Water Block for
GeForce RTX 4090 Founders Edition
(incl. Improved backplate )
Accessories
1
BP-VG4090FE-SOLO-V2
2
M2.5 x 8 Screw
#
Two screws fastened in advance.
#
3
M3 x 6 Screw
4
I/O shield
1 SET
7 PCS
3 PCS
1 PC
EN ver.2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bitspower BP-VG4090FE-SOLO-V2
Summary of Contents for Bitspower BP-VG4090FE-SOLO-V2
- Page 1 EN ver.2 BP-VG4090FE-SOLO-V2 Bitspower Nebula VGA Water Block for GeForce RTX 4090 Founders Edition (incl. Improved backplate ) Accessories BP-VG4090FE-SOLO-V2 1 SET M2.5 x 8 Screw 7 PCS Two screws fastened in advance. M3 x 6 Screw 3 PCS I/O shield...
- Page 2 Assembly steps step 1 Backplate step 2 (Not included) Before installing the graphics c a r d , p l e a s e m a k e s u r e t h a t the GPU has been coated with thermal paste.
- Page 3 Assembly steps step 4 step 5 Original bracket(Not included) Digital RGB PIN on motherboard or other equipment. BPTA-DRGBMFC motherboard DRGB Multi Function Controller (Not included) [ 3 ]...
- Page 4 Use an appropriate amount of thermal paste.(Not Include) Make sure the correct thermal pads are in the appropriate locations. 1.0 mm Thermal pad 1.5 mm Thermal pad Specification Quantity Name Thermal pad 1 8×12×1mm 13×16×1mm Thermal pad 2 Thermal pad 3 15×37×1mm Thermal pad 4 14×50×1mm...
- Page 5 Use an appropriate amount of thermal paste.(Not Include) Make sure the correct thermal pads are in the appropriate locations. 1.0 mm Thermal pad 1.5 mm Thermal pad Specification Quantity Name Thermal pad 1 8×12×1mm 13×16×1mm Thermal pad 2 Thermal pad 3 15×37×1mm Thermal pad 4 14×50×1mm...
- Page 6 As such, if you feel uncomfortable with the steps involved in installing this product, please reach out to our customer support for assistance. We recommend the use of a leak tester, such as our Bitspower Digital Leak Detector, after completing the assembly of your liquid cooling loop to make sure there are no leaks prior to filling up your loop with coolant.
