- Page 1 HD Intelligent Enforcement Camera Quick Start Guide V1.0.0...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the structure, installation, system networking, and initial configurations of the HD Intelligent Enforcement Camera (hereinafter referred to as the "Camera"). Safety Instructions The following categorized signal words with defined meaning might appear in the manual. - Page 3 Quick Start Guide ● All trademarks, registered trademarks and the company names in the manual are the properties of their respective owners. ● Please visit our website, contact the supplier or customer service if there is any problem occurring when using the device. ●...
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Transportation Requirements Transport the device under allowed humidity and temperature conditions. - Page 5 Quick Start Guide ● An emergency disconnect device must be installed during installation and wiring at a readily accessible location for emergency power cut-off. ● Disconnect the device when installing and connecting the lens. Operation Requirements ● Make sure that the power supply is correct before use. ●...
-
Page 6: Table Of Contents
Quick Start Guide Contents Foreword..........................1 Important Safeguards and Warnings................3 1 Structure......................... 6 1.1 Terminal................................6 1.2 Rear Panel..............................7 2 Basic Configuration......................9 2.1 System Network............................9 2.2 Initialization..............................9 3 Installation........................11 3.1 Accessories Package..........................11 3.2 Installing Sun Shade..........................11 3.3 Installing SD Card............................12 3.4 Vertical Mounting........................... -
Page 7: Structure
Quick Start Guide 1 Structure 1.1 Terminal A typical terminal is shown in the figure below. Different devices might have different types of terminals, and the actual device shall prevail. Figure 1-1 Terminal Table 1-1 Description of terminal Name Description Flashing light 1 triggers output F1+ Flashing light 1 triggers output F1- Flashing light 2 triggers output F2+... -
Page 8: Rear Panel
Quick Start Guide 1.2 Rear Panel Figure 1-2 Rear panel Table 1-2 Rear panel interfaces Interface Function DC 12 IN Power input interface 12 VDC input. Synchronous input interface of The camera synchronizes with SI+, SI- external frequency source external signal source. Restore to factory settings. - Page 9 Quick Start Guide Interface Function 2 ports, connecting to signal detector, vehicle detector, radar, A1, B1 flashing light, strobe, and other illuminators. RS–485 ports 2 ports, connecting to flashing A2, B2 light, strobe, and other illuminators. Ground terminal. 4 IO snapshot ports or 4 alarm IN1, IN2, IN3, IN4 IO input input ports.
-
Page 10: Basic Configuration
Quick Start Guide 2 Basic Configuration 2.1 System Network After mounting the Camera, power on the Camera, connect it to the network and make initial settings, then you can successfully log in to the webpage of the Camera. For more configurations, see the web operation manual. Procedure Step 1 Connect the Camera to network. - Page 11 Quick Start Guide Step 4 On the Online Upgrade page, you can cancel selecting Auto-check for updates (selected by default). Step 5 Click Confirm. Step 6 On the login page, enter the username (admin) and the password that you set. Step 7 On the Config Guide page, set the business type and road mode.
-
Page 12: Installation
Quick Start Guide 3 Installation 3.1 Accessories Package Figure 3-1 Accessories package 3.2 Installing Sun Shade Figure 3-2 Installing sun shade... -
Page 13: Installing Sd Card
Quick Start Guide 3.3 Installing SD Card Figure 3-3 Installing SD card... -
Page 14: Vertical Mounting
Quick Start Guide 3.4 Vertical Mounting Figure 3-4 Vertical mounting... -
Page 15: Horizontal Mounting
Quick Start Guide 3.5 Horizontal Mounting Figure 3-5 Horizontal mounting... -
Page 16: Adjusting Camera Angle
Quick Start Guide 3.6 Adjusting Camera Angle Figure 3-6 Adjusting camera angle (horizontal and vertical mounting)
