Help Guide
Flash
HVL-F60RM/HVL-F60RM2/HVL-F46RM/HVL-F46RMA
Use this Help Guide when you have issues or questions on how to use your flash unit.
HVL-F60RM2/HVL-F46RM/HVL-F46RMA: Regarding the compatibility with cameras equipped with global
shutter image sensor
To use the global shutter sync photography, you need to update the software in the HVL-F60RM2/HVL-F46RM/HVL-F46RMA to version 2.00
or later. Update to the latest version to use it.
For details about the global shutter sync photography, view here.
Compatible cameras
HVL-F60RM
For camera models compatible with the HVL-F60RM flash unit, view here. (Another window will open.)
HVL-F60RM2
For camera models compatible with the HVL-F60RM2 flash unit, view here. (Another window will open.)
HVL-F46RM
For camera models compatible with the HVL-F46RM flash unit, view here. (Another window will open.)
HVL-F46RMA
For camera models compatible with the HVL-F46RMA flash unit, view here. (Another window will open.)
Support information
Radio wireless flash photography
For an overview with preparation and usage examples for radio wireless flash photography, view here. (Another window
will open.)
About this Help Guide
Locating parts and controls/on-screen indicators
Locating parts and controls (HVL-F60RM/HVL-F60RM2)
Locating parts and controls (HVL-F46RM/HVL-F46RMA)
Basic operations
Using the control wheel
Using the Quick Navi screen
Using the MENU screen
Direct setting (HVL-F60RM/HVL-F60RM2)
