AKG HSC 200 SR Specifications

Description
The HSC 200 SR is a combination of semi-open stereo
headphones and an adjustable electret microphone. The
microphone element rests in a shock mount that suppresses both
cable noise and acoustic headphone leakage.
The microphone operates on phantom powering over the range
from 9 to 52 volts dc. Microphone sensitivity is 7 mV/Pa at 1 kHz.
The microphone connector is a 3-pin XLR type and the headphone
connector is a 0.25 in. (6.3 mm) ring-tip-sleeve stereo jack.

Specifications

Microphone
Transducer Principle: Condenser prepolarized
Frequency Range: 20–20,000 Hz
Polar Pattern: Cardioid
7 mV/Pa ^ = -43 dBV
Sensitivity at 1,000 Hz:
Equivalent Noise Level: < 22 dB-A
S/N Ratio (A-weighted): > 69 dB
Electr. Impedance: < 200 ohms
Load Impedance: > 2,000 ohms
Power Requirement: 9 to 52 volts phantom power
Connector: 3-pin XLR type
Headphones
Transducer Principle: Dynamic
Type: Semi-open, supra aural
Frequency Range: 20–20,000 Hz
Rated Impedance: 100 ohms/system
Finish: Non-reflective black
Connector: Gold plated 0.25 in. (6.3 mm)
stereo jack
Net/Shipping Weight: 8.8 oz./1 lb. (250 g/450 g)
Included Accessories: Foam windscreen,
Phantom power adapter
Optional Accessory: B 18 E Battery Power Supply
HSC 200 SR
Features
• Semi-open headphones
• Shock mounted microphone
• Flexible gooseneck
• Phantom power adapter
• Bass roll-off
• Rugged and lightweight design
Broadcast Headset
