36” gas rangetop

Advertisement

Quick Links

INSTALLATION INSTRUCTIONS
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or
liquids near this or any other appliance.

Table of Contents

Product Dimensions ........................................ 4
Cabinet clearances.......................................... 4
Island installation............................................. 6
ance................................................................. 7
Electrical connection ....................................... 7
Gas safety ....................................................... 8
Gas connection ............................................... 9
WARNING
If the instructions contained in this manual are not followed precisely, a fire
or explosion may result causing property damage, personal injury or loss of life.
FOR YOUR SAFETY:
• Do not store or use gasoline or other flammable vapors or liquids near this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch electrical switches; do not use any phone in the building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER,
SERVICE COMPANY OR GAS SUPPLIER.
Note: For appliances installed in the State of Massachusetts, go to page 9.
Note: When operating at elevations higher than 2000 ft. above sea level, the appliance rating
should be reduced by 4 percent for each additional 1000 ft.
All rights reserved. Printed in Italy
36" GAS RANGETOP
INSTALLER.
Important Notes to the Installer
1. Read all instructions contained in these installa-
tion instructions before installing the range.
2. Remove all packing material from the oven and
the drawer compartments before connecting the
electrical and gas supplies to the range.
3. Observe all governing codes and ordinances. Be
sure to leave these instructions with the con-
sumer.
Important Note to the Customer
Keep these instructions with your owner's guide for
future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECCG3672ASA and is the answer not in the manual?

Questions and answers

Summary of Contents for Electrolux ECCG3672ASA

  • Page 1: Table Of Contents

    INSTALLATION INSTRUCTIONS 36” GAS RANGETOP INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER. IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. WARNING FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids near this or any other appliance.
  • Page 2: Important Safety Instructions

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS This manual contains important safety symbols and insulating pad or sheet of ¼" (10,16cm) thick ply- instructions. Please pay attention to these symbols wood between the range and carpeting. and follow all instructions given. •...
  • Page 3: Safety Codes And Standards

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS • In the event of an electrical power outage, the sur- Tip Over Hazard face burners can be lit manually. To light a surface WARNING burner, hold a lit match to the burner head and slowly turn the Surface Control knob to LITE.
  • Page 4: Product Dimensions

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS Product Dimensions Cabinet clearances 912.4 mm 35 15/16" max: 688 mm max: 27 1/8" min: 681.5 mm min: 26 13/16” 190.5 mm 7 1/2" 914 mm 36” 46.5 mm 1 13/16" max: 619 mm max: 24 3/8” min: 612.5 mm min: 24 1/8”...
  • Page 5 36” GAS RANGETOP INSTALLATION INSTRUCTIONS Countertop cutout for gas and electric 2. Divide the measurement in half and draw the midline on the surface of the cabinet. connections 3. Measure 3” (76mm) from the front edge of the cabinet and draw a line perpendicular to the mid- line.
  • Page 6: Location Of The Gas And Electric Outlets

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS Location of the gas and electric Island installation outlets If the appliance is installed as an island: 1. Unscrew the screws indicated. 2. Remove the spacers (A) and the screws (B). min: 24” min: 610 mm Keep a minimum clearance of 5 7/8"...
  • Page 7: Unpacking, Moving And Positioning The Appliance

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS Unpacking, moving and Electrical connection positioning the appliance Electrical shock hazard WARNING CAUTION This unit is designed as a cooking • This appliance is equipped appliance. For safety reasons, never use it for with a four-prong grounding warming the room or as a space heater.
  • Page 8: Gas Safety

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS See the rating plate for technical specifications. The rating plate is visibly located at the bottom of the Electrical shock hazard WARNING appliance, towards the rear. • For personal safety, this appliance must be properly grounded.
  • Page 9: Propane Gas Installation

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS The maximum supply pressure of 14.0 inches water Install the pressure regulator (supplied with the unit) on the gas inlet. Install the gasket (supplied with the column (34.9 Millibars) must not exceed. unit) between the inlet and the regulator. Position WARNING State of California Proposi- the regulator so that the cap D is easily accessible.
  • Page 10 36” GAS RANGETOP INSTALLATION INSTRUCTIONS The technical data tables for the nozzles and burn- Connect the gas supply line to the unit pressure reg- ulator using a 1/2” flex gas line connector between ers are shown below the manual shut-off valve and the pressure regula- tor.
  • Page 11: Testing For Gas Leaks

    36” GAS RANGETOP INSTALLATION INSTRUCTIONS Testing for gas leaks Adjusting the minimum gas setting Since all cooktop burners are of the dual-flame type, WARNING NEVER use a flame to check for the minimum gas setting must be adjusted for both gas leaks.
  • Page 12 36” GAS RANGETOP INSTALLATION INSTRUCTIONS When checking if the regulator is working properly, 3. Invert the plastic regulator stem to achieve the the inlet pressure must be at least 1" greater than configuration “B” for Propane Gas and screw it in the operating (manifold) pressure above.
  • Page 13 36” GAS RANGETOP INSTALLATION INSTRUCTIONS 4. Remove the internal (8) and external (9) nozzles Refitting the burners and replace them with the LPG nozzles (see In order to be installed correctly, the shape of the "LPG nozzles table (Pressure in W.C.P.: 10”)"). burner skirt openings must match the shape of the openings in the burner base.
  • Page 15 914780092-A-112021...
