BPX-600 Post Driver
User Manual
[Revision 2.0 August 2017]
Checking and Changing Engine
Oil.
Failure to add engine oil will void the
Advertisement
Table of Contents
Related Manuals for Baumr-AG BPX-600
Summary of Contents for Baumr-AG BPX-600
- Page 1 BPX-600 Post Driver User Manual [Revision 2.0 August 2017] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Safety
BPX-600 Post Driver Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or... - Page 3 BPX-600 Post Driver switch is dangerous and must be • Ensure all power sources conform to repaired. equipment voltage requirements and are disconnected before connecting equipment. General Fuel Safety General Service Information Petrol/fuel/gasoline is • Have the equipment serviced or extremely flammable –...
-
Page 4: Table Of Contents
BPX-600 Post Driver Table of Contents Safety ..............................2 Parts Identification ..........................5 Engine and Machine Components ......................6 Before Use Checklist ......................... 7 Engine Oil ..............................7 Air Filter ..............................7 Fuel ................................7 Priming the Fuel System........................7 Attaching the Piling Socket ........................ -
Page 5: Parts Identification
BPX-600 Post Driver Parts Identification Name Name Tools / Accessories: Engine / Hammer / Handle Assembly 5 / 6 / 8mm Allen Key 68mm Piling Socket Spark Plug Tool / Screwdriver 55mm Piling Socket Spark Plug (spare, may be included) Grease (for hammer pin) 65mm (2 ½") Pipe Adaptor... -
Page 6: Engine And Machine Components
BPX-600 Post Driver Engine and Machine Components Name Name Engine ON / OFF Switch Oil Filler Cap Throttle Control Exhaust Choke Lever Air Filter Assembly (air filter inside) Starter Cord Spark Plug Cover (spark plug inside) Fuel Tank Handle Fuel Primer... -
Page 7: Before Use Checklist
BPX-600 Post Driver Before Use Checklist Ensure that you carry out all procedures below before starting the engine or operating the equipment. All procedures described are generic in nature and slight variations between different models may exist. Failure to follow the checklist and carry out the procedures correctly may result in making the product warranty void. -
Page 8: Attaching The Piling Socket
BPX-600 Post Driver Attaching the Piling Socket Always check that the hammer case bolts (B) are tight before attaching the piling socket (use 6mm Allen key). • Do not use the machine without a piling socket attached. Screw the required piling socket (1) to the thread on the end of the hammer case (C) (rotate right ). -
Page 9: Engine Starting And Post Driver Operation
BPX-600 Post Driver Engine Starting and Post Driver Operation Starting the Engine 1. PRIME – If necessary, “prime” the fuel system. 2. CHOKE – If the engine is cold, place the choke (E) in the “COLD” position. If the engine is warm or the ambient temperature is high, place the choke in the “RUN”... -
Page 10: Post Driver Operation
BPX-600 Post Driver Post Driver Operation Before use, ensure that there are no electrical cables, gas or water pipes etc or other buried or unseen hazards in the work area. Contact the applicable utility providers for assistance. • The machine should be operated on ground that is suitable for driving posts. -
Page 11: Maintenance
BPX-600 Post Driver Maintenance Running combustion engines in confined areas CAN KILL IN MINUTES. Engine exhaust fumes contain carbon-monoxide – a deadly gas that you cannot smell or see. NEVER run a combustion engine in confined areas EVEN IF windows and doors are open. -
Page 12: Checking And Changing Engine Oil
BPX-600 Post Driver Checking and Changing Engine Oil The product is NOT supplied with engine oil, although traces of oil from the manufacturing process may be present. It is essential to add adequate engine oil of the correct type to the engine before use. -
Page 13: Checking, Cleaning Or Replacing The Air Filter
BPX-600 Post Driver Checking, Cleaning or Replacing the Air Filter Operating the machine without a functional air filter may cause severe engine damage and will void any warranty. • A dirty or oil saturated air filter will restrict air flow, which can reduce performance and be mistaken as fuel system problems. -
Page 14: Checking, Cleaning Or Replacing The Fuel Strainer
BPX-600 Post Driver Checking, Cleaning or Replacing the Fuel Strainer A dirty or blocked fuel strainer will restrict fuel flow, which can reduce performance and be mistaken as fuel system problems. Check the condition of the fuel strainer before adjusting engine idle speed, where applicable. -
Page 15: Maintaining The Spark Plug
BPX-600 Post Driver Maintaining the Spark Plug If the spark plug is damaged (cracked insulator, broken or eroded electrodes etc), replace it. • Always use spark plugs of the correct “heat range” - see Specifications. The spark plug is used to ignite the air/fuel mixture inside the engine. The spark plug has electrodes on one end and an electrical terminal on the other. -
Page 16: Transportation And Storage
BPX-600 Post Driver Transportation and Storage Always ensure that the machine is cool enough to touch before transporting or storing. • Petrol/fuel/gasoline is extremely flammable – keep clear of naked flames or other ignition sources. • Always transport the machine with the engine ON/OFF switch in the “OFF” position. -
Page 17: Troubleshooting
BPX-600 Post Driver Troubleshooting Running combustion engines in confined areas CAN KILL IN MINUTES. Engine exhaust fumes contain carbon-monoxide – a deadly gas that you cannot smell or see. NEVER run a combustion engine in confined areas EVEN IF windows and doors are open. ONLY run combustion engines OUTDOORS and away from doors, windows and vents. -
Page 18: Specifications
BPX-600 Post Driver Difficulty restarting the engine after use or engine stops suddenly during use. Possible Fault Action No fuel or engine oil Check fuel level and ensure adequate fuel is available. For some engines, an engine oil sensor will automatically switch off the engine or prevent starting if a low engine oil level is detected. -
Page 19: Service And Maintenance Record
BPX-600 Post Driver Service and Maintenance Record Use the following tables as a record of machine servicing and maintenance. Keeping accurate records will help ensure better machine service life and may simplify fault diagnosis and any possible warranty claims. Place a tick in the required box for either clean or replace with the date, as required. - Page 20 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death, consult the points below and additionally, the information available at www.datastreamserver.com/safety •...
