- Page 1 OWNER'S MANUAL ELECTRIC RANGE Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH LSES6338 www.lg.com MFL68920538 Rev.01_082421 Copyright © 2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY Test Run INSTRUCTIONS 21 Test the Range Before Use 23 OPERATION READ ALL INSTRUCTIONS BEFORE USE 4 Safety Messages Control Panel 4 Anti-Tip Device 23 Control Panel Features WARNING 25 Knob Positions 5 Installation 26 Knob Lighting 5 Operation Changing Oven Settings 6 Maintenance... - Page 3 50 Wireless LAN Module Specifications 50 FCC Notice 51 FCC RF Radiation Exposure Statement 51 Open Source Software Notice Information Smart Diagnosis™ Feature 51 Using LG ThinQ to Diagnose Issues 51 Using Audible Diagnosis to Diagnose Issues 52 MAINTENANCE Cleaning...
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Download this owner's manual at http://www.lg.com Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. -
Page 5: Installation
IMPORTANT SAFETY INSTRUCTIONS • Do not step or sit on the oven door. The range could be tipped and injury might result from spilled hot liquid, food, or the range itself. • Never remove the oven legs. The range will not be secured to the anti-tip bracket if the legs are removed. -
Page 6: Maintenance
IMPORTANT SAFETY INSTRUCTIONS • Always use pot holders or oven mitts when removing food from the oven or the surface element. Cookware will be hot. Use only dry pot holders. Moist or damp pot holders on hot surfaces may result in burns from steam. -
Page 7: Caution
IMPORTANT SAFETY INSTRUCTIONS • If a cabinet storage is provided directly above cooking surface, place items that are not frequently used and can be safely stored in an area subjected to heat. Temperatures may be unsafe for volatile items such as flammable liquids, cleaners or aerosol sprays. •... -
Page 8: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features Exterior & Interior Cooktop Cooktop controller Oven door Storage drawer Oven mode knob Gasket Broil heater Convection heater Model & serial number plate Product Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Oven Range Models LSES6338 Description... -
Page 9: Included Accessories
Gliding rack (1ea) Optional Accessories Grid Broiler pan NOTE • Contact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing. • For your safety and for extended product life, only use authorized components. • The manufacturer is not responsible for product... -
Page 10: Installation
10 INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. -
Page 11: Tools Needed
INSTALLATION Tools Needed 4-Wire cord or 3-Wire cord (UL approved 40 or 50 AMP) Strain relief (For conduit installations only) NOTE • Observe all governing codes and ordinances. • Have the installer show you the location of the circuit breaker or fuse. Mark it for easy reference. -
Page 12: Choosing The Proper Location
12 INSTALLATION Flooring NOTE • Your range is heavy and can be installed on soft CAUTION floor coverings such as cushioned vinyl or • Use an insulated pad or 1/4 in. (0.64 cm) plywood carpeting. Use care when moving the range on under the range if installing the range over this type of flooring. -
Page 13: Dimensions And Clearances
INSTALLATION Dimensions and Clearances Dimensions Dimensions LSES6338 Width 29 7/8" (758.8 mm) Height 37 1/4" (946 mm) Depth (Includes Door Handle) 29 3/8" (745.2 mm) Height (Excludes Vent Trim) 36" (913.0 mm) Depth (Includes only the product body that is loaded into the cabinet. 24 3/4"... -
Page 14: Minimum Dimensions
14 INSTALLATION Clearances Acceptable electrical outlet area Normal counter top depth Counter top height Cabinet Wall Center A (Cabinet opening) = 30" (76.2 cm) For U.S.A = 30" (76.2 cm) ~ 31" (78.7 cm) For CANADA Minimum Dimensions... -
Page 15: Leveling
INSTALLATION 30" (76.2 cm) minimum clearance between the top of the cooking surface and the bottom of an unprotected wood or metal cabinet; or 24" (60.9 cm) minimum when bottom of wood or metal cabinet is protected by not less than 1/4"(6.4 cm) flame retardant millboard covered with not less than no. 28 MSG sheet steel, 0.015"... -
Page 16: Connecting The Power Cord / Conduit
16 INSTALLATION Connecting the Power Cord / Specified Power Cord Kit Rating Conduit Case 1 The rear access cover must be removed. Loosen • Voltage: 120/240 volts (3-wire) the two screws with a screwdriver. The terminal block will then be accessible. •... - Page 17 INSTALLATION Tighten the 3 screws securely into the Ring terminal block. Body Cord/Conduit connection plate CAUTION Conduit • Do not remove the ground strap connections. 3-Wire Connection: Power Cord WARNING • The middle (neutral or ground) wire, which is white, of a 3-wire power cord or a 3-wire conduit has to be connected to the middle post of the main terminal block.
-
Page 18: Conduit Connections
18 INSTALLATION Insert the power cord through the strain relief Cord/Conduit connection plate and tighten it. Bend strap up and attach. CAUTION 3-Wire Connection: Conduit • Do not install the power cord without a strain relief. WARNING • If screws are not tightened securely, it can result in electrical spark and severe personal injury or Remove the lower 3 screws from the terminal death. - Page 19 INSTALLATION Conduit Installations Insert the bare wire (white/neutral) end through the center terminal block opening. Do not remove the ground strap connections. CAUTION • Do not install the conduit without a strain relief. Insert the two side bare wire ends into the lower left and the lower right terminal block Remove the cord/conduit connection plate openings.
-
Page 20: Optional Rear Filler
20 INSTALLATION Optional Rear Filler Attach the ground (green) bare wire end to the range frame and secure it in place with the ground screw. Installing the Rear Filler If the counter does not bridge the opening at the Insert the bare wire (white/neutral) end rear wall, the rear filler kit which is provided with through the center terminal block opening. -
Page 21: Anti-Tip Device
INSTALLATION Anti-Tip Device • Screws must enter wood or concrete. Installing the Anti-Tip Device Tip Hazard WARNING • A child or adult can tip the range and be killed. Anti-tip bracket Wall plate Engaging the Anti-tip Device • Install the anti-tip device to the structure and/or the range. - Page 22 22 INSTALLATION and off periodically even when the knob is in the Hi position. This cycling prevents the glass-ceramic from being cracked by thermal shock. NOTE • The Warm Zone does not consume enough power to glow red. After checking all the surface heating elements, check the locking system by pressing Control Lock for three seconds.
-
Page 23: Operation
OPERATION OPERATION Control Panel Control Panel Features Model: LSES6338 Smart Diagnosis Use during the Smart Diagnosis feature. Control Lock Press and hold the button for 3 seconds to lock the control panel. Cook Time Press the button to set the desired amount of time for food to cook. The oven shuts off when the set cooking time runs out. - Page 24 24 OPERATION Oven Mode Knob Turn the knob to select oven operating mode. NOTE • Flashing Clock If the colon in the clock display flashes, press Clock and reset the time, or press any key to stop the flashing. • Press any button on the control panel to activate the display. •...
-
Page 25: Knob Positions
OPERATION Knob Positions After cleaning the oven knobs, make sure to replace each knob in the correct position. Failure to do so can result in improper operation of the burners. Dual (Mark A) Icon Type1 Icon Type2 Single (Mark C) Icon Type1 Icon Type2 Mode... -
Page 26: Knob Lighting
26 OPERATION Knob Lighting Knob lighting illuminates the edge of the knob when you turn the knob to operate the heating elements (excluding Mode knob). LED Lighting Mode Knob NOTE • Oven Mode knob does not have knob lighting. • If the knob lighting does not match the actual operation of the heating elements, it may indicate a problem with the product. -
Page 27: Timer On/Off
OPERATION Timer On/Off The power on chime sounds, SEt appears in the display, and the Wi-Fi icon ( ) blinks. The Timer On/Off serves as an extra timer in the kitchen that beeps when the set time has run out. It does not start or stop cooking. -
Page 28: Adjusting The Oven Thermostat
28 OPERATION the display. For example, select Conv. Bake, enter • Once the temperature is increased or decreased, 350 ℉, and 325 ℉ shows on the display after the display shows the adjusted temperature preheat. until it readjusts. Convection Auto Conversion is enabled by default. To change the setting, follow these instructions. -
Page 29: Control Lock
OPERATION Control Lock Press Cook Time and touch the number buttons to set the baking time. The Control Lock feature locks the control panel and oven mode knob. Press Start Time. • When the Control Lock feature is activated, the cooktop and oven mode knob do not operate. -
Page 30: Minimum & Maximum Default Settings
30 OPERATION Set the baking time: press 3 and 0 (for 30 Min. Max. minutes). Temp. Temp. • The baking time can be set for any amount Feature Default of time between 1 minute and 11 hours and Time Time 59 minutes 0:01 11:59... -
Page 31: Cooktop
OPERATION • Glazed cookware. Only certain types of glass, NOTE glass-ceramic, ceramic, earthenware, or other glazed cookware are suitable for range-top • * : Using auto conversion service without breaking due to the sudden • Default cook mode times are without setting a change in temperature. -
Page 32: Using The Cooktop Elements
32 OPERATION Turn the knob in either direction to the TRIPLE desired setting NOTE • The control knob clicks when it is positioned at OFF, HI and LO. • It is normal to see a very faint red ring around the outer edge of a dual or triple element when using it as a single element at a high heat setting. -
Page 33: Turning On The Warm Zone
OPERATION Turning on the Warm Zone Icon Type 1 Icon Type 2 Single CAUTION • FOOD POISON HAZARD : Bacteria may grow in food at temperatures below 140 °F. Single Bridge - Always start with hot food. Do not use the warm setting to heat cold food. -
Page 34: Using The Proper Cookware
Do not use the cooktop if element. Check for flatness by placing a ruler metal has melted on it. Call an authorized LG across the bottom of the cookware. The ruler Service Center. -
Page 35: Oven
OPERATION Oven Vent temperature is reached. Not recommended for use on ceramic cooktops. Areas near the vent may become hot during • Porcelain-enamel on metal - Heating operation and may cause burns. Do not block the characteristics will vary depending on base vent opening. -
Page 36: Instaview
36 OPERATION Instaview Setting the Bake Function (example, 375 ℉) Knock twice on the center of the glass panel to reveal the contents of the oven without opening Turn the oven mode knob to select Bake. the door. Set the oven temperature: press 3, 7 and 5. Press START. -
Page 37: Convection Mode
OPERATION Convection Mode combines cooking with the convection fan to roast meats and poultry. The heated air circulates The convection system uses a fan to circulate the around the food from all sides, sealing in juices heat evenly within the oven. Improved heat and flavors. -
Page 38: Broil
38 OPERATION Rack and Pan Placement Rack Food position Cheesecake, crème Custards brulée Soufflés Sweet or savory Casserole Frozen lasagna Roasting Rack Guide Rack Food Multiple rack baking position Rare Medium Well done Boneless Rare Beef rib, top Medium Heavy duty rack Heavy duty rack sirloin Well done... - Page 39 OPERATION • When using your broiler, the temperature inside • Keep the interior of your oven as clean as the oven will be extremely high. Take caution to possible. Leftover debris from prior meals can avoid possible burns by: burn or catch fire. - Keeping the door closed when broiling •...
-
Page 40: Recommended Broiling Guide
40 OPERATION Recommended Broiling Guide The size, weight, thickness, starting temperature, and your preference of doneness will affect broiling times. This guide is based on meats at refrigerator temperature. For best results when broiling, use a pan designed for broiling. Grid (sold separately) Broiler pan (sold separately) First... - Page 41 OPERATION First Second Quantity and/or Rack Food Side Side Comments Thickness Position (min.) (min.) " thick) Pork Chops Well done 2 (1" thick) about 1lb. 2 (1" thick) Medium about 10 to 12 Well done Lamb Chops Medium 2 (1 "...
-
Page 42: Proof
42 OPERATION Proof has finished using a Timed Cook or a Delayed Timed Cook. This feature maintains a warm oven for rising yeast-leavened products before baking. (Set Setting the Warm Function temperature: 92 °F) Turn the oven mode knob to select Proof/ Setting the Proof Function Warm until Proof appears in the display. -
Page 43: Air Fry
• Use either the optional air fry tray available from The Air Fry function is specially designed for oil- LG or a dark baking tray with no sides or short free frying. sides that does not cover the entire rack. This allows for better air circulation. -
Page 44: Recommended Air Frying Guide
44 OPERATION • Keep the oven free from grease buildup. Wipe CAUTION down the interior of the oven before and after air frying (once the oven has cooled). • Never cover slots, holes, or passages in the oven bottom or cover entire racks with materials such •... -
Page 45: Air Sous-Vide
OPERATION Quantity Rack Recommended Items Temp. (°F) Time Guide (oz) Position Frozen Chicken Strips 30-40 Frozen Hot Wings, Bone- 30-40 CHICKEN-Fresh, Skin on 30-35 Brush or lightly spray with † Fresh Chicken Wings 1 tbsp. of oil. Add salt and Fresh Chicken 35-45 pepper to taste. -
Page 46: Recommended Air Sous-Vide Guide
46 OPERATION ice bath and stored in the freezer or Turn the oven mode knob to select Air Sous- refrigerator after cooking. Vide mode. • Crisp and Moist Results - The fine temperature control of Air Sous-Vide Set the desired oven temperature. (Range: cooking is an excellent way to achieve the 100 °F ~ 205 °F) perfect texture when cooking meat and... -
Page 47: Meat Probe
OPERATION Setting the Meat Probe Function Functions section to connect the appliance to the network. (example for roast at 375 °F with probe temp. 160 °F) Setting Remote Start Insert the meat probe into the meat. Open the oven door to make sure the oven is empty and ready for pre-heating. -
Page 48: Using The Sabbath Mode
48 OPERATION Press Start. all function buttons are inactive. will appear in display. Set the probe temperature. Disconnect the probe. The probe function is not available in Sabbath mode. Press Start. Turn the oven mode knob to select Bake. IMPORTANT NOTE Turn the oven mode knob to the OFF position to Set the desired temperature and cook time. -
Page 49: Smart Functions
LG ThinQ • LG ThinQ is not responsible for any network application and connect it again. connection problems or any faults, malfunctions, • This information is current at the time of or errors caused by network connection. -
Page 50: Installing The Lg Thinq Application
Connecting to Wi-Fi connected. • Consult the dealer or an experienced radio/TV The Wi-Fi button, when used with the LG ThinQ technician for help. application, allows the appliance to connect to a This device complies with part 15 of the FCC Rules. -
Page 51: Fcc Rf Radiation Exposure Statement
LG ThinQ application. Statement • Launch the LG ThinQ application and select the This equipment complies with FCC radiation Smart Diagnosis feature in the menu. Follow exposure limits set forth for an uncontrolled the instructions provided in the LG ThinQ environment. -
Page 52: Maintenance
52 MAINTENANCE MAINTENANCE Cleaning • To clean the knobs, make sure that they are in the OFF position and pull them straight off the stems. CAUTION • To replace the knobs, make sure the knob has • Do not clean this appliance with bleach. the OFF position centered at the top, and slide the knob directly onto the stem. -
Page 53: Oven Racks
MAINTENANCE Oven Door • Both the broiler pan and grid may be cleaned with a commercial oven cleaner or in the dishwasher. CAUTION • Do not use harsh cleaners or harsh abrasive Oven Racks cleaning materials on the outside of the oven Remove the oven racks before operating the Self door. -
Page 54: Cooktop Surface
54 MAINTENANCE Cooktop Surface Glass-Ceramic Cooktop CAUTION • If any sugar or food containing sugar spills, or plastic or foil melts on the cooktop, remove the material IMMEDIATELY with a metal razor scraper while the cooking surface is still hot to avoid the risk of damage to the glass-ceramic surface. -
Page 55: Maintaining The Cooktop
MAINTENANCE NOTE • Do not use a dull or nicked blade. • Hold the scraper at approximately a 30° angle to the cooktop. • The razor scraper will not damage the markings on the cooking surface. When the cooking surface has completely cooled, apply a few dime-sized dabs of a ceramic glass cooktop cleaner in each burner area. -
Page 56: Metal Marks And Scratches
56 MAINTENANCE NOTE • For additional product information, visit our website at www.lg.com Metal Marks and Scratches CAUTION • Cookware with rough or uneven bottoms can mark or scratch the cooktop surface. • Do not slide metal or glass across the cooktop surface. - Page 57 MAINTENANCE • Do not open the oven door during the EasyClean NOTE cycle. Water will not get hot enough if the door is opened during the cycle. • For models without Self Clean option - The EasyClean feature may not be effective in removing heavy, built-up soils.
-
Page 58: Self Clean
58 MAINTENANCE Close the oven door. Turn the oven mode If some light soils remain, repeat the above knob to select EasyClean. Press START. steps, making sure to thoroughly soak the soiled areas. CAUTION • For models with Self Clean function •... - Page 59 MAINTENANCE • The kitchen should be well ventilated to (aluminum foil will melt to the interior surface of minimize the odors from cleaning. Open a the oven). window or turn on a ventilation fan or hood • Do not force the door open. This can damage the before self-cleaning.
-
Page 60: Setting Self Clean
60 MAINTENANCE Soil Level Cycle Setting NOTE • If the clock is set for a 12-hour display (default) Moderately Soiled Oven 4-Hour Self Clean the Delayed Self Clean can never be set to start Cavity more than 12 hours in advance. Heavily Soiled Oven 5-Hour Self Clean •... -
Page 61: Removing/Assembling Lift-Off Oven Doors
MAINTENANCE Set the time of day you would like the Self Close the door to the removal position Clean to start by pressing numbers. (approximately five degrees) which is halfway between the broil stop position and fully closed. If the position is correct, the hinge Press START. -
Page 62: Removing/Assembling Drawers
62 MAINTENANCE Hinge arm Lever Hinge lock Push down with finger Pull up with finger Close the oven door. Pull the drawer away from the range. Removing/Assembling Drawers Assembling Drawers Removing Drawers Pull the bearing glides to the front of the chassis glide. -
Page 63: Periodic Maintenance
MAINTENANCE Lift the vent trim. Plug in the range or reconnect the power. Assembling the Vent Trim Assemble the vent trim in the reverse sequence of its removal. Periodic Maintenance Changing the Oven Light The oven light is a standard 40-watt appliance halogen. -
Page 64: Troubleshooting
64 TROUBLESHOOTING TROUBLESHOOTING FAQs Frequently Asked Questions What types of cookware are recommended for use with the cooktop? • The pans must have a flat bottom and straight sides. • Only use heavy-gauge pans. • The pan size must match the amount of food to be prepared and the size of the surface element. - Page 65 TROUBLESHOOTING Can I leave my racks in the oven when running a Self Clean cycle? (On some models) No. Although it will not damage the racks, it will discolor them and may make them hard to slide in and out during use. Remove all items from the oven before starting a Self Clean cycle. What should I do if my racks are sticky and have become hard to slide in and out? Over time, the racks may become hard to slide in and out.
-
Page 66: Before Calling For Service
66 TROUBLESHOOTING Yes. The convection fan or heater element may get a little wet during cleaning. However, direct spray onto the broil burner and heater elements is not necessary because these are self-cleaning during regular use. Do I need to use all 1 ¼ cups (10 oz or 300 ml) of water for EasyClean? Yes. - Page 67 TROUBLESHOOTING Problem Possible Cause & Solution Steam is exhausted Cooking foods with high moisture produces steam. through the oven • This is normal. vent. Appliance does not Cord is not plugged in correctly. operate. • Make sure cord is plugged correctly into outlet. Check circuit breakers. Service wiring is not complete.
-
Page 68: Parts And Features
68 TROUBLESHOOTING Problem Possible Cause & Solution Excessive smoking Excessive soil. during a Self Clean • Turn off the Self Clean function. Open the windows to rid the room of smoke. Wait until the cycle (On some Self Clean mode is cancelled. Wipe up the excess soil and reset the clean. models) Burning or oily odor This is normal in a new oven. - Page 69 TROUBLESHOOTING Problem Possible Cause & Solution Areas of Food spillovers not cleaned before next use. discoloration on the • See the "Glass-Ceramic Cooktop" section in the MAINTENANCE chapter. cooktop Hot surface on a model with a light-colored cooktop. • This is normal.The surface may appear discolored when it is hot. This is temporary and will disappear as the glass cools.
-
Page 70: Noises
70 TROUBLESHOOTING Problem Possible Cause & Solution Oven will not Self The oven temperature is too high to set a Self Clean operation. Clean. (On some • Allow the range to cool and reset the controls. models) Oven controls improperly set. •... -
Page 71: Wi-Fi
TROUBLESHOOTING Wi-Fi Problem Possible Cause & Solution Trouble connecting The password for the Wi-Fi network was entered incorrectly. appliance and • Delete your home Wi-Fi network and begin the registration process again. smartphone to Wi-Fi network Mobile data for your smartphone is turned on. •... -
Page 72: Limited Warranty
Should your LG Electric Range ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics (“LG”) will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product and applies only when purchased and used within the United States including U.S. - Page 73 • Increases in utility costs and additional utility expenses. • Any noises associated with normal operation. • Use of accessories, components, or consumable cleaning products that are not authorized by LG. • Replacement of light lamps, filters, or any consumable parts.
- Page 74 74 LIMITED WARRANTY Problem Possible Cause & Prevention Cooktop enamel Improper usage chipping off • Do not hit enamel cooktop. Pitting of the If not removed immediately, sugary spillovers (such as preserves, ketchup, cooktop glass tomato sauce, jellies, fudge, candy, syrups, or chocolate) or melted plastic or foil can cause surface pitting of the cooktop.
-
Page 75: Procedure For Resolving Disputes
Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632 USA. - Page 76 76 LIMITED WARRANTY subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
- Page 77 LIMITED WARRANTY You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure. Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benefits of the Limited Warranty.
- Page 78 78 Memo...
- Page 79 Memo...
- Page 80 80 Memo...
- Page 81 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: U.S.A. 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...
