- Page 1 ELECTRIC FOLDING SCOOTER OP ER AT I ON M A N U AL H1 - J N Y - D M...
- Page 2 HELMETS SAVE LIVES! Always wear a properly fitted helmet that complies with CPSC or CE safety standards when you ride your E-Scooter. Correct Fit: Make sure your helmet covers your forehead. Incorrect Fit: Forehead is exposed and vulnerable to serious injury.
- Page 3 In this manual, the WARNING sign indicates a hazardous situation which, if not avoided, can cause serious injury or death. WARNING Great care should be taken with the Hover-1 Journey Max when folding and unfolding it. Moving and folding parts can cut skin or pinch if mishandled.
- Page 4 Hover-1 can not be held liable. ATTENTION 1. Use only the supplied charger from Hover-1 with this E-Scooter. 2. The operating temperature range of the charger is 32°F - 104°F (0°C - 40°C). 3. The operating temperature range of the Journey Max is 32°F - 104°F (0°C - 40°C).
- Page 5 LOW TEMPERATURE WARNING Low temperatures will affect the lubrication of moving parts inside the Journey Max, increasing internal resistance. Additonally, the discharge capacity and capacity of the battery will be significantly decreased. Use caution when riding the Journey Max in cold temperatures (below 40°F/4°C).
- Page 6 • Do not operate or allow others to operate the Journey Max until the user understands all instructions, warnings, and safety features described in this manual. • Check with your doctor if you have a medical condition that could affect your ability to use the Journey Max. •...
-
Page 7: Safety Precautions
• Hover-1 is not liable for tickets or violations given to riders who do not follow local laws and regulations. • For your safety, always wear a helmet that meets CPSC or CE safety standards. - Page 8 • Obey all local traffic laws. Obey red and green lights, one-way streets, stop signs, pedestrian crosswalks, etc. • Ride with traffic, not against it. • Ride defensively; expect the unexpected. • Give pedestrians the right-of-way. • Do not ride too close to pedestrians and alert them if you intend to pass them from behind.
- Page 9 • Do not try to open or modify your Journey Max E-Scooter. Doing so voids the manufacturer warranty and may cause your Journey Max to fail, resulting in injury or death. • Do not use the Journey Max in a manner that would put people or property in danger.
- Page 10 WARNING Proper use of your brake is vital to ensure safe, efficient stopping. To avoid misuse and potential injury, do not apply sudden or excessive force to your brakes. Apply your brakes gradually and give yourself enough room to come to a complete stop safely. and carry your Journey Max.
- Page 11 • Do not attempt to jump on or off your Journey Max. • Do not attempt any stunts or tricks with your Journey Max. • Do not ride the Journey Max in dark or poorly lit areas. • Do not ride the Journey Max near or over potholes, cracks, or uneven pavement or surfaces.
-
Page 12: Care And Maintenance
• Do not let the Journey Max fall from high places, as doing so may damage the internal circuitry. • Do not attempt to disassemble the Journey Max. • Use only the charger provided by Hover-1. • Use only the manufacturer’s authorized replacement parts. WARNING Avoid using water or other liquids for cleaning. -
Page 13: Battery Care / Maintenance
BATTERY CARE / MAINTENANCE BATTERY SPECIFICATIONS Battery Type: Rechargeable lithium-ion battery Charge Time: Up to 6.5 hours Battery Voltage: 36Vdc Battery Capacity: 13Ah Working Temperature: 32°F - 104°F Charging Temperature: 32°F - 104°F Storage Time: 1 year Storage Temperature: 32°F - 104°F Storage Humidity: 5% - 95% BATTERY MAINTENANCE •... - Page 14 • The battery contains dangerous substances, do not open the battery, or insert anything into the battery. • Please only use the charger provided by Hover-1. • Do not attempt to charge the device if the battery has discharge or emits any substances. In that case, immediately distance yourself from the battery in case of fire or explosion.
-
Page 15: Specifications
SPECIFICATIONS Model: H1-JNY-DM Net Weight: 44.77 lbs (20.31 kgs) Max Supported Weight: 264 lbs (120 kg) Min Supported Weight: 44 lbs (20 kg) Max Speed: Up to 19 mph (30.57 km/h) Max Range: Up to 26 miles (41.84 km) Battery Type:... - Page 16 HOVER-1 JOURNEY DIAGRAM FEATURES/PARTS 1. LCD Display 8. Steering Column 2. Brake Handle 9. Folding Hinge 3. Handlebar (L) 10. Charging Port 4. Handlebar (R) 11. Foot Deck 5. Throttle 12. Kickstand 6. Power Button 13. Folding Hook 7. Folding Clip 14.
-
Page 17: Lcd Display
HOVER-1 JOURNEY DIAGRAM BRAKE HANDLE LCD DISPLAY POWER BUTTON FOLDING THROTTLE CLIP LCD DISPLAY Displays the current speed mode when toggled. While powered on, press the power button two times to switch between 3 modes: E : Low speed D : Drive mode... - Page 18 CHARGING YOUR JOURNEY • Ensure that the charging port is clean and dry. • Make sure that there is no dust, debris or dirt inside the port. • Plug the charger into a grounded wall outlet. • Connect the cable with the power supply (100V-240V; 50 Hz/60 Hz). •...
-
Page 19: Pinch Points
PINCH POINTS Some parts of your Journey Max can injure you if mishandled. Moving and folding parts can cut skin. Clamps and pivoting parts such as brake levers can pinch. When folding and unfolding your Journey Max, please watch for pinch points where injury may be sustained. Do not leave your hand in these areas during the folding or unfolding process. -
Page 20: Cruise Control
SINGLE / DUAL DRIVE MODE Make sure your scooter is turned on. Press the power button three times, product will beep, product is preset on single Front wheel mode, the F icon will appear on the display. To exchange from single front motor, single rear motor or dual drive mode, press the power button three times. -
Page 21: Before Riding
BEFORE RIDING Before each use, the E-Scooter operator shall perform the pre-operation checks as specified below: • The area that the unit is to be operated in is safe and suitable for safe operation. • The braking system is functioning properly. •... - Page 22 RIDING YOUR JOURNEY FAILURE TO FOLLOW ANY OF THE FOLLOWING SAFETY PRECAUTIONS MAY LEAD TO DAMAGE TO YOUR DEVICE, DAMAGE TO PROPERTY, VOID YOUR MANUFACTURER WARRANTY, AND MAY CAUSE SERIOUS BODILY INJURY OR DEATH. OPERATING YOUR DEVICE Make sure the device is fully charged before the first use. Before turning on your Journey Max E-Scooter, ride it like a normal kick scooter to get comfortable with the device before using it with the motor.
- Page 23 SPEED AND WEIGHT LIMITATIONS Speed and weight limits are set for your own safety. Please abide by the limits listed here in the manual. • Maximum Speed: 19 mph • Maximum Supported Weight: 264 lbs • Minimum Supported Weight: 44 lbs WARNING Riding Journey...
-
Page 24: Safety Alerts
SAFETY ALERTS If a system error occurs or an improper operation is performed while riding your Journey Max, the device will alert the user in a variety of ways. The following are common occurrences that will produce safety alerts. These notices should not be ignored and appropriate action should be taken to correct any improper operation, failure, or errors. -
Page 25: Fcc Statement
FCC STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 26: Warranty
WARRANTY For warranty information, please visit us at www.hover-1.com Error E1 - Motor hall failure, the motor needs to be replaced MOS fault or motor phase line short Error E2 - circuit fault Brake failure Error E3 - Error codes... - Page 27 @Hover1Rideables @RideHover1 @RideHover1 www.Hover-1.com...
