VM5404D / VM5808D User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
VM5404D / VM5808D User Manual User Information Online Registration Be sure to register your product at our online support center: International http://eservice.aten.com Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America...
VM5808D installation. Chapter 3 Front Panel Configuration, explains the fundamental concepts involved in operating the VM5404D / VM5808D at the local site via the front panel LCD display using pushbuttons. Chapter 4 Browser Operation, provides a complete description of the VM5404D / VM5808D's Browser Graphical User Interface (GUI), and how to use it to remotely configure and operate the VM5404D / VM5808D.
For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com...
Page 11
VM5404D / VM5808D User Manual This Page Intentionally Left Blank...
Introduction Overview The ATEN VanCryst VM5404D / VM5808D 4 x 4 / 8 x 8 DVI Matrix Switch with Scaler is a versatile solution that provides an easy way to route high definition video and audio from any of 4/8 DVI sources to any of 4/8 DVI displays at the same time.
VM5404D / VM5808D User Manual Features 4x4 or 8x8 DVI I/O connections Extends IR transmission via IR extension cable Scaler – features a video scaling function to integrate a video wall seamlessly with various output video formats Seamless Switch™ – features close-to-zero second switching that provides...
Chapter 1. Introduction Requirements The following devices are required for a complete VM5404D / VM5808D installation: Source Devices Computer or A/V source device with DVI-D output connector(s) Note: A DVI/HDMI adapter is required when connecting a HDMI source device. Display Devices...
VM5404D / VM5808D User Manual Source Device Operating Systems Supported operating systems are shown in the table below: Version Windows 2000 and higher Linux RedHat 6.0 and higher SuSE 8.2 and higher Mandriva (Mandrake) 9.0 and higher UNIX 4.3 and higher FreeBSD 3.51 and higher...
Chapter 1. Introduction Components VM5404D Front View Component Description LCD Display The LCD Display gives a quick view of all port connections, and shows the various options for configuring and operating the VM5404D. For full details, see Main Screen, page 17. Input Pushbuttons These pushbuttons refer to the DVI Input ports found on the VM5404D rear panel.
VM5404D / VM5808D User Manual VM5404D Rear View Component Description Power Socket This is a standard 3-pin AC power socket. The power cord from an AC source plugs in here. Power Switch This is a standard rocker switch that powers the unit on and off.
Main Screen, page 17. Input Pushbuttons These pushbuttons refer to the DVI Input ports found on the VM5808D rear panel. Press to select the Input port. These pushbuttons may also correspond to menu options, connection profiles (P1–P8) and so on.
Ethernet Port In order to access the VM5808D’s Browser Graphical User Interface (GUI), the VM5808D must be connected to your network. The cable that connects the VM5808D to your LAN plugs in here. See Cable Connection, page 13, for further details...
Chapter 1. Introduction IR Remote Control Component Description Power ON/OFF Use the ON and OFF pushbuttons to turn the Output displays on or off – by individual port, or all ports. (see IR Remote Control Operation, page 34) Output Pushbuttons Press Output display pushbuttons 1–8 to select the Output display you want to configure (see IR Remote 1–8...
Page 22
VM5404D / VM5808D User Manual This Page Intentionally Left Blank...
Keyboard Power On function. Rack Mounting The VM5404D / VM5808D can be mounted in a 19” (1U) system rack. For the most convenient front panel pushbutton configuration and operation at the local site, mount the unit at the front of the rack, as follows: 1.
To prevent damage to your installation, it is important that all devices are properly grounded. 1. Use a grounding wire to ground the VM5404D / VM5808D by connecting one end of the wire to the grounding terminal, and the other end of the wire to a suitable grounded object.
Note: Do not omit this step. Proper grounding helps to prevent damage to the unit from surges or static electricity. 2. Connect up to 4 (VM5404D) or 8 (VM5808D) DVI video sources to the DVI Input ports 3. Connect up to 4 (VM5404D) or 8 (VM5808D) DVI display devices to the DVI Output ports 4.
Chapter 3 Front Panel Configuration Overview The VM5404D / VM5808D can be configured and operated locally via the front panel LCD/pushbuttons and IR Remote Control; remotely over a standard TCP/IP connection via graphical user interface (GUI) using a web browser; via a remote terminal session using Telnet;...
If the Password screen / LCD Menu fails to load, an error message displays. Reset the unit and try again. If you are accessing the VM5404D / VM5808D for the first time, the Password screen appears as soon as the LCD loading process is done. Enter the default password 1234 to continue to the Main Screen (see Main Screen, page 17).
Chapter 3. Front Panel Configuration Main Screen The Main Screen shows the Input ports in the top row, which are tied to the Output ports shown in sequential order (1–8) or (1–4) at the bottom row. INPUT 1 2 5 5 1 1 OUTPUT 1 2 3 4 5 6 7 8 The front panel pushbutton label (1–8) or (1–4) corresponds to the Input...
Page 30
VM5404D / VM5808D User Manual (Continued from previous page.) 2. To disconnect an Output port from an Input port, press the corresponding Output port pushbutton. In the example below, Output port 2 has been disconnected from Input port 3. To switch to another Input port, press any Input port pushbutton. The Output port LED(s) tied to the said Input port will flash.
Chapter 3. Front Panel Configuration Output Port Selection Use the Output Port pushbuttons to select the Output port you want to configure. INPUT 1 2 5 5 1 1 3 4 OUTPUT 1 2 3 4 5 6 7 8 To select which output display corresponds to each input source device, do the following: 1.
Page 32
VM5404D / VM5808D User Manual 4. To switch Output ports 2, 3 and 4 to another Input port (and disconnect it from Input port 2), press another Input port pushbutton to which you want them tied. In the example below, Input port 3 has been pressed and is now connected to Output ports 2, 3 and 4.
Chapter 3. Front Panel Configuration LCD Menu Organization The VM5404D / VM5808D has a built-in configuration utility via the front panel LCD, which can be controlled by pressing the MENU and front panel Input pushbuttons (1–8). User can cycle through the menu options, starting...
The values in the LCD Menu are read-only and can be edited via the Browser GUI (OSD, page 74). IP Address / Subnet Mask To view the VM5404D / VM5808D’s IP address and Subnet Mask, do the following: 1. From the Menu page, press 1 to see the IP Setting submenu. The IP address and Subnet Mask are then shown.
Chapter 3. Front Panel Configuration Gateway To view the VM5404D / VM5808D’s gateway address, do the following: 1. From the Menu page, press 1 to see the IP Setting submenu, then press 8 to get to the next page. The gateway address displays.
VM5404D / VM5808D User Manual Serial Port Setting To configure the VM5404D / VM5808D’s baud rate for its serial port connection, select Serial Port Setting from the Menu page. 1: IP Setting 2: Serial Port Setting 8: Next Baud Rate To set the VM5404D / VM5808D’s baud rate, do the following:...
Output Resolution To configure the VM5404D / VM5808D’s operation mode settings from the Main Screen, use the Menu pushbutton to access the Menu page, press 8/Next to navigate to the next page, then press pushbutton 1 to access the Operation Mode page.
The On-Screen Display or OSD feature enables real-time text updates to appear on the display device’s screen for any configuration changes made to the Output port via the VM5404D / VM5808D’s front panel, IR remote control or Browser GUI. To configure the OSD setting for each output port, do the following: 1.
Chapter 3. Front Panel Configuration 3. Press pushbuttons (1–8) or (1–4) to enable (ON) or disable (NA) the OSD feature for the output port. OUTPUT 1 ON ON ON NA ON NA ON NA Note: The default OSD setting is On. 4.
Page 40
VM5404D / VM5808D User Manual To configure the Output Resolution settings for each output port, do the following: 1. From the Operation Mode page, press 8 or Next to go to the next page, then press pushbutton 2: 7: Back...
Chapter 3. Front Panel Configuration Security Mode The Security Mode page allows users to manage the VM5404D / VM5808D’s security-related settings. Three security modes are available: None, Password Enable and Lock Screen. The VM5404D / VM5808D’s password can also be changed here.
New Password: * * * * 4. Re-enter the new password in the following screen. The new password is applied by the VM5404D / VM5808D immediately. Re-enter New Password: * * * * If the password you entered does not match the one entered in the previous screen, an error message appears.
Chapter 3. Front Panel Configuration Save to a Profile The switch allows users to store up to 8 (VM5404D) or 16 (VM5808D ) (numbered P1–P16) different connection profiles that can be saved and recalled later. The active Input-to-Output port connections on the LCD Main Screen is the configuration saved to a profile.
VM5404D / VM5808D User Manual Play/Stop the Profile Schedule Inputting port pushbutton 2 will Play or Stop the active Profile Schedule. 7: Back 1: Save to a Profile 2: Play/Stop the Profile Schedule...
Press the Cancel pushbutton to exit Note: If there are no profiles configured on the VM5404D / VM5808D device, an error message “No Available Profile” is displayed when the Profile pushbutton is pressed.
Output displays simultaneously Before using the remote control, a user must first plug the IR External Receiver into the rear panel of the VM5404D / VM5808D and place the receiver where the IR signal can be reached (see IR Port, page 8).
Chapter 3. Front Panel Configuration Power on/off all Output displays To power on/off all Output displays simultaneously, with the remote control, do the following: 1. Press the ON or OFF pushbutton.* 2. Repeat step 1 to simultaneously change back the power status of all Output ports, to on or off, respectively.
Page 48
VM5404D / VM5808D User Manual This Page Intentionally Left Blank...
For full details, see the sections that follow. Logging In To access the GUI, type the VM5404D / VM5808D’s IP address into the address bar of any browser. If a Security Alert dialog box appears, accept the certificate –...
VM5404D / VM5808D User Manual Main Page The Main Page opens to the Profile List. This is where you configure the input to output connections by creating profiles. The page is divided into three parts: the Menu Bar, Profile List, and Profile Scheduling.
Profile List The Profile List lets you configure the input to output port connections by creating profiles to use. You can store up to 8 (VM5404D) or 16 (VM5808D) differently configured profiles that can be saved and played by two methods: locally via the unit’s front panel pushbuttons and via the web GUI.
Page 52
VM5404D / VM5808D User Manual 4. New profiles appear in the Profile List, as shown here: 5. Select the profile and click Apply. 6. The profile appears in the large Play window and the connections start: Note: More information about Profile List options are provided on the next...
To export the VM5404D / VM5808D’s connection profiles, do the following: 1. Click Export Profiles. A configuration file will then begin downloading. To import connection profiles to the VM5404D / VM5808D, do the following: 1. Click Import Profiles. 2. Browse to the configuration file, select it and click Open.
VM5404D / VM5808D User Manual Profile List Options Clicking a Profile or the Play window opens a pop-up menu with options. Profile Option Description Apply Click Apply to put the profile in the Play window. This allows you to start the profile connections.
Chapter 4. Browser Operation Option Description Edit Click Edit to configure the profile's input to output connections. Other Option Description Show OSD Check Show OSD to show text updates that appear on the display when configuration or port changes are made. Mute All Check Mute All to mute the audio for all ports.
VM5404D / VM5808D User Manual Profile Scheduling Profile Scheduling is located below the Profile List. Scheduling allows you to queue and play connection profiles in sequence for a specific amount of time. Option Description Click to edit profile schedule. Click to play profile schedule.
Page 57
Chapter 4. Browser Operation After selecting Edit, you will be presented with the following options. Option Description Click to add profiles to the schedule in the order to be played, left to right, then set the amount of time each profile plays. Click a profile for a pop-up menu to appear: Select Startup to use the profile as the starting point for the schedule.
VM5404D / VM5808D User Manual Connection Profiles There are two types of profiles: Digital Signage and Video Wall. Digital Signage profiles are for displays where video is viewed on separate monitors.Video Wall profiles are for displays that are tiled together, where multiple monitors form one large screen –...
Chapter 4. Browser Operation Output Icon Option Description Output Icon Click an Output icon(s) to highlight it in green and use the Select Source menu to set the video options (see Select Source below). The large number is the Video Input port selected for the display. The small number (upper-left corner) is the Output port of the display.
VM5404D / VM5808D User Manual Grid View The Grid View allows you to select the Input to Output connections using a simple grid. Select a box to coordinate Input Ports to Output Ports. By default, ports will be aligned so that i01 will correspond to o01, etc.
Chapter 4. Browser Operation Video Wall Profile Each blank icon represents an Output port and the connected display. Use the icons to create Independent and Grouped Outputs. Independent Outputs will display video on a single monitor. Grouped Outputs will display video across multiple monitors as one large screen.
VM5404D / VM5808D User Manual Number of Displays / Output Order / Bezel Dimensions Option Description Number of Use the Horizontal and Vertical drop-down menu to select the Displays number of displays that make up the video wall (a maximum of 64 are supported).
Chapter 4. Browser Operation Null Input Option Description Null Input Icon Click Null Input icons to highlight icons in green and use the Display Preferences menu to set the video options (see Display Preferences, page 53). Select a single icon to set the Output and Video Input for an independent display (see Independent Output, page 52).
VM5404D / VM5808D User Manual Independent Output Option Description Independent Independent Outputs are displays that have their own Video Input Output and Output selected. Independent Outputs: Display their own video Icons have their own color and Video Input Select an Independent Output and use the Display Preferences (page 53) menu to select the Video Input.
Chapter 4. Browser Operation Group Option Description Group A Group (of Outputs) shares the same Video Input and displays the video together as one large screen. A Group of Outputs: Displays video across multiple monitors to form one screen Icons have the same color and Video Input number. Select a Group and use the Display Preferences menu to select the Video Input.
VM5404D / VM5808D User Manual Option Description Video Input Use the drop-down menu to select the Video Input port. Radio Button Fit Width of Output(s): fits the video to the width of the display. Fit Height of Output(s): fits the video to the height of the display.
Chapter 4. Browser Operation Output Options The Output Options page is used to configure DVI Video options. DVI Video Options DVI Video Options allow you to set Seamless Switch™ options which determine how a display performs when the input port is changed. Note: When Seamless Switch™...
Page 68
VM5404D / VM5808D User Manual Use the drop-down menu to apply to all ports, or ON/OFF button to enable/disable Transitions per port. Period: Sets the fade speed for the Transition option. Use the drop-down menu to apply an option (Slow, Normal, or Fast) to all ports, or lower drop-down menus to apply options per port.
Chapter 4. Browser Operation System Settings Click the Settings link from the Main page for the System Settings to open on the General page: The General page allows you to edit Baud, Language and Fan settings and view device information. The User Account page allows you to add and edit user accounts.
The General page has three sections: Fan Status, Device Info and Other. Fan Status This section displays the VM5404D / VM5808D’s two fans’ statuses. The VM5404D / VM5808D also includes a drop-down menu which allows for manual selection of fan speed.
Page 71
Chapter 4. Browser Operation Options include: English, French, German, Italian, Japanese, Korean, Portuguese, Russian, Spanish, Simplified Chinese and Traditional Chinese. Use the Baud Rate drop-down menu to select a serial port setting. Options include: 9600, 19200, 38400 and 115200.
Note: This is an Administrator only function. Add account – Click the Add account button to add another user to the list. The VM5404D / VM5808D supports up to 32 users and allows up to 16 concurrent logins (see page 61 for more details).
Click Create User to save the data. Click Cancel to discard the changes and exit. If a user is logged into the VM5404D / VM5808D’s GUI, their user settings cannot be edited, and the fields in this screen are grayed out.
The three available permission levels are as follows: Administrator – this level provides full access and control of the VM5404D / VM5808D, in addition to full User Management privileges. Advanced User – this level provides full access and control with no User Management privileges.
Chapter 4. Browser Operation Port Name The Port Name page lets you name the input and output ports for easy identification. To name an Input/Output port, enter a descriptive name of up to 16 multi-language characters (excluding :;=[]+=/?\|) in the corresponding field and click Save.
Telnet settings for connecting to the VM5404D / VM5808D. Enable DHCP to allow the DHCP server to assign an IP address to the VM5404D / VM5808D. Select Disable to enter your own static IP address settings for the device. Click Cancel to use the following default values: IP Address –...
The EDID Settings page lets users view and select an EDID Mode so that the VM5404D / VM5808D can use the best resolution for its display(s). Note: The EDID Mode can also be selected via the Front Panel pushbuttons –...
In the left panel of the page, users can select a pre-configured EDID Mode using the EDID Mode radio buttons. Select the EDID Mode to use and click Apply. The VM5404D / VM5808D uses the settings configured for that EDID mode.
Retrieve EDID: Click and a pop-up window appears to retrieve the EDID settings of a stored EDID configuration: Customized EDID 01- 08, or ATEN Default. Select the port to retrieve: The right panel displays a summary of the acquired EDID settings that you can edit.
VM5404D / VM5808D User Manual EDID & CEA Description The right panel of the screen lets users view the configuration of the EDID and CEA Modes selected: From the left column, click the option that you want to view and/or edit.
Chapter 4. Browser Operation Customized EDID Settings The EDID structure is comprised of 128 bytes in total – each heading shown in the left column corresponds to a specific number of bytes. The pages for the pre-configured EDID Modes (Port 1, Default and Remix) cannot be edited.
Page 82
VM5404D / VM5808D User Manual Standard Timings This page shows eight resolutions/timings that display devices can support in addition to those listed in the Established Timings page. Select the H Active Pixel from the drop-down menu. Select the Aspect Ratio from the drop-down menu.
Chapter 4. Browser Operation Monitor Description This screen lets you specify the viewing specifications, namely horizontal and vertical scan ranges and pixel clock rate, of your monitor/display device. Enter the values that correspond to your device and click Save to apply the changes.
This will ensure the GUI refreshes and functions properly. To back up the VM5404D / VM5808D’s system settings, do the following: 1. Click Backup. A configuration file will then begin downloading.
Chapter 4. Browser Operation HDCP The HDCP page lets users view and set HDCP key settings between input and output ports for digital copy protection and to ensure Seamless Switch™ is used between different devices. This is an Administrator and Advanced User only function.
VM5404D / VM5808D User Manual The OSD page lets users view and set OSD settings for all ports. OSD: Sets the default OSD option for the port. When OSD is on, real- time text updates appear on the display for 10 seconds when configuration and port changes are made to its output.
VM5404D / VM5808D is connected. This mobile application is especially useful for profile and AV source switching when you do not have access to the VM5404D / VM5808D’s front panel or the web interface.
12.0 or later Android 8.0 or later The VM5404D / VM5808D needs to be connected to a local area network via the Ethernet port. Installation and Connections To install the Video Matrix Control App on a mobile device, do the following: 1.
Video Matrix Control App is only effective while the profile is being played and will not be saved to the VM5404D / VM5808D unit. Previews of input assignment, as indicated by input numbers in the control interface on the left, are not supported for VM0404HB, VM0808HA, and VM0808HB.
Page 90
Description In the Audio tab, you can specify the audio input for the digital and analog outputs of the VM5404D / VM5808D. Note: The fields available in this tab may vary for the connected device. In the Settings tab, you can look up...
5. At the login prompt, type the login username and password for the VM5404D / VM5808D. 6. When a session is established with the VM5404D / VM5808D, you can control and configure the VM5404D / VM5808D via RS-232 commands. For more information on commands, see Commands, page 81 Note: If a user logs in using a username that is already in session, the newest login takes effect and the previous session will be replaced.
Connecting to the Matrix Switch via RS-232 You can control and operate the VM5404D / VM5808D using a high-end controller or PC. To connect to the VM5404D / VM5808D via RS-232, do the following: 1. Connect the RS-232 serial port on the VM5404D / VM5808D to the RS- 232 serial port on your computer using a 9-wire straight cable, with only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5 connected.
Command incorrect - indicates that the command has the wrong format and/or values. Commands After connecting to the VM5404D / VM5808D via Telnet or RS-232, you can operate the system using the following commands. Switch Port Command The Switch Port command allows you to switch ports on the VM5404D / VM5808D.
Page 94
VM5404D / VM5808D User Manual Output Command Description Output command Port number Description 01-08 port All output ports Control Description Turn on the display Turn off the display Next Port Previous Port Note: 1. By default, input port 01 is tied to output port 01; input port 02 is tied to output port 02;...
[Enter] The VM5404D / VM5808D implements the EDID of each connected display according to its connection when the VM5808D is first powered on, or immediately after selecting the Remix option. edid default [Enter] ATEN’s default EDID is passed to the video...
Page 96
VM5404D / VM5808D User Manual Command Control Enter Description EDID custom [Enter] Implements the customized mode.
Chapter 6. CLI Commands Mute Command Mute allows you to enable or disable an output port(s) audio. The formula for the Mute command is as follows: Command + Output + Number + Control + [Enter] 1. For example, to mute the audio coming from output port 1, type: mute o01 on [enter] The following tables show the possible values for the Mute command: Command...
VM5404D / VM5808D User Manual Scaling Command The Scaling command allows you to set a resolution for scaling the display connected to an output port. The formula for the Scaling command is as follows: Command + Output + Number 1 + Horizontal Resolution + Number 2...
Page 99
Chapter 6. CLI Commands Resolution Number Description vvvv Vertical resolution Frequency Description freq Frequency command for scaling Frequency Number Description Frequency resolution Control Description Turn off the scaling function (by pass mode) native Map display's native resolution for scaling (default) Note: 1.
Page 100
VM5404D / VM5808D User Manual Horiz Vertic Port Comm Outp ontal Numb Numb Frequ Numb Contr Numb Enter Description Resol Resol ency ution ution scaling 1920 1080 freq [Enter Scale output port yy to 1920x1080@ 60Hz yy: 01 ~ 08 or...
Page 101
Chapter 6. CLI Commands Horiz Vertic Port Comm Outp ontal Numb Numb Frequ Numb Contr Numb Enter Description Resol Resol ency ution ution scaling 1280 1024 freq [Enter Scale output port yy to 1280x1024@ 60Hz yy: 01 ~ 08 or scaling 1024 freq...
VM5404D / VM5808D User Manual Fan Speed Command The Fan Speed command allows you to set the VM5808D’s internal fan speed. Note: This feature is not supported by the VM5404D. To set the fan speed, use the following command: Command + Control + [Enter] 1.
Chapter 6. CLI Commands Echo Command The Echo function updates the RS232 controller when operations are made via the front panel pushbuttons, web browser, or telnet. The changes echo back to the RS232 controller to keep the settings in sync with the device. The formula for the Echo command is as follows: Command + Control + [Enter] 1.
VM5404D / VM5808D User Manual Black Screen Command The Black Screen command turns a display screen black when no source signal is detected. This prevents the display from showing the default blue or other color used when no source signal is detected.
Chapter 6. CLI Commands Read Command The Read command allows you to view information about the device. The formula for the Read command is as follows: Command + [Enter] 1. To view information, type: read [Enter] The following table shows the possible values for the Read command: Command Description read...
VM5404D / VM5808D User Manual Reset Command The Reset command allows you to reset the VM5404D / VM5808D to the default factory settings. The formula for the Reset command is as follows: Command + [Enter] The following tables show the possible values for the Reset command:...
Baud Rate Command The Baud Rate command allows you to set the RS-232 data rate for the VM5404D / VM5808D to use. Options are 9600, 19200 (default) 38400 and 115200. The formula for the Baud Rate command is as follows: Command + Control + [Enter] 1.
VM5404D / VM5808D User Manual Save/Load Profile Command The Save/Load Profile command allows you to save and load connection profiles. Saving profiles will save the connections currently in use. The formula for the Save/Load Profile command is as follows: Command + Profile + Number + Control + [Enter] 1.
Chapter 6. CLI Commands OSD Command To enable or disable the On-Screen Display (OSD) for displays, use the following command: Command + Output + Number + Control + [Enter] 1. For example, to enable the OSD for output 07, type: osd o07 on [Enter] 2.
VM5404D / VM5808D User Manual Alert Command To trigger a warning when issues arise for a specific input port, use the following command: Command + Input + Number + Control + [Enter] 1. For example, to enable the basic Alert function for input port 1, type:...
Appendix Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. This product is for indoor use only. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result.
Page 112
VM5404D / VM5808D User Manual If an extension cord is used with this device make sure that the total of the ampere ratings of all products used on this cord does not exceed the extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes.
Appendix Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack.
VM5404D / VM5808D User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For telephone support, see Telephone Support, page iii: North America Email Support support@aten-usa.com Online Troubleshooting http://www.aten-usa.com/support Technical Documentation Support Software Updates...
VM5404D / VM5808D User Manual Telnet Operation To connect to VM5404D / VM5808D via Telnet, follow the steps in Connecting to the Matrix Switch via Telnet, page 79. Configuration Menu Once a Telnet connection to the VM5404D / VM5808D is established, the device’s text-based Configuration Menu comes up, with the following items:...
Appendix Old IP subnet mask: 255.255.255.0 New IP subnet mask: 4. IP – Set IP address Old IP address: 192.168.0.60 New IP address: 5. LO – Load connections from profile LO 01 Load profile 01 OK. 6. PW – Change password Old password: ******** New password: 7.
VM5404D / VM5808D User Manual 11. SV – Save the current connections into a profile SV 01 Save the current connections into profile 01 12. TI – Set timeout TI 30 Set 30 minute timeout 13. VR – Software version information...
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.
