INSTRUCTION MANUAL
COUNTERTOP PRESSURE STEAM STERILIZER
MODEL: LFSS03AA (LCD)
IMPORTER AND AUTHORIZED SERVICE POINT IN POLAND
ACTIV TOMASZ PACHOLCZYK
8B Graniczna St., Building DC2A
54-610 Wroclaw, Poland
www.activeshop.com.pl
Warning: The device should only be operated by qualified personnel who have the knowledge
and proper training to operate this type of equipment. A suitable person should be designated
to operate and maintain the device.
V1.0
AUTOCLAW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LFSS03AA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LAFOMED LFSS03AA

Summary of Contents for LAFOMED LFSS03AA

  • Page 1 INSTRUCTION MANUAL V1.0 COUNTERTOP PRESSURE STEAM STERILIZER AUTOCLAW MODEL: LFSS03AA (LCD) IMPORTER AND AUTHORIZED SERVICE POINT IN POLAND ACTIV TOMASZ PACHOLCZYK 8B Graniczna St., Building DC2A 54-610 Wroclaw, Poland www.activeshop.com.pl Warning: The device should only be operated by qualified personnel who have the knowledge and proper training to operate this type of equipment.

  • Page 3: Table Of Contents

    7.6. Closing the door ......................................20 7.7. Program selection ....................................20 7.8. Launching the program...................................21 7.9. Interruption of the program by the user ...............................21 7.10. Opening the door and unloading the chamber ...........................21 AUTOCLAVE LFSS03AA S t r o n g (LCD)
  • Page 4 Appendix 1 Items and results of inspections ..............................30 Appendix 2 Explanation of each step in the process ...........................30 Attachment No. 3 Sample printout of the result of the completed program .....................31 CONTACT DETAILS ................................32 AUTOCLAVE LFSS03AA S t r o n g (LCD)

  • Page 5: Scope Of The Instruction

    These instructions apply to table top (countertop) pressure steam sterilizers manufactured by Ningbo Haishu Life Medical Technology Co., Ltd. Model: LFSS03AA (LCD). Before using the device, read this manual carefully to ensure safe operation of the device and its operator.

  • Page 6: Description Of Symbols

    Do not turn. Do not move by rolling (do not roll). Permissible number of stacking layers. Range of storage heights (stacked maximum 3). Acceptable temperature range: +5°C ~ +40°C. Humidity range (relative humidity ≤ 80%). Store in a dry place. AUTOCLAVE LFSS03AA S t r o n g (LCD)

  • Page 7: Warnings And Important Safety Information

    DANGER Do not block or cover the autoclave door, ventilation and heat dissipation openings. CAUTION Do not remove the nameplate, any labels, warning and information stickers From the device. CAUTION AUTOCLAVE LFSS03AA S t r o n g (LCD)

  • Page 8: Brief Introduction

    The saturated steam temperature is between 121°C and 124°C, and the temperature difference between different points in the sterilization chamber, at the same time, does not exceed 2°C, and the holding time is 20 minutes. AUTOCLAVE LFSS03AA S t r o n g...

  • Page 9: Construction Of The Device - General View

    SPECIFICATION 2.1. Chamber specifications Dimensions of available space: Model: Dimensions (nominal diameter x depth mm) LFSS03AA (LCD) Dep. = 175, H = 55, W = 280 Available space 2.2. Chamber parameters Design pressure: -0.1 / 0.27 MPa Design temperature: 140°C...

  • Page 10: Device Parameters

    To ensure the safe and reliable operation of the device, check that the following requirements are met, as specified below: 3.2.1. Power supply requirements: Single-ended (DC) 220V - 240V, 50 Hz, 2900W power supply. AUTOCLAVE LFSS03AA 10 | S t r o n g...

  • Page 11: Handling Of The Packaged Device

    When lifting or transferring by hand, use extreme caution to avoid danger. DANGER 3.4. Unpacking Cut the packing tape, if used with knives or scissors. Then open the closures and remove the packaging lid, and finally remove the protective film. AUTOCLAVE LFSS03AA 11 | S t r o n g (LCD)

  • Page 12: Positioning The Device On The Mounting Surface

    (error code: E10, E11) or other problems may occur. The way to regulate atmospheric pressure: Open the door, turn off the power, wait about 20 seconds, turn on the power and wait 1 minute. AUTOCLAVE LFSS03AA 12 | S t r o n g...

  • Page 13: Date And Time Setting

    121°C Universal were initially (121°C Universal) set up B&D/Helix Test Test program Vacuum Test Vacuum: -80 kPa, holding time: 15 min Test program The parameters Dry (Drying) have been preset AUTOCLAVE LFSS03AA 13 | S t r o n g (LCD)

  • Page 14: Sterilization Load Types For Each Program

    Maximum load weight - solid batches Maximum load weight - batches Model (instruments/tools) porous (fabrics) LFSS03AA (LCD) 2.2 kg 0.5 kg individually wrapped 5.3. Maximum operating time and maximum water consumption Maximum operating time, maximum water consumption for each program at maximum load:...
  • Page 15 : Cursor Press the "Up Arrow" or "Down Arrow" button to move the cursor to the desired program, and then press the "OK" button to start the selected program. AUTOCLAVE LFSS03AA 15 | S t r o n g (LCD)
  • Page 16 If the cursor is at the height of this option, press the "OK" button to set the appropriate temperature display unit. You can set the temperature expressed in degrees Celsius (°C) or degrees Fahrenheit (°F). AUTOCLAVE LFSS03AA 16 | S t r o n g...
  • Page 17 - After setting the password, press "OK" to confirm; - Move the cursor to the " Enable" position ("Enable") and press "OK" to set ON/OFF or OFF/OFF password. AUTOCLAVE LFSS03AA 17 | S t r o n g (LCD)
  • Page 18 Open door, wait until to cool the chamber to the right temperature, this may take about 5 - 7 the chamber has cooled down and minutes. try to again. AUTOCLAVE LFSS03AA 18 | S t r o n g (LCD)

  • Page 19: Preparation For Use

    Use a handle/grip to place the load to avoid the risk of burns caused by touching the chamber. Do not touch any wall of the sterilization chamber to avoid the risk of burns. WARNING AUTOCLAVE LFSS03AA 19 | S t r o n g...

  • Page 20: Closing The Door

    Autoclave cannot be used to sterilize liquids or liquids in closed vessels (especially glassware), as this leads to the bursting of these vessels, t h u s endangering the safety of people and equipment. DANGER AUTOCLAVE LFSS03AA 20 | S t r o n g (LCD)

  • Page 21: Launching The Program

    Too much data stored on the SD card, will fill up the entire card, and once the card is full, older records will be automatically overwritten with new ones. AUTOCLAVE LFSS03AA 21 | S t r o n g...

  • Page 22: Emergency Door Opening

    The temperature of the ring temperature sensor. temperature sensor. heating jacket is ≤ 0°C. 2. Ambient temperature 2. Check the temperature is too low. In the room whether it is < 0°C. AUTOCLAVE LFSS03AA 22 | S t r o n g (LCD)
  • Page 23 121°C program: 3. Check the water pump pressure < 200 kPa. and inlet solenoid valve. Unlocked door during Check the door solenoid Defective door lock. cycle launched. and control board. AUTOCLAVE LFSS03AA 23 | S t r o n g (LCD)

  • Page 24: Conservation

    You can check whether the Inspection of the safety valve valve is working properly. 1 time every six See 9.3.6 protecting the chamber Absolutely do not do this months while cycle launched. AUTOCLAVE LFSS03AA 24 | S t r o n g (LCD)

  • Page 25: Detailed Information

    There is a drain filter at the front of the sterilization chamber: 1. Turn clockwise to remove the filter from the chamber. 2. Unscrew the inner pressure ring of the filter. 3. Clean the 2 internal filter elements. AUTOCLAVE LFSS03AA 25 | S t r o n g (LCD)
  • Page 26 Absolutely do not do this directly with your hand. The operator must stand as far back as possible and always wear special insulated protective gloves, WARNING To avoid the risk of getting burned. AUTOCLAVE LFSS03AA 26 | S t r o n g (LCD)
  • Page 27 If an external waste water tank is used, check every day before starting work, Whether it is not full or close to full. If it is filled, at least half full, empty the tank. AUTOCLAVE LFSS03AA 27 | S t r o n g...

  • Page 28: Service And Warranty Terms And Conditions

    The warranty is void, even during the warranty period in the following cases: - Damage or defects caused by improper installation and operation, - damage or malfunctions caused by damage to the device, such as from a fall or impact, AUTOCLAVE LFSS03AA 28 | S t r o n g...

  • Page 29: Accessories

    Handle (handle) for removing trays from the chamber to avoid the trays. risk of burning yourself. Cable/hose drain It is used to drain water. (2 pcs.) Power cord (1 piece). AUTOCLAVE LFSS03AA 29 | S t r o n g (LCD)

  • Page 30: Announcements

    Vacuum drying. Air is drawn inside the sterilization chamber through a bacteriological filter to equalize the equilibrium pressure in the chamber to atmospheric pressure. Termination of the running program. AUTOCLAVE LFSS03AA 30 | S t r o n g (LCD)

  • Page 31: Attachment No. 3 Sample Printout Of The Result Of The Completed Program

    STERILIZATION TEMP: MIN START MAX. TEMP: MAX TEMPERATURE MIN. PRESS: MIN TEMPERATURE MAX. PRESS: PRESSURE RUDDER-END MIN. PRESSURE END DRY-END OF STERILIZATION CYCLE COMPLETE END OF DRYING COMPLETE CYCLE AUTOCLAVE LFSS03AA 31 | S t r o n g (LCD)

  • Page 32: Contact Details

    IMPORTER AND AUTHORIZED SERVICE POINT IN POLAND ACTIV Tomasz Pacholczyk 8B Graniczna St., Building DC2A 54-610 Wroclaw, Poland www.activeshop.com.pl Number and date of issuance of instructions: GC-JS-22 01/00 2020-07-22 GB | 09.11.2020 EN AUTOCLAVE LFSS03AA 32 | S t r o n g (LCD)
