Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfi l your needs for many years
to come. Scandinavian design combines clean lines, everyday functionality
and high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To ensure that you get the most out of your new machine, we recommend
that you read the operating instructions before using the machine. The
operating instructions also contain information on how to avoid damaging
the environment.
Operating Instructions
Tumble dryer
ASKO T794CW
WARNING: Read the instructions before using the machine.
Advertisement
Table of Contents
Related Manuals for Asko T794CW
Summary of Contents for Asko T794CW
- Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfi l your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
-
Page 2: Table Of Contents
Contents Before using your machine for the How to choose the settings fi rst time Clock Language selection Audible Volume Safety instructions Language Child-safe Safety Return Installation Transport/Winter storage Care and cleaning Packing material Cleaning the lint fi lter Recycling Emptying the condensed water container 16 Child safety Cleaning the outside of the machine... -
Page 3: Before Using Your Machine For The Fi Rst Time
Before using your machine for the fi rst time Language selection You will be prompted to select the display language when you have connected your machine and start it for the fi rst time. Do as follows: 1. Turn the programme selector to choose from: US English, English, Svenska, Dansk, Norsk, Suomi, Français, Deutsch, Italiano, Espanol, Русский, Nederlands. -
Page 4: Safety Instructions
Safety instructions Read the operating instructions and Safety keep them in a safe place! • The machine must not be used for drying items that have been dry-cleaned at home or fabrics that may contain residues of fl ammable liquids. •... -
Page 5: Do Not Allow Children To Play With The Tumble Dryer
Child safety General Child-safe start By activating the child-safe start function you WARNING! can prevent children from starting the tumble dryer or changing the current programme. Do not allow children to play with the 1. Turn the programme selector until Settings is tumble dryer. -
Page 6: Description Of The Tumble Dryer
Description of the tumble dryer Main power switch Lint fi lter Condensed water container Outer door Panel Condenser Type plate... -
Page 7: Advice And Tips Before You Tumble-Dry
Advice and tips before you tumble-dry Static electricity Here are some tips that may help you before you begin tumble-drying. To reduce the risk of static electricity in the laundry after tumble drying you can: Have the clothes been spun? •... -
Page 8: Tumble Drying
Tumble drying Below are step-by-step instructions to help you achieve the best possible tumble-drying results. Sort your fabrics You will achieve the most uniform drying results if the items are made of the same type of material. Do up zips and buttons, fasten belts, sort the items and adjust the load and temperature. -
Page 9: Select The Programme
Tumble drying Select the programme Programme selector Display window Start Stop Main power switch Select a programme by turning the programme selector. The name of the selected programme and the programme time are shown in the display window. Press the button in the middle of the programme selector if you want to select any options. - Page 10 Tumble drying NOTE! When using the Timed dry programme with a programme time that is too long, the garments can become "over-dry". This can cause items to shrink or crease and feel rough to the touch. Synthetic materials can also become charged with static electricity.
- Page 11 Tumble drying Programme chart Here we present the energy and time consumption of a few diff erent programmes. The table shows the eff ect of using diff erent spin speeds when washing the load. Consumption can vary depending on room temperature, humidity, load, variations in the power supply and selected options. For the consumption values given below, the requirements are as follows: Temperature of intake air: 23 °C...
-
Page 12: Selecting Options
Tumble drying Selecting Options By selecting options, you can tailor Anti crease a drying programme to suit your This is a useful feature if you cannot take the requirements. The available options depend washing out as soon as the tumble dryer has on the selected programme. -
Page 13: Press The Start Button
Tumble drying Press the Start button. Remaining drying time TIP! An estimate of the remaining drying time will be shown on the display a few minutes after The condensed water is decalcifi ed and can the drying programme starts. 1:35 means that be used in steam irons. -
Page 14: Settings
Settings You can carry out the following Audible Volume settings You can choose to have the machine notify you • Clock when a programme is fi nished or when a fault • Audible Volume has occurred. • Language 1. Press the programme selector again to •... -
Page 15: Care And Cleaning
Care and cleaning Cleaning the lint fi lter 3. Open the inner fi lter as shown in the fi gure. The lint fi lter must be cleaned after each load. 1. Lift the fi lter from the holder in the door. 4. -
Page 16: Emptying The Condensed Water Container
Care and cleaning Emptying the condensed water container If you have not connected the machine to a separate drain the condensed water container must be emptied after each load. Remove the condensed water container, empty out the water and replace the container. If the condensed water container becomes full to overfl... -
Page 17: Cleaning The Condenser
Care and cleaning Cleaning the condenser The condenser should be cleaned at least three NOTE! times a year. If you have pets, the condenser must be cleaned more frequently. Do not clean the condenser in a dishwasher. 1. Turn off the tumble dryer with the main power 5. - Page 18 Care and cleaning Cleaning the outside of the machine NOTE! Clean the outside of the machine and the programme panel with a mild cleaner. Do The dryer should never be operated without not use solvents, as these can damage the the fi...
-
Page 19: Troubleshooting
Troubleshooting The machine will not start Drying takes too long Check • Check that the lint fi lter is not blocked. See • that the door is properly closed. the Care and cleaning chapter. • that the main power switch is on. •... -
Page 20: Technical Information
Technical information Technical data Height: 845 mm Width: 595 mm Depth: 585 mm Weight (net): 44 kg Cylinder volume: 112 l Max. drying capacity: 7 kg Speed: 50-55 rpm Rated power: See type plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel. -
Page 21: Service
Service Before contacting the service division See the Troubleshooting and Care and cleaning chapters to see whether you can rectify the problem. If you need to contact the service division, make sure that you know the model designation, type designation and serial number. The model designation (1) can be found on the fi... -
Page 22: Installation
Stacking The tumble dryer can be placed on top of a ASKO washing machine. Use the two foot cups found in the document bag included with the machine and the two tip guards attached to the bottom left corner of the back of the machine. -
Page 23: Adjusting The Feet
Installation 4. Attach the plastic cups for fi xing the tumble 7. Lower the tumble dryer’s front feet into the dryer’s front feet to the washing machine’s plastic cups and adjust the tumble dryer to top cover. This is essential, as only when ensure it is level. -
Page 24: Condensed Water
Installation Condensed water Installation The machine is supplied as shown in Option 1 See the separate installation instructions (inset). This means that the condensed water included in the set of documents. is pumped into the condensed water container, Electrical installation which must be removed and emptied by hand. -
Page 25: Door Hanging
Door hanging 1. Hinge pins (top and bottom) 4. Locking hook 2. Cover plate 5. Hinges (left + right side) 3. Plastic plugs (on the upper and lower edges) 6. Plinth... -
Page 26: Follow These Instructions
Door hanging You can choose whether the door is hung on the right or the left. NOTE! Follow these instructions: Be careful not to damage the appliance with the 1. Remove the plinth. screwdriver. 2. Remove the hinge, two screws. 6. -
Page 27: Your Notes
Your notes... -
Page 28: Quick Guide
Clean the lint fi lter after each load. Empty the condensed water container. Turn off the main power switch. Close the door. We reserve the right to make changes. Gorenje, Partizanska 12, 3320 Velenje, Slovenija www.asko.com TD70.3 SPK T794CW en (11-16)
