INSTRUCTION MANUAL
SPECIFICATIONS
Model
Diameter
Capacity
PACKING LIST
Components
Movable Pedal (4)
Accessories
Multipurpose Wrenches (2)
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
V. 2024.02.28
2.5-INCH RETRACTABLE
WORKBENCH CASTERS (4-PACK)
CA2580
2.5 Inches
Combined: 600 Pounds (Evenly Distributed)
Individual: 150 Pounds
Casters (4)
Leg Mounting Plate (4)
Hardware
M6x52 Hex Bolt (4)
M6x46 Hex Bolt (4)
NEED HELP? CONTACT US!
TECHSUPPORT@WENPRODUCTS.COM
MODEL CA2580
Wheel Mounting Plate (4)
M12 Hex Nut (4)
M6 Hex Nut (8)
M5x25 Screw (24)
Advertisement
Related Manuals for Wen CA2580
Summary of Contents for Wen CA2580
- Page 1 INSTRUCTION MANUAL MODEL CA2580 2.5-INCH RETRACTABLE WORKBENCH CASTERS (4-PACK) SPECIFICATIONS Model CA2580 Diameter 2.5 Inches Combined: 600 Pounds (Evenly Distributed) Capacity Individual: 150 Pounds PACKING LIST Components THANKS FOR REMEMBERING Movable Pedal (4) Casters (4) Leg Mounting Plate (4) Wheel Mounting Plate (4)
