Page 1
IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
TABLE OF CONTENTS Technical Data Rules for Safe Operation Assembly Exploded View Warranty TECHNICAL DATA Model Number: 73017 Maximum Capacity: 1500 pounds per dolly Casters: 2.5 in.
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFE- TY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not use your item until the following steps have been read and understood. These safety rules cannot address every possible scenario you may encounter, so please use common sense and caution when using the item.
VEHICLE DOLLY WARNINGS 1. Do not exceed the rated capacity. Use only on hard level surfaces. Before moving a load, assure that the load is centered and secured with a load restraint device. 2. Before each use, check the vehicle dollies for loose hardware, cracks, damaged parts and any other conditions that may affect the safety of the product.
3. To move a vehicle supported by four dollies, remove the wheel chocks, unlock the casters and use the handles to slide the vehicle into place. 5. Once the vehicle is in place, lock the casters. EXPLODED VIEW AND PARTS LIST PART DESCRIPTION QUANTITY 73017-01 Frame with Handle 73017-02 Caster with Brake 73017-03 Caster w/o Brake...
LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
