JLG T500J BUCKET LIFT OPERATING INSTRUCTIONS &
Quick Start Guide
The ground control station and platform control station emergency stop buttons
(RED) must be set to "ON" in order to operate this machine. The unlock toggle
must be held down in order to operate any controls. Be sure to push the brake
handle on the tow bar DOWN to ensure the brakes are active. UNIT MUST BE
DISCONNECTED FROM VEHICLE BEFORE OPERATION.
1.
Operating from Ground Controls
- Outrigger Control – At the ground control station, turn the key to the
color that coordinates with the ground control on the diagram. To
lower the outriggers, hold the unlock toggle while pressing down on
the outrigger toggle. The outriggers will all come down and self-level.
Wait for all 4 of the green lights next to the toggle to illuminate.
That will assure that the unit is level.
To raise the outriggers, hold the unlock toggle while pressing up on
the outrigger toggle.
Boom Controls from ground control – This lift has many directions
of operation. It features a diagram labeled press and hold the unlock
toggle, while simultaneously holding the toggle that corresponds
with the diagram
2. Operating from Platform Controls
- Switching to Platform Controls – At the ground control station, turn
the key to the color that coordinates with the platform control on the
diagram
