Advantech MIC-75S00 Startup Manual

MIC-75S00
Dual Front Accessible 2.5" SATA Storage Bay for
MIC-7 Series Embedded System
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. MIC-75S00 Module x1
2. MIC-75S00 Startup Manual x1
3. M3 x 4L Screws x 4
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-75S00 Series Rev. A1.
Part No. 204175S000
Printed in China
P/N: 204175S000
P/N: 1930007979
1st Edition
December 2022
Specifications
Storage
• Internal SATA connector: 2
Note 1:
MIC-75S00 supports 2 x 2.5' HDD space and
both SATA signals are from main system.
Note 2: MIC-75S00 supports thickness of 2.5" HDD/SSD
up to 15mm.
Environment
• Operating Temperature:
-20 ~ 60° C with 0.7 m/sec air flow: with 1 x Industrial SSD
0 ~ 45° C with 0.7 m/sec air flow: with 1 x 2.5" HDD
• Storage Temperature: - 40 ~ 85° C (-40 ~185° F)
• Relative Humidity: 95% @ 40° C (non-condensing)
Mechanical
• Dimensions (H x W x D): 192 x 31(min.)/69.15(max.) x
230
