Page 3
Install the side panels Insert the bottom support beams ③ into the side panels ① and ②. BEFORE ASSEMBLY THIS PRODUCT, PLEASE READ THIS INSTRUCTIONS CAREFULLY. Rear side, connecting the back panel. M4*8 Screws x10 Divider Snap x8 Handle x1 φ4*20 Handle fixing screw x1 Note the orientation of the bottom support ×...
Page 4
Install the back panel Fix the cabinet with screws ④ Install the top panel Insert Slide in ⑤...
Page 5
Secure the cabinet to the wall Place the divider snap First, mark the locations of the back panel's pre-drilled holes on the wall. Use your own electric Attach the 8 divider snaps (b) to the 4 legs. drill to drill holes at the marked spots, then insert expansion tubes into the drilled holes. Place the bottom shelves ⑥...
Install the magnetic strips Install the door Attach the magnetic strips (f) to the door (⑦, both top and bottom) between the two holes. Insert Fix the bottom of the door with the door spindle and washer (e) in the bottom crossbeam with the raised ends of the silicone pads (g) into the holes to cover the magnetic strips.
