User Manual
GETTING
STARTED?
EASY.
ZCG912A6XA
EN User Manual
Cooker
EG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZCG912A6XA and is the answer not in the manual?

Questions and answers

Related Manuals for Zanussi ZCG912A6XA

Summary of Contents for Zanussi ZCG912A6XA

  • Page 1 User Manual GETTING STARTED? EASY. ZCG912A6XA EN User Manual Cooker...

  • Page 2: Safety Information

    VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage.
  • Page 3 This appliance is intended for use up to an altitude of 2000 m • above sea level. This appliance is not intended to be used on a ships, boats or • vessels. Do not install the appliance behind a decorative door in order •...

  • Page 4: Safety Instructions

    WARNING: Use only hob guards designed by the • manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents. SAFETY INSTRUCTIONS •...

  • Page 5: Care And Cleaning

    • Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent. WARNING! Risk of injury and burns. • Do not keep hot cookware on the control panel. Risk of electrical shock. • Do not let cookware boil dry. •...

  • Page 6: Internal Lighting

    • Use only lamps with the same specifications. • Do not change the specification of the lid. GAS GRILL • Clean the lid regularly. • Do not open the lid, when there are spills on the WARNING! Risk of fire, explosion and surface.

  • Page 7: Before First Use

    COOKING SURFACE LAYOUT Auxiliary burner Semi-rapid burner Semi-rapid burner Triple Crown burner Rapid burner ACCESSORIES For cakes and biscuits. • Turnspit • Wire shelf For roasting larger joints of meat and poultry. For cookware, cake tins, roasts. • Baking tray BEFORE FIRST USE 1.

  • Page 8: Burner Overview

    BURNER OVERVIEW WARNING! Be very careful when you use open fire in the kitchen environment. The manufacturer declines any responsibility in case of the flame misuse. The spark generator can start automatically when you switch on the mains, after installation or a power cut. It is normal.

  • Page 9: Hob - Care And Cleaning

    WARNING! Do not put unstable or Diameter of cookware damaged pots on the burner to Burner (mm) prevent spills and injuries. CAUTION! Make sure that pot Triple Crown 160 - 260 handles are not above the front edge of the cooktop. Rapid 160 - 240 Semi-rapid...

  • Page 10: Oven - Daily Use

    OVEN - DAILY USE WARNING! Refer to Safety chapters. OVEN FUNCTIONS Oven function Application Off position The oven is off. Grilling To grill flat food in the middle of the grill. To make toast. Oven lamp To illuminate the oven interior. To use this function, press the button for the lamp and turnspit.

  • Page 11: Oven - Clock Functions

    Control the flame trough the holes in the bottom of CAUTION! Make sure to turn the knob the oven. for the oven funstions as far as it goes. Avoid the intermediary position USING THE GRILL KNOB between Off and Grill. On the To set the length of flame that you want, turn the intermediary positions the spark knob for the oven to one of the flame positions.
  • Page 12 A. Support hook Put the shelf on the correct shelf position. Make B. Forks sure it does not touch the back wall of the oven. C. Spit WARNING! The maximum weight D. Handle permitted on the oven shelf is 24 kg. The support hook is installed in the top Avoid putting heavier food on the of the oven cavity.

  • Page 13: Oven - Hints And Tips

    6. Use the screws to tighten the forks. 12. Make sure that turnspit rotates. 7. Put the tip of the spit into the turnspit hole. 13. Close the oven door. Refer to "Product description" chapter. The turnspit does not stop if you open the oven 8.
  • Page 14 Casseroles Preheating Food Quantity (kg) Knob position Time (min) Shelf position time (min) Lasagna 1.5 - 2.5 40 - 50 Cannelloni 1.5 - 2.5 30 - 40 Potato gratin 1.5 - 2.5 85 - 95 Macaroni oven 1.5 - 2.5 40 - 50 Kebab Hala 1.5 - 2.5...

  • Page 15: Oven - Care And Cleaning

    Preheating Food Quantity (kg) Knob position Time (min) Shelf position time (min) Calzone 1.4 - 1.5 35 - 40 Cakes Preheating Food Quantity (kg) Knob position Time (min) Shelf position time (min) Biscuits 0.3 - 0.5 10 - 15 Flat cake 0.6 - 1.0 25 - 35 Orange cake...

  • Page 16: Cleaning The Oven Door

    Clean the oven interior after each use. Fat accumulation or other food remains may result in a fire. Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a cleaning agent. Do not clean the accessories in the dishwasher.
  • Page 17 When the cleaning is completed, install the glass panels and the oven door. To install the oven door, do the above steps in the opposite sequence. 4. Put the door on a soft cloth on a stable surface. 5. Use a screwdriver to remove the 3 screws from the bottom edge of the door.

  • Page 18: Replacing The Lamp

    REPLACING THE LAMP WARNING! Risk of electric shock. The lamp can be hot. 1. Turn off the oven. Wait until the oven is cooled down. 2. Disconnect the oven from the mains. 3. Put a cloth on the bottom of the cavity. The back lamp 1.

  • Page 19: Service Data

    Problem Possible cause Remedy The flame colour is orange or The flame can look orange or yellow. yellow in some areas of the burner. This is normal. The lamp does not operate. The lamp is defective. Replace the lamp. Steam and condensation settle You left the dish in the oven for Do not leave the dishes in the on the food and in the cavity of...
  • Page 20 Minimum distances Frequency 50 - 60 Hz Appliance class Dimension Dimension Height 850 - 870 Width Depth TECHNICAL DATA Voltage 220 - 240 V OTHER TECHNICAL DATA Appliance category: II2H3B/P Gas original: G30 (3B/P) 28-30 mbar Gas replacement: G20 (2H) 20 mbar BYPASS DIAMETERS BURNER Ø...
  • Page 21 GAS BURNERS FOR LPG G30 28-30 mbar NORMAL POW- REDUCED POWER INJECTOR MARK BURNER GAS RATE g/h ER kW 1/100 mm Triple Crown 290.9 101o Rapid 218.1 Semi-rapid 138.2 0.43 Auxiliary 0.95 69.1 0.35 Oven 283.6 Grill 218.1 GAS CONNECTION FLEXIBLE NONMETAL PIPES CONNECTION If you have an easy access to the connection, you WARNING! Before you connect the...
  • Page 22 You can find this plate in the bag WARNING! Before you replace the supplied with the appliance. injectors, make sure that the gas If the supply gas pressure is not constant or it is knobs are in the Off position. different from the necessary pressure, install an Disconnect the appliance from the applicable pressure adjuster on the gas supply...
  • Page 23 2. Carefully remove from the burner the Assemble the burner in a revers sequence. thermocouple A. Next remove the spark plug B. Replace the gas type sticker near the gas supply ramp with the one related to the new gas type. ADJUSTING THE MINIMUM GAS LEVEL ON THE OVEN BURNER 1.
  • Page 24 6. Remove the knob for the oven functions again. CAUTION! The assembly should be 7. Screw on slowly the bypass screw till the flame made by two people. becomes minimum and stable. 8. Put the knob for the oven functions back. 1.

  • Page 25: Electrical Installation

    To install all the accessories, do the first step in the opposite sequence. 5. Tilt the cooker forward 30 degrees and repeat the previous step for the back feet. ELECTRICAL INSTALLATION WARNING! The manufacturer is not responsible if you do not follow the safety precautions from Safety chapters.
  • Page 28 WWW.ZANUSSI.COM/SHOP...
