- Page 1 HD-01e High Definition Easy Scope Easy SKIN & HAIR ANALYSER USER’S MANUAL Version 4, June of 2024...
- Page 2 Class) Easy Scope with multi-applications. We believe the versatility and ease of use of this product will lead you to obtain more success in business deals and create more profit for you. HD-01e is with high resolution images for 640x480 VGA mode. This High...
-
Page 3: Standard Accessories
1. ACCESSORIES 1-1 Standard accessories: ITEM DESCRIPTION HD-01e High definition UVC (USB Video Class) Easy Scope (Handy probe type) * 640x480 VGA mode EVA Probe stand USB cable (extending from handy probe, USB plug & play) 2 image programs for free: a. -
Page 4: System Diagram
2. SYSTEM DIAGRAM USB cable, to computer Freeze button Probe stand... - Page 5 3. ATTACHING LENS TO HANDY PROBE 3-1 ATTACHING LENS TO HANDY PROBE (1) Take off the anti-dust cover of the handy probe. (2) Find the short post on the lens. Short post (3) Look at the front side of handy probe, you will find there’s a “︵” shape slot. “︵”...
- Page 6 Step 1 Step 2 Step 3 Step 4...
- Page 7 4. OPERATION OF OPTIONAL LENSES (1) 50x Polarized lens You can rotate the black rubber ring anti-clockwise to make surface skin inspection; rotate the black ring clockwise you can make deeper layer skin inspection. Polarized inspection Surface inspection (2) Normal 50x and 200x lens The lens has been well adjusted the focus.
- Page 8 (3) 1x focus adjustable lens (for styling purpose) The focus range for this lens is adjustable. You can rotate the black ring clockwise or anti-clockwise to get the right focus of full face/body, half body, or partial face). ＊This lens does not consist any inside LED lamp, therefore getting enough environmental outer light source is required.
- Page 9 (5) 50RN(UV) lens This lens is specially designed for ACNE inspection. It needs to be applied under ”HD-Pro Video Master” software. ＊ Under the UV light of 50RN(UV) lens, the acne will appear in fluorescent brown or red color. It is very useful in observation. (6) Iris lens (for iridology analysis) The focus range for this lens is adjustable.
- Page 10 (7) Microcirculation lens --- for observing the thickness, shape of the blood vessels, the speed of blood flow of the nail-tip. PATENTED anti-reflection bar (a) Suggested test part: left ring finger, see the picture for available area. Available test area (b) Operation method: Please apply penetrating oil (vegetable oil) on the test part in order to get clearer image.
- Page 11 320x Microcirculation Lens Application 1. Standard package (1) Finger supporter (Probe stand) 1 pc (2) 320x Microcirculation lens1 pc with PATENTED anti-reflection bar (3) Empty bottle 1 pc (Please add vegetable oil) (4) Slope plate to adjust finger height 4 pcs ※...
- Page 12 USB port: 3.0*1, 2.0*2 ＊Required OS: Windows 7, 8 & Windows 10 ＊Remark: HD-01e is with high resolution images for 640x480 VGA mode. 5-1 Power on your IBM compatible computer. Insert “HD-01e Easy Scope” CD-R into the CD-ROM drive.
- Page 13 5-3 The CD contents include： (1) “My Capture Pro. 1/2/4” ” program (Refer to instructions: P.13-17): This program assists you to make single / 2 splits (left & right) / 4 splits frame freeze & store function. Click “My Capture Pro. 1/2/4” Program, choose the language you need and “1-2-4 CAPTURE”...
- Page 14 HD-01e is with high resolution images for 640x480 VGA mode. Power on your computer & connect HD-01e well, and enter “1-2-4 CAPTURE” program, the default window is in 640x480 VGA (4:3 screen) mode. Please directly select the freeze function you need.
- Page 15 6-1 Operation procedures under 640 x 480 VGA (4:3) mode While operating Freeze or Release (Re-Capture) function, you can press “Frame Freeze” button on the handy probe or press “Freeze” in the program page. 6-1-1 Single frame freeze (4:3) Click “1 Frame” Entering live window.
- Page 16 6-1-2 2 Split frames freeze (4:3) 進入2-1影像Live視窗 Click “2 Splits”. Entering 2-1 live window. (Press “Re-Capt.”if you do not like Capture the image by pressing “Freeze” button. 2-1 captured image.) Then press “Confirm”. 2-1 freeze completed, press Entering 2-2 live window. “Capture”...
- Page 17 2-2 image capture completed. 2 split frames comparison, you can Press “Compare” to make 2 split press “Save” to save image (or “Re- frames comparison. Capt.” to continue new image capture). Find the folder you want to save, input file name and press “Save”.
- Page 18 (Press “Re-Capt.”if you do 4-2 freeze completed, then press Entering 4-3 live window. “Capture” to 4-3 image capture. not like 4-2 captured image.) Then press “Confirm”. (Press “Re-Capt.”if you do Capture the image by pressing 4-3 freeze completed, then press “Capture”...
- Page 19 7. “HD-01 Capture” Program application 7-1 HD-01 Capture operation (1) Fix the lens on handy probe, connect the USB to computer and turn on your computer. (2) Double click “HD-01 Capture” icon on computer desktop to enter the program. * If your OS is Windows 7, the icon name will be “Win 7 HD Capture”;...
- Page 20 (4) Color adjustment “HD-01 Capture” can offer color adjustment. If you want to adjust the color by yourself. click the icon from the upper left window, you can change the brightness, contrast, hue, saturation, etc. to your desirable value. Click “Apply” to get your desirable color image. If you want to change back to the original color setting, you can just click “Default”...
- Page 21 7-2 “HD-01 Capture” Operation / Application 7-2-1 Image Capture / save procedures (640 x 480 VGA mode) (1) Double click “HD-01 Capture” icon on computer desktop to enter the program. Press “Frame Freeze” button to capture the image from the live window. (2) Press again “Frame Freeze”...
- Page 22 7-2-2 Image comparison (1) In “HD-01 Capture” main window you can click icon to open a saved image to compare the new image you are going to capture. Find a saved image from the folder and press “Open”. Opened image Captured new image Opened image (2) Now the opened image appears on the right Data window.
-
Page 23: Troubleshooting
＊TROUBLE SHOOTING TROUBLE SHOOTING Check whether the computer is powered on. I have fixed the lens on HD-01e, but no function. The control box is 1). Check if the USB cable on handy probe is disconnected. powered on, but the handy probe doesn’t...
