AC Triac Dimmer (WiFi + 2.4G + Push)
Features
Uses WiFi + 2.4G + PUSH wireless transmission technology
●
Smartphone APP control
●
2.4G RF wireless remote control
●
Push dimming function
●
Trailing edge phase-cut technology
●
0~100% stepless dimming and icker free
●
Lowest brightness setting function
●
Built-in temperature detecting switch, over heart /loading
●
protection
Auto transmitting function, unlimited control distance
●
Screw connector is reliable and easy to do installation
●
Anti- re PC shell is more safety
●
Parameters
Name: AC Triac Dimmer
Model No.:
TRI-C1WR
Input Voltage:
100-240V~ 50/60Hz
Output:
100-240V~
Output Current:
Max 1.36A
Output Power:
150W @110V; 300W @220V
Protocol:
WiFi/ 2.4GHz RF
Control Distance:
2.4G: 30M
Model No.: TRI-C1WR
IP Rating:
Working Temperature:
EMC Standard (EMC):
Safety Standard (LVD):
Radio Equipment (RED):
Certi cation:
IP20
-10~40℃
ETSI EN 301 489-1 V2.2.3(2019-11)
ETSI EN 301 489-3 V2.3.2 (2023-01)
EN 61347-2-11: 2001+A1: 2019
EN 61347-1: 2015+A1:2021
EN 62493: 2015+A1:2022
ETSI EN 300 440 V2.2.1 (2018-07)
CE, EMC, LVD, RED
Advertisement
Related Manuals for Miboxer AC Triac Dimmer
Summary of Contents for Miboxer AC Triac Dimmer
- Page 1 AC Triac Dimmer (WiFi + 2.4G + Push) Model No.: TRI-C1WR Features Uses WiFi + 2.4G + PUSH wireless transmission technology ● Smartphone APP control ● 2.4G RF wireless remote control ● Push dimming function ● Trailing edge phase-cut technology ●...
-
Page 2: Connection Diagram
Connection Diagram Short press " Link" button 1 time for Output: 100-240V remote linking. Long press "Link" button 3 seconds for Triac dimming LED light WIFI pairing while indicator flashes quickly. Tradi�onal filament lamp Short press " Min. Set" button for mini brightness. - Page 3 Various control solu�on: Philips MiBoxer IKEA 2.4GHz Amazon Zigbee Gateway TRÅDFRI Remote Echo Plus Compa�ble with these 2.4G RF remote controls (Purchased separately) B1 / B1-B / T1 B2 / T2 K1 / K1-B WL-Box1 Auto transmi�ng (2.4G RF remote signal) can transmit remote signal to another automa�cally while...
- Page 4 2.4G RF Remote control instruc�on Linking Code Instruc�ons Triac Power Dimmer Triac Link / Unlink Power Dimmer bu�on Link Power off 10 seconds and Short press " I " bu�on Lights blink 3 �mes power on again or short 3 �mes within 3 seconds. slowly means linking press "Link"...
- Page 5 Smartphone app control instruc�on Network Configura�on (Don’t support 5G router) 1). Download and install [Tuya Smart] app Search for [Tuya Smart] in Apple or Google store or scan following QR code to download and install the app. Please open the app click " Register " bu�on to create account while using it in the first �me, Log in directly if you already had account.
- Page 6 App turn on and off “Do Not Disturb” mode (default ac�vated) Click the light which need to be set up or group control --- click “More” --- click “Power-on behavior” --- turn on or off 2 in 1 Controller 2 in 1 Controller...
- Page 7 Alexa voice control instruc�on Please add device into [Tuya Smart] app (check details in page 6), then start following steps 1). Open Alexa App 2). Click “More” on the bo�om of right corner 3). Click “Skills & Games” 4). Click “ ”...
- Page 8 Google Home voice control instruc�on Please add device into [Tuya Smart] app (check details in page 6), then start following steps 1). Open Google Home App 2). Click “+” on the top of le� corner 3). Click “Set up device” 4).
- Page 9 A�en�on 1. Please turn off power supply before installa�on. 2. Please ensure input voltage to be same as requirements from device. 3. Don’t disassemble device if you are not expert, otherwise it will damage it. 4. Please do not use the light in the place with widely range metal area or strong electromagne�c wave nearby, otherwise, the remote distance will be seriously affected.
