Miboxer TRI-C1 Manual

Ac triac rf+push dimmer
Hide thumbs

Advertisement

Quick Links

Download this manual
Subordinate New Brand
AC Triac RF+Push Dimmer
Model No.: TRI-C1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRI-C1 and is the answer not in the manual?

Questions and answers

Related Manuals for Miboxer TRI-C1

Summary of Contents for Miboxer TRI-C1

  • Page 1 Subordinate New Brand AC Triac RF+Push Dimmer Model No.: TRI-C1...
  • Page 2 1. Feature No need to change orignal electric circuit and install signal cable , low cost price, convenient to construct. Dim light through remote and Link code / Unlink code simply. Small and exquisite apperance which is easy to insert into EU and USA standard wire box.
  • Page 3 2. Parameters Model No.: TRI-C1 Input Voltage: AC100~240V 50/60Hz Output Voltage: AC100~240V Output Current: Max 1.36A Output Power: 150W @110V； 300W @220V Dim Method: RF wireless dimming, Push dimming Control Distance: 30m Working Temperature: -10~40℃ 25mm 49mm...

  • Page 4: Connection Diagram

    3. Connection Diagram Input: AC100~240V Push switch INPUT OUTPUT Triac dimming LED light Traditional filament lamp Halogen lamp Warning Please ensure all cable connected with right way before turn on power supply, otherwise it will damage the dimmer.

  • Page 5: Installation Diagram

    4. Installation Diagram Support following standard bottom case Botton case depth is Push switch over 50mm 5. Push Dimming Short press push switch: turn on or turn off light. Long press push switch: stepless dimming brightness. Long press / release and long press again to increase or decrease brightness.
  • Page 6 6. Link code K1 remote Link code 1. Enter into learning code mode. Solution1: short press "SET" button 1 time, the indicator is flashing explosively. Solution2: turn off the dimmer 10 seconds and turn on again. indicator light Solution3: short press push switch to lighting up mode.
  • Page 7 7. Unlink code Solution1: Long press "SET" button on dimmer 3 seconds untill the indicator is flashing quickly, Unlink code is done. Solution2: K1 remote Unlink code 1. Enter into learning code mode. 2. Press "SET" button on remote 5 times with 3 seconds, the light is flashing 10 times quickly, Unlink code is done.
  • Page 8 8. Compatible remote ( buy separately) WL-Box1 9. Set up min brightness This item should be paired with remote firstly before setting. Set up min brightness with K1 1. Long press "SET" button on remote 3 seconds untill the light is flashing one time and indicator of dimmer is going to flashing status.
  • Page 9 Setting up min brightness with other remote 1. Long press "off" button between remote and dimmer ( like: " " or " "） untill the light is flashing one time and indicator of dimmer is going into flashing status. 2. Short press " off " button between remote and dimmer ( like: "...
  • Page 10 11. Attention 1. Please turn off power while install device. 2. Kindly check input voltage before installation. 3. Don't disassemble device if you are not professtional user, otherwise it will damage device. 4. Don't use it near metal or magnetive area, otherwise it will affect control.
