PIP/PBP

1st Level Menu
OFF
PIP
PBP
2nd/3rd Level Menu
Source HDMI™ 1
HDMI™ 2
DP
Type C
PIP Size Small
Medium
Large
Location Left Top
Right Top
Left Bottom
Right
Bottom
Customize
Display Switch
Audio Switch
Mode 1
Mode 2
Customize
Source 1 HDMI™ 1
HDMI™ 2
DP
Type C
Source 2 HDMI™ 1
HDMI™ 2
DP
Type C
Display Switch
Audio Switch
Description
● PIP (Picture in Picture) allows users to
simultaneously display multiple video sources
on one screen. One program is displayed on the
full screen at the same time as one or more other
programs are displayed in inset windows.
● PBP (Picture by Picture) is a similar feature that
displays two input sources side-by-side on the
screen.
● Display Switch allows users to switch between
primary and secondary input sources.
● If there is only one signal input, the Display Switch
and Audio Switch will be grayed out.
● Users can adjust the ratio of window division by
switching Mode 1/ 2/ Customize.
● Activating PIP/PBP will affect:
Affected Function
» Adaptive-Sync
» Optix Scope
» HDMI™ CEC
» DisplayHDR
» HDMI™ 2.1
» DSC
» PIP: Screen Size 1:1
» PBP: Screen Size
» PIP: Screen Size 24.5" /
27"
17
Function Status
Set to OFF
Set to OFF &
unable to select
Unable to select
Set to Auto &
unable to select
Set to Auto
