- Page 1 Vacuum cleaner User manual SC18K51**** / SC21K51**** Series • Before operating this unit, please read the instructions carefully. • For indoor use only.
-
Page 2: Table Of Contents
Contents PREPARATION APPENDICES Safety information Notes and cautions Safety information In use Important safety instructions Cleaning and maintenance Troubleshooting INSTALLATION Name of the parts Accessories OPERATIONS Using the vacuum cleaner Using the body Using the handle control Using the brushes MAINTENANCE Cleaning and maintaining When to empty the dust bin... -
Page 3: Preparation
PREPARATION Safety information Safety information WARNING • Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • Because these following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual. -
Page 4: Important Safety Instructions
Important safety instructions When using an electrical appliance, basic precautions should be observed, including the following: WARNING This vacuum cleaner is designed for household use only. Do not use this vacuum cleaner to clean building waste and debris. Regularly keep the filters in clean conditions to prevent of collecting fine dust in them. - Page 5 • Avoid picking up hard, sharp objects with the vacuum cleaner as they may damage the cleaner parts. • Do not stand on the hose assembly. Do not put weight on the hose. • Do not block the suction or the exhaust port. •...
- Page 6 • Do not use to suck up water. • Do not immerse in water for cleaning. • The hose should be checked regularly and must not be used if damaged. • Please contact the manufacturer or service agent for a replacement. Power related •...
- Page 7 In use • Do not use this product outdoors since it’s designed for household use only. – There is a risk of malfunction or damage. ❇ ❇ Outdoor cleaning : A stone, Cement ❇ ❇ A billiard room : Powder of a chalk ❇...
- Page 8 • Do not use alkaline or industrial detergents, air fresheners or (acetic) acids to clean the washable parts of the vacuum cleaner. (Refer to the following table.) – It may cause damage, deformation or discoloration of the plastic parts. The washable parts Dust bin of the body, Dust filter, Sponge filter, Available detergent...
- Page 9 CAUTION In use • Do not use the pipe for anything other than its intended purpose. – It may result in injury or damage. • When you lift up the handle of dust bin while using the vacuum cleaner, safety device will be activated and there might be changes in operating noise.
-
Page 10: Installation
INSTALLATION Name of the parts 01 Pipe 06 Filter light 02 Handle control 07 Power button 03 Hose 08 Power cord 04 Dust bin 09 Outlet filter 05 Cord rewind button English... -
Page 11: Accessories
Accessories RF hose Pipe (Option) Pipe (Option) 2-step brush 2-step brush (SC18K51**** SERIES / Parquet master (Option) (SC07K51**** SERIES) SC21K51**** SERIES) Anit-Tangle tool/Mini Pet Power pet plus / Pet Care 3-in-1 accessory Care Tool (Option) Brush (Option) User manual English 11... -
Page 12: Operations
OPERATIONS Using the vacuum cleaner Using the body Using the handle control Power cord NOTE • For cleaning fabrics, push the button downward to reduce suction. On/Off 01 Power ON/OFF 02 Increasing suction power 03 Decreasing suction power Suction 01 Higher power 02 Lower power English... -
Page 13: Using The Brushes
Using the brushes ❼ ❽ ❻ ❶ ❷ ❸ ❶ ❷ ❹ ❺ Where to use the brushes ❶ 2-step brush ❷ 2-step brush ❸ Parquet master ❹ Anit-Tangle tool/ Mini Pet Care Floor ❇ ❇ Tool Carpet ❺ Power pet plus / ❻... -
Page 14: Maintenance
MAINTENANCE Cleaning and maintaining You must unplug the vacuum cleaner before cleaning it. When to empty the dust bin Click Cleaning the dust bin Clean the dust bin if there’s too much dust in the dust bin. ❇ ❇ Anti-Tangle Turbine(Cyclone Force) –... -
Page 15: Cleaning The Dust Filter
Cleaning the dust filter Cleaning the outlet filter If the filter check indicator turns red with the inlet floating 10 cm above flat floor, clean the dust filter. Click English 15... -
Page 16: Cleaning The Brush
Cleaning the brush Cleaning the pipe 2-step brush Cleaning the hose Cleaning method for the [2-step brush], [Anit-Tangle tool/Mini Pet Care Tool] and [Parquet master] is the same. Storing the vacuum cleaner Power pet plus / Pet Care Brush English... -
Page 17: Appendices
APPENDICES Notes and cautions In use NOTE • Safety device will cut off the power when the vacuum cleaner was on for more than 30 minutes without any button input. In this case, press the [Power] button on the body or unplug the power plug and then plug it again. -
Page 18: Cleaning And Maintenance
• To prevent floors from scratches, inspect condition of the brush and replace it if it is worn down. • Replacement filters are available at your local Samsung service agent. • Hold the power cord and then press the Cord rewind button since you can get injured if the power cord may lose control while rewinding it. -
Page 19: Troubleshooting
Troubleshooting Symptom Checklist • Check the cable, the power plug and outlet. Motor does not start. • Leave it to cool. • Check if there is any blockage, and remove it if required. Suction force is gradually • Please check the filters, and if required, clean as illustrated decreasing. - Page 20 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country / Customer Care Center Web Site Location 1300 362 603 (Other) AUSTRALIA www.samsung.com/au/support 1300 425 299 (HHP) www.samsung.com/hk/support (Chinese) HONG KONG 3698 4698 www.samsung.com/hk_en/support (English)
