- Page 1 CQSA-E2 1024 Ethernet to DMX Stand-Alone interface Datasheet & Quickstart Guide 1 ...
- Page 2 Technical Manual & Quick Start Guide Congratulations on your purchase of a CHROMATEQ controller. Please read this manual carefully and thoroughly before using the CQSA-E2 Chromateq. The information presented here provides a useful introduction to the wide range of features, settings and functions available in this compact and versatile CQSA-E2 The CQSA-E2 Technical Manual is written in English and French. (Le manuel technique du CQSA-E2 est rédigé en anglais et en français.) All products and software are developed and designed in France. CHROMATEQ SARL 191 Allée de Lauzard 34980 St Gély du Fesc FRANCE VAT: FR18521458034 Siret: 52145803400027 Web & E-mail: www.chromateq.com Phone: +33 952210755 / +86 13422062209 Whatsapp: +8613422062209 Wechat: Chromateq QQ: 2908265661 Twitter: https://twitter.com/Chromateq Facebook: https://www.facebook.com/ChromateqCompany/ YouTube: https://www.youtube.com/c/chromateq - - - - - - - - - - - - - - - - - - - - - - Copyright Information and Disclaimer Copyright © 2021 - CHROMATEQ.All rights reserved. No part of this publication may be reproduced, distributed or transmitted in any form or by any means whatsoever, including photocopying, recording or other electronic or mechanical methods, without the prior written permission of the publisher, except in the case of brief quotations in criticisms and certain other non-commercial uses permitted by copyright law. ...
-
Page 3: Table Of Contents
Table of Contents Introduction 5 Technical features 5 Device features 6 Software option 6 Buttons and connectivity 7 Front Panel 7 Left Panel 7 Right Panel 7 Rear Panel 7 Button operation and LED display menu 8 Main buttons 8 Mode selection button 8 Confirm Button 8 Next/Previous (Up/Down) +/- buttons 8 Blue LED buttons 8 Available Modes display and option descriptions 9 General modes 9 Advanced function mode. 9 Clock and calendar setting 10 Clock Calibration 10 ... - Page 4 External contacts Trigger: 26 Triggers by DMX-IN 27 Triggers via Wi-light 2 app and UDP commands 27 Time triggers 28 Single trigger 28 Permanent trigger 28 Light intensity trigger 29 Trigger priority with identical time 29 Advanced trigger options. 29 Restore after power off 30 Play in priority 30 Save in memory option 31 Basic backup 31 Save to an internal and external micro SD card 32 Backing up Art-Net or sACN to an external SD card 32 Standalone use 33 Switch to standalone mode 33 External and USB power supply 33 Charging the clock battery 33 Play a show via a Micro SD Card 33 ...
-
Page 5: Introduction
Introduction The CQSA-E2 is a versatile multifunction lighting control interface. ● Suitable for live applications and fixed installations ● Hardware compatibility with Player, Pro, Pixel Mapping and Studio DMX software ● Remote device configuration and lighting control when connected to an access point or Wifi router ● Playback over Ethernet without a computer when operating in Stand Alone mode ● SD card slot provides option to expand memory capacity ● Art-Net, sACN Playback on Ethernet ● DMX Splitter mode boosts reliability of DMX networks ● Wide choice of triggering methods ● Wi Light 2 app web remote compatible over Ethernet and Internet Objectives The purpose of this technical manual is to develop the options managed by the interface in standalone mode, for software options, please refer to the software manuals. Technical features Connectors USB 2.0 via USB-C, Ethernet and RJ45 x2 (External contact x7, Master/Slave, Infrared, Light Sensor, ) DMX lines Up to 2 x 512 channels (8 and 16-bit DMX channels) on 3 pin XLR (XLR5 optional) Internal memory yes, 8 MB (no SD card required) Internal memory capacity ... -
Page 6: Device Features
Temperature of use - 25 to +70 C° Certifications CE, RoHS International guarantee Yes, 5 years Compatibility of systems Windows (7 and higher), MAC OS X (10.13 and higher) and Linux (64 Bits, Debian, Redhat, Archlinux, Raspberry Pi) Device features 2x512 output, 1024 output or 512 output + 512 input (PC DMX 1024 and standalone mode, DMX recording, DMX IN trigger, DMX merge) Multiple zones 5 zones, plays up to 5 scenes simultaneously Combined areas yes Clock in real time - RTC Time and calendar triggering Smart contacts 7 (127 maximum) Master/Slave synchro Yes, 32 max per wiring / 128 max LAN RS232 Triggers Yes In/Out Infrared remote / Light sensor Optional (Requires the IR Kit) 15m. distance max. UDP Ethernet triggers and commands Software option Line DMX Art-Net Options Software ... -
Page 7: Buttons And Connectivity
Buttons and connectivity Front Panel 1. Mode selection (Trigger, Page, Colour, Speed, Dimmer, Zone, Function) 2. Confirm selection / Colour Off 3. Display: 7-segment LED display 4. Decrease values 5. Increase values 6. 8 Trigger Buttons : Scene 1 On/Off, Scene 2 On/Off, Scene 3 On/Off, Scene 4 On/Off, Scene 5 On/Off, Scene 6 On/Off, Scene 7 On/Off, Scene 8 On/Off Left Panel 1. USB-C port and power connector 5-24 V DC, 0.3 A Right Panel 1. Micro SD Port Rear Panel ... -
Page 8: Button Operation And Led Display Menu
2. RJ 45 connector TRIG 5 Volts out 1. - 7. Trig G - Trig A 8. 5V DC 3. XLR DMX Signal Connector A 1. Ground 2. Data - 3. Data + 4. XLR DMX Signal Connector B, 3 Pins. Can be set to Output mode (splitter or output) or Input mode (DMX In Triggers / Merge PC and Stand Alone). 1. Ground 2. Data - 3. Data + 5. Power supply 9V-24V DC input jack 6. RJ45 Ethernet port Network (LAN) connection Button operation and LED display menu Main buttons Mode selection button Press the button to select one of the available modes: Scene triggers (SA), Page (PA), Colour (Co), Speed (SP), Dimmer mode (dI) or zone selection (Zo). Press and hold for 4 seconds to enter the Advanced function mode. Confirm Button Press the button in SA, ArtNet, sACN, Node mode to display the current network mode (Static IP or DHCP). When navigating Mode menu, press to confirm values or to release the current colour selection. ... -
Page 9: Available Modes Display And Option Descriptions
Available Modes display and option descriptions Press the button to select General modes. Hold to select advanced function mode. General modes SA - Scene trigger mode : Select the scene using the + or – buttons, then press Confirm to play the selected scene (01 to 255). The scene number will flash several times to confirm your selection. Scene “00” indicates that no scene is playing. PA - Page Mode : Select page using the + or – buttons (P0 to P9), then choose an available scene in the selected page using the 8 trigger buttons. Then the number of the selected scene will be display on the LED display. Co - Colour mode : Using the 8 trigger buttons, select one of the 8 custom colours. Or, choose a colour from the colour wheel using the + or – buttons to select from 00 to 99. Press the Confirm button to turn off the current colour or to recall the last colour from the colour wheel. SP - Speed Mode : Increase or decrease the Speed of the current scene using the + or – buttons. Values range from -9 to +9. dl - Dimmer Mode : Increase or decrease the general intensity (dimmer and/or RGB channels) of scenes and colours with + or – buttons. Values range from -9 to +9. Zo - Zone Mode : Select the zone using the + or – buttons (Zone A ~ E and global Zone), then choose an available scene in the selected zone using the 8 trigger buttons or pages. Advanced function Mode: Scroll through the functions F1 to F6 using the + or – buttons and press Confirm to enter the function. Advanced function mode. Scroll through the functions F1 to F6 using the + or – buttons and press Confirm to access to several global interface settings. F1: Display the static IP of the interface. Press to scroll through the numbers. F2: Select DHCP (dh) or static IP (iP) mode. Press to switch the current mode. F3: Press to enter the mode. Use the + and - buttons to select the Stand Alone (SA), Art-Net (Ar), sACN (AC), Node Art Net (nA) or Node sACN (nS) mode. Press to confirm the selected mode. ... -
Page 10: Clock And Calendar Setting
Clock and calendar setting In Clock mode (advanced function menu F4) "YE" shows the current year setting. Use the + and - buttons to select the correct year and confirm by pressing the button. Repeat this procedure to set month (Mo), day (dA), hour (ho) and minutes (Mi). After confirming the minutes, “CL” will blink to confirm that the new configuration is saved to memory. The interface clock is now calibrated to your new setting. This function is useful for setting the interface clock directly on site and without the use of a computer. Clock Calibration After several weeks or months of use, you may notice the internal clock running slightly fast or slow. The standalone mode in the software includes a clock calibration setting. The internal clock may also be calibrated using the Device Tool program. Use the calibration setting to compensate for the clock’s timekeeping discrepancy by adding or subtracting milliseconds per day. (Cf: Clock tab) Display codes list The interface is powered On and is not running any show from memory. The interface is connected to a computer and communicating with the software. In this mode, the interface is under software control. The interface is in stand-alone and static IP mode. The default network address is 192.168.0.5. The interface is in stand-alone and DHCP mode. The network address is automatically defined by the router or the access point. Inserted SD card is properly detected and the interface is playing the show file from the Sd card. Scene trigger mode. In this mode, the LED display shows the current scene number (from 01 to 511). By default, when no scene is playing, all DMX channels are set to 0. “00” indicates Blackout and the interface sends nulls (0x00) on all DMX channels. Page mode. There are 10 pages of 8 scene, it is about 80 scenes maximum to be triggered. The display indicates the page number from P0 to P9. In this mode, use the 8 trigger buttons play the scenes stored in the selected page. Colour mode. The display indicates the selected custom colour number (from C1 to C8). Or the colour value applied from the colour wheel. 10 ... - Page 11 Speed mode. Increase or decrease the current scene speed. The display indicates the speed of the current scene from -9 to 9. Dimmer mode. Increase or decrease light output of scenes and custom colours. The display indicates the general intensity from -9 to 9. Programming memory Mode. Pr is displayed when the interface is writing a show to memory. Zone mode. After programming the interface memory, Zone A is selected by default. In this mode, the LED display shows the current Zone: Global, A, B, C, D, E. A current zone Global current zone - The display switches between the current zone and the running scene number every 3 seconds. Use + or – to navigate between zones. Scene buttons may be pressed to instantly trigger scenes without entering in the zone with the button. Functions 1 ~ 6 of the advanced function mode. Node Art-Net mode (Art-Net to DMX decoder for x2 Universes) Node sACN mode (sACN to DMX decoder for x2 Universes) Art-Net mode (Stand Alone, from SD card show file) sACN mode (Stand Alone) Year setting in the clock setting mode. Month setting in the clock setting mode. Day setting in the clock setting mode. Hour setting in the clock setting mode. Minute setting in the clock setting mode. Confirmation of the new clock setting. Updating firmware mode. Displayed when a new firmware is being written to memory. File Problem in the SD card: No show File save on the SD card or wrong File name (sdcardshowv2.sdq) or show file corrupted or empty SD Card detected or wrong memory format. 11 ...
-
Page 12: Usb Drivers Installation
USB drivers installation Install the USB drivers is necessary to communicate with the device and change settings. Installation of USB drivers is required only for Windows at the end of installation. Drivers for Mac and Linux systems are installed automatically. USB drivers verification : In the Windows Device Manager. Check that the device icon is visible in "USB Bus Controllers". If drivers are not installed, the Windows Device Manager lists a device with a yellow warning. On Mac OS, simply check the USB device tree to view "DMX 512 Stand Alone Device". On Linux, use the "lsusb" command to view "DMX 512 Stand Alone Device" in the list. After software installation and USB drivers ● Connect the device with the USB cable. ● Start the software or the DEVICETOOL and select "Open USB Device" or "USB" to check the success of drivers installation. All connected and detected devices are listed. Multiple USB connections 12 ... -
Page 13: Ethernet Connection And Configuration
Ethernet connection and configuration Establish Ethernet communication with the device to change its settings in the software options window or via the DEVICETOOL. It can be done in several ways: Live, via an IP Switch or a Wifi router. The device is in DHCP mode by default. Initial steps required ● Connect the device to the LAN or computer via an RJ45 Ethernet cable. ● Power the device via USB cable (5V DC, 0.3A). ● Connect the computer to the same network (LAN) or device via an RJ45 Ethernet cable. when the DHCP or static IP connection settings have been configured, they are stored in memory and used by default when the device is restarted after an update or when the device is in Bootloader mode. DHCP / IP Static In DHCP mode, without responses from a DHCP server after a short time, the device will use static IP mode with its default IP address and wait for the next DHCP request to use DHCP mode. It will therefore always be possible to connect directly to the computer in static IP MODE.The device is in DHCP mode by default. DHCP connection DHCP mode, allows you to communicate with devices through a DHCP server that automatically assigns and manages the IP addresses of each device.The DHCP server can be of Switch IP or Router type or other. The device is in DHCP mode by default. It is detected by software automatically when the computer is also connected in DHCP to the same network or with a static IP address of the same range. DHCP benefit is that the DHCP server automatically manages the IP addresses of connected devices. So it is not necessary to know exactly the IP of your device to connect to it.However, IPs are modified regularly and can make the installation less reliable. ... -
Page 14: Static Ip Connection
Static IP connection Static IP mode, allows you to communicate directly with a device without necessarily going through another device such as IP switch or router or access point. It is also used on LANs without DHCP server. Static IP mode also allows you to freeze a network configuration and provides better stability to installations designed with multiple devices thanks to an IP switch or routers. The default static values of the device are: IP address: 192.168.0.5 Subnet mask: 255.255.255.0 Setting up the Static IP connection ● After the required initial steps are completed. ● If the device is in Static IP mode. ● Set the IP address of the computer to an identical IP address range of type 192.168.0.x.With "x" different than 5 to avoid identical IP conflicts on the network. ● Also set the subnet mask to 255.255.255.0. ● Start the software or application. In an identical IP address range, the device will be recognized when software starts. Reset of the IP address If there is a default IP address not found, use the USB connection and software settings tools to check or change the device IP address. MAC address (Media Access Control) Fixed hexadecimal: 70.B3.D5.94.4X.XX For the last 3 characters, use Euclidean division. Divide the device serial number by 4096. Convert the remainder of the division into hexadecimal. Connecting to a wifi router ... - Page 15 Note: Connect multiple devices to the WiFi router or extend the available RJ45 ports with a Swich IP. Implementation of the WIFI network: ● Set up the WiFi router as a Hotspot to create a new access point. ● Or configure the WiFi router as “Bridge” or repeater to join an existing network. ● It is possible to configure the router in Static IP or DHCP. ● In DHP (default mode of a router) IP addresses are dynamically assigned on the network by the DHCP server. ● After configuring the router, connect the RJ45 ports and configure the device in DHCP or static IP mode. ● Once the device is connected to the router, it can be used and visible on the network. Check that the following ports are open: 8011 + 8012 + (30000 + device serial number) Server address: 217.160.187.41 15 ...
-
Page 16: Standalone Mode Settings
Standalone mode settings In standalone mode of the software, configure the device according to the available options then select and configure the scene triggers to be write in memory. Device configuration IN/OUT tab Select a DMX input/Output configuration of the device from the drop-down menu. Available configurations will be displayed depending on the connected device depending on whether it has 1.2 or 4 DMX lines. ● A OUT - Assigns 1 output universe on the DMX line(s), for devices that have more than 1 DMX lines duplicate the universe on each. ● AB OUT - Assigns 1 different output universe on 2 DMX lines, for devices that have 4 DMX lines duplicates the first 2 lines on the next 2 lines. ● A OUT/B or D IN - Assigns 1 output universe on the first line(s) and uses the last DMX line as DMX input. ● ABC OUT - Assigns 1 different universe output on the first 3 DMX lines. ● ABCD OUT - Assigns 1 different universe output on 4 DMX lines. ● AB OUT / D IN - Assigns 1 different output universe on the first 2 lines and uses the last DMX line as DMX input. ● ABC OUT / D IN - Assigns 1 different output universe on the first 3 lines and uses the last DMX line as DMX input. "Merge DMX In / DMX Out" option 16 ... -
Page 17: Art-Net/Sacn Universe Range
Available with devices with more than 2 or 4 DMX lines. Enable the option to re-inject line configured as an input (IN) to the line(s) configured in DMX outputs and thus merge them. The merged DMX levels are compared and the highest is retained. We are talking about HTP (Highest Takes Priority). Maintain manual control on some circuits with an external DMX console. Create a multi-zone system by merging several cascading devices to obtain only one common DMX line. Assign any universe of the software to any DMX line assigned to output, choosing line by line (U1, U2...). Optimize the size of shows saved in memory by reducing the number of circuits per universe depending on the channels used. Example: If 150 channels are used in the show, select only the nearest higher value, here 192. Art-Net/sACN universe range: Define the starting universe and the finish universe to write in memory on an external SD card for an Art-Net/sACN show. Cf: "Saving Art-Net or sACN to an external SD card" 17 ... -
Page 18: Clock Tab
Clock tab Set up the internal clock of the selected device 1. Display the current date and time of the device. 2. Synchronize the device's date and time with the computer. 3. Manually set the date and time, then apply the changes. 4. Calibrate the compensation time based on the observed deviation. 5. Enable the option to account for daylight saving time (summer/winter time changes). 6. Specify the dates for daylight saving time changes. Options tab For devices with an LED display, turn it off after 4 seconds of inactivity by checking the option. 18 ... -
Page 19: Master/Slave Tab
Select a default scene to play automatically after the device is turned on (with USB or external power supply). For multi-zones devices it is possible to set a default scene for each area. Note: The selected default start scene loses its priority if another scene uses the "Restore if power off" option. Cf: "Advanced trigger options" Configure the "Select Dimmer channels" option to select separately the Dimmer or RGBW light intensity channels that will be controlled directly by Dimmer mode, dry contacts or via the infrared remote control. Master/Slave tab Connect multiple devices into USB so that they are detected by the software. 19 ... -
Page 20: Master/Slave Mode "By Default
Use the Master/Slave option to synchronize their standalone mode and DMX universe. When an device is set as a master in the software, the other devices are automatically put in slave mode.There are four different modes of master/slave interaction: By default, desynchronized, LTP, and no release. Master/Slave mode "by default" A single device is defined as master (lower serial number by default), the others are automatically defined as slaves.The master device plays the current scene and synchronizes the slave devices. The master forces slave devices to play the same scene and the same stage step simultaneously. Slave devices are forced to track the timings and triggers of the master and they cannot act otherwise, play or trigger a scene independently. The master can trigger and stop scenes from slave devices. "Desynchronized" Master/Slave mode One device is defined as master, the others are automatically defined as slaves. All master device triggers are transmitted to slaves. However, slave devices are not synchronized with the master device synchronization signal and retain individual control. Therefore, slaves can trigger and play different scenes at any time and not synchronized perfectly with those of the master.The master acts as a general remote control imposing the trigger on slaves with total priority.The master can trigger ON and OFF scenes from the slave device. Master/Slave mode "LTP" LTP means "Latest Takes Priority / The latter has Priority".All devices are defined as slaves.The devices are not synchronized with timing and can trigger and play different scenes by themselves.However, device triggers are automatically transmitted to other connected devices and slave devices are forced to trigger the same scene.In this mode, each device acts as a general remote control imposing triggering on other slaves without synchronization. Master/Slave mode "No release" This option is only available with LTP or DESYNCHRONIZED modes.Only ON triggers of the master device are executed and functional. All OFF triggers are ignored and slave devices continue to play their current scene. Each slave device can choose whether or not to release its scene depending on whether the option is enabled or not. Cf: "Wiring diagram for Master/Slave installation" 20 ... -
Page 21: Commands Tab
Commands tab Assign external contacts, among those available for your device, to trigger some standalone mode commands: Dimmer +, Dimmer -, Blackout, Speed +, Speed -, Pause, Scene +, Scene - and Zone. Note: Be careful not to use the same command trigger as the one used for a scene and vice versa.Cf: "Choice of triggers by external contacts" The last assigned contact will take priority over the other. Use 2 types of Short/Hold contact and thus assign an identical contact to 2 different commands. (here as an example with the Dimmer +; Dimmer -) Zones tab The multi-zone option allows you to play multiple scenes simultaneously in defined areas. Add, delete and set zones in the scene list window. (cf : Scenes and zones selection zones configuration) 21 ... -
Page 22: Multi-Zone And Master/Slave Connection
The tab displays the DMX configuration summary of the associated DMX zones and addresses. Set the area settings manually, moving the center bar or digitally choosing the range of the area in the fields. Note: Verify that the addresses of DMX patches and devices match the defined areas. Multi-zone and Master/Slave connection If the interfaces are connected in Master/Slave mode, only the Master device controls the multi- zone. Its last zone (zone E) can be extended to the next universes of the Slave devices. Device stand-alone mode configuration In the "Device" tab enable or disable the standalone modes of the device by clicking on the icons at the top of the device. The icon is selected when it appears in white 22 ... -
Page 23: Scenes And Zones Selection And Configuration
Scenes and zones selection and configuration 1- global scene selection and assignment buttons : Unselect all scenes Select all scenes to be saved in memory Reorder all scenes according to the scene index created in the software's editing mode. Drop all scenes to assign them to trigger buttons Drop all scenes to assign them to infrared triggers Drop all scenes to assign them to external contacts 2- Add and remove zones 3- Set first and last DMX address. 4- Scenes list : drag and drop scenes to reorder. Select scenes to be saved in memory and assign triggers from those available by your device. Choice of triggers In the "Triggers" tab, select and assign different types of triggers. 23 ... -
Page 24: Infrared Trigger
Trigger buttons in the "Device" tab Assign physical buttons to scenes using the schematic representation of the device in the "Device" tab. After selecting the area and scenes to save in memory, drag and drop onto the device buttons. Use plus and minus buttons to change page. Automatically assign buttons to all scenes in the list according to their area, by clicking on the "button" icon on the toolbar scenes list. Infrared Trigger For devices that do not have this trigger option an Infrared kit is available containing an IR receiver and a remote control. Cf: "use of the remote control by infrared" Select a scene from the list and assign it a remote control button from the 15 available buttons. 24 ... -
Page 25: Rs232 Trigger
Automatically assign buttons to all scenes in the list by clicking the Infrared icon on the scene list toolbar. RS232 trigger Use RS232 as a receiver to control the device via another device with the commands also described in the Software Help topic. 25 ... -
Page 26: External Contacts Trigger
External contacts Trigger: Depending on the device, several external contacts are available: Trig A, Trig B, Trig C ..., and the Use a multiplexing device to extend the number of contacts when possible.(from 3 to 7; from 4 to 15; from 5 to 31 ...) Contact reaction time, 5ms (0.005s) Example of multiplexing system with 4 external contacts extended to 15. Select a scene from the list and assign it a contact from those available through the device. Option of triggers Select a trigger option from the drop-down menu next to it. On: Activating the contact makes the scene play (the only trigger action is to start the scene). On/Off: Activating the contact starts the scene, subsequent activation stops the scene.Each trigger action will reverse the stage state (start/stop). Auto Release: The scene is played only while the contact is enabled. When the contact is released, the scene stops. Restart: If the scene is playing, enabling the contact restarts the scene from its beginning.If the scene is not being played, it will start.External contact reaction time: 8 ms (0.008 s) / time between 2 contacts: 500 ms (0.5 s) If something plays: Play the selected scene if a scene is already played. 26 ... -
Page 27: Triggers By Dmx-In
If nothing plays: Play the selected scene if nothing plays. These two interdependent options allow the same contact to be assigned to two different scenes. Note: Be careful not to use the same scene trigger as the one used for a command and vice versa.Cf: "Order tab" The last assigned contact will take precedence over the other. Automatically assign external contacts to all scenes in the list by clicking the external contact icon on the scene list toolbar. Triggers by DMX-IN 255 trigger channels and up to 255 levels per channel are available. Select a scene from the list and assign it a channel number associated with a trigger level.A trigger level corresponds to the threshold above which the scene is triggered. Note: To configure triggers in DMX-IN, one of the DMX lines must be Select as input in the "IN/OUT Config tab." Triggers via Wi-light 2 app and UDP commands When connected to a local network with a WIFI access point, it is possible to trigger and control the device with the Wi-Light 2 app for Android and iOS when it runs in standalone mode.This local mode is also available on the internet with the Web Remote option. Each device, device and mobile, must be connected to the same access point in DHCP (recommended) or fixed IP mode.The application will then detect the device and display the list of scenes and other possible controls and commands. The Web Remote control option requires you to create a user account and save your devices locally first. Please refer to the Wi-Light 2 manual to use this mode. The Wi-Light 2 app uses an open protocol for developers with standard communication based on simple UDP commands. 27 ... -
Page 28: Time Triggers
Third-party software can establish UDP communication with the software/device and control it using predefined JSON commands.Option only available with devices with an Ethernet port.(see "Communication Development Kit User Manual") Time triggers Select a scene from the list and assign it a trigger period.Organize and repeat triggers over the year in specific ways. Single trigger Check "Enable trigger" and "disable trigger" to determine a period. Select a date (timetable icon) and time (hour/minutes fields) of trigger activation and then disable trigger. Without shutdown, the scene will play indefinitely until another event replaces it with another scene triggering or manual shutdown. Permanent trigger For example above: the scene plays from Monday to Thursday from 11am to noon from 1st to 20 of each month, from September to April. Check "Repeat every year" to set the monthly and then daily triggers. Select or deselect the months of active triggers in the left wheel. (selection in orange) After selecting the green square for the start day or the red square for the end day, determine the period of the month during which the trigger will be active. 28 ... -
Page 29: Light Intensity Trigger
Select or deselect the days of the week or the trigger will be active in the right wheel. (selection in orange) Select a start time and an end time of trigger. Note: For a daily repetition, if the start time is after the end time, the trigger will stop the next day, even if the next day has not been selected. Light intensity trigger This option is available for devices with an Infrared kit. Cf. "Use the remote control" Check "brightness" to activate or disable the trigger according to the ambient light. Once checked this option cancels and replaces the time trigger. Click on the icon to determine if the trigger activates or disables during the upward phase (day to night) or downward phase (night to day). Click the arrow to set a value that corresponds to the light sensitivity and at which the trigger activates or disables. Using the arrows, adjust the value that fits into the dedicated field. Trigger priority with identical time When multiple scenes have the same time trigger (date + hour + minute), only the last scene in the list will be triggered. The others above in the list will be ignored when triggered. Advanced trigger options. 29 ... -
Page 30: Restore After Power Off
Restore after power off By checking this option in the "Triggers" tab, the selected scene takes priority on the boot scene (see "Options tab") when the power supply is restored. If all scenes have the option checked, the last active scene is replayed. Play in priority By checking this option in the "Triggers" tab, the selected scene plays continuously until its end, without taking into account other triggers, except for time triggers and physical buttons on the device. 30 ... -
Page 31: Save In Memory Option
Save in memory option Check scenes that need to be saved in memory. Click on the "Write in Memory" button Select the desired option in the Scenes Write window. Basic backup Write standalone configuration: Change only certain settings in the configuration of a show already written in memory. Reduces backup time. Write to Memory: Default backup in the internal memory of the device. 31 ... -
Page 32: Save To An Internal And External Micro Sd Card
Save to an internal and external micro SD card For devices with a micro SD port. Save scenes to a micro SD card (Class 10) installed in the device's SD card reader or in the computer drive.The card must be CLASS 10, formatted in FAT or FAT 32 with a maximum capacity of 256 GB.It is recommended to use the largest allocation unit size available when formatting. Write to the SD card of the device: SD card installed in the device drive Write to an external SD card: SD card connected to the computer Note: Save to the root directory of the SD card. Backing up Art-Net or sACN to an external SD card For devices with a micro SD port and an Ethernet port. Art-Net - Write to an external SD card: Save up to 8 universes only on micro SD to render an Art- Net or sACN show independently. Set the universe range in the IN/OUT config tab.Cf: Pre-commissioning verification: Connecting the RJ45 cable before power on. Connection to the local network.Cf: "Ether Ethernet connection and configuration" Configuring the device in Art-net or sACN mode via the software or DeviceTool. Note: Once in Art-Net (Ar) or sACN (AC) mode, the device is no longer visible on the local network. In Art-Net the device will use Broadcast to play the show on the network. In sACN the device will use the Multicast to play the show on the network. 32 ... -
Page 33: Standalone Use
Standalone use Switch to standalone mode The device switches to standalone mode automatically after 5 seconds after power on and if no software connection is made. External and USB power supply The external power supply is only used for "Autonomous" mode.But it is possible to connect a USB cable and power supply at the same time, even if this configuration is not recommended.If a USB cable is connected to the device when running in standalone mode, the device will detect a possible connection to a computer but this will not affect the scenes that play. Charging the clock battery Before installing the device in standalone mode, connect the device for 1 hour to charge the clock battery and avoid losing the saved time configurations. Play a show via a Micro SD Card To play the SD show standalone, insert the card into the micro SD drive of the device. When powered, the screen displays "Sd" to indicate that the SD file of the project is being played. Note: The show file must be saved to the root directory of the micro SD.It will not be read if the file is renamed or saved in a folder or subdirectory. Notes on Recommended Specifications for SD cards: The class of the SD card indicates its read/write speed.Higher class numbers (for example, Class 10) offer faster speed and better compatibility. Class 6 or higher micro SD cards are preferable for optimal system performance. Older Class 2 and 4 SD cards may not work. Prefer Class 10 micro SD cards for mobile phones. 33 ... -
Page 34: How To Use Ir Remote
How to use IR Remote Infrared Remote triggers work in Standalone and in Live mode when “Get Stand Alone Triggers” is checked in software option window, at the bottom of "Device" section. Previous Remote Control Unit (Before 2022) Functioning for devices without Mode and older devices. 1. Scene trigger buttons (1 to 10) assigned via the software. 2. Scene selector, next or previous. 3. Speed value, increase & decrease 4. Dimmer value, increase & decrease 5. Blackout: Stops the current scene and plays the scene 00. All DMX levels are set to zero. 6. Pause: Freezes the current scene in its state Functioning for devices with Modes 1. Scene trigger buttons (1 to 10) assigned via the software 2. Increase or decrease the value of the selected mode: Scene +/-, Dimmer +/-, Speed +/-, Color +/-. 3. Color mode 4. Scene mode 5. Dimmer mode 6. Speed mode 7. -
Page 35: New Remote Control Unit (2022)
New Remote Control Unit (2022) Functioning for devices without Mode and older devices. 1. Scene trigger buttons (1 to 10) assigned via the software. 2. Scene selector, next or previous. 3. Speed value decrease 4. Speed value increase 5. Dimmer value decrease 6. Dimmer value increase 7. Blackout: Stops the current scene and plays the scene 00. All DMX levels are set to zero. 8. Pause: Freezes the current scene in its state Functioning for devices with Modes 1. Scene trigger buttons (1 to 15) assigned via the software Trigger 1 to 15 with 1 Zone. Trigger 1 to 9 with several Zone. 2. 5 Control Zones available: A, B, C, D, E and Global Zone: [ ] to trigger each Zone in the same time. 3. Increase or decrease the value of the selected mode: Scene +/-, Dimmer +/-, Speed +/-, Color +/-. 4. Release Color mode 5. Color mode 6. -
Page 36: Functions Descriptions
Functions descriptions Scene +/-: Each push selects the next or previous scene of the current Zone. Scene are play immediately. Master Dimmer: Increases or decreases the RGB, CMY and dimmer channels of the current zone. The CMY, RGB, Dimmer channels are defined in the Profile of the fixture and the standalone mode. Scene Speed: Increases or decreases the speed of the current scene in the current zone. A different speed can be chosen separately for each scene. Zones: Choose a Zone (A,B,C,D,E or Global [ ]). Then select a scene or mode to trig in the selected zone. Modes: Select a Mode from Speed, Dimmer, Color or Scenes, then use +/- to change values. IR Codes 36 ... -
Page 37: Ir Receiver Box
IR receiver box To use the optional IR remote control, an external circuit with an IR receiver must be connected via an RJ45 port or via the standalone device terminal block. IR PCB pinout -With RJ45 cable, use pins: #8 = Ground; #4 = IR data; #7 = 5V. -With connectors, use pins: O = IR data; V = 5V; G = Ground. Maximum distance from cable to receiver is approx. 20 m. Light sensor The light sensor integrated in the IR box circuit only works with hourly triggers. The external card must be connected via the RJ45 port or via the terminal block. Light sensitivity must be set in the software. See "Time-controlled scenes". 37 ... -
Page 38: Node Mode Configurations
NODE mode configurations Setup with the software Network setup Access the device options window: In the "Ethernet" tab, check "DHCP" to put the device in DHCP mode and apply. To put the device in static IP mode, uncheck "DHCP" and enter the IP address, subnet mask, gateway, and name, and then apply. Cf: "Ether Ethernet connection and configuration" NODE Art-Net or sACN mode The device's Node mode makes it possible to convert Art-Net and sACN signals to DMX. In the Node part, select Node Art-Net to change the settings you want. Configure names with "Short Name" and "Long Name". Change the DMX ports or outputs of the Node by changing the "SubNet" and "DMX Universe", and then apply. Select Node sACN to choose DMX and applied Universes. Press "Apply" to take into account the new settings. To use the device in the selected mode, you must restart the device after configuration by unplugging it from the power supply. It is also possible to switch between Art-Net and sACN mode with long support (5s.) on the Device Mode button and following the network configuration of the device. 38 ... -
Page 39: Setup With The Devicetool
Setup with the DeviceTool Network setup Open the device via USB or Ethernet with the option "Open USB Device" or Open "Ethernet Device. Select the "Network" tab. In the "Ethernet" tab, check "DHCP" to put the device in "DHCP" mode and apply. To put the device in static IP mode, uncheck DHCP and enter the IP address, subnet mask, gateway, and name, then apply. NODE Art-Net or sACN mode The device's Node mode makes it possible to convert Art-Net and sACN signals to DMX. Open the device via USB or Ethernet with the option "Open USB Device" or Open "Ethernet Device. Select the "Fashion" tab. Select Node Art-Net to change the desired settings. Configure names with "Short Name" and "Long Name". Change the DMX ports or outputs of the Node by changing the "SubNet" and "DMX Universe", and then apply. Select Node sACN to choose DMX and applied Universes. Press "Apply" to take into account the new settings. 39 ... -
Page 40: Configuration With A Web Browser
To use the device in the selected mode, you must restart the device after configuration by unplugging it from the power supply. Switch between Art-Net and sACN mode with long support (5s.) on the Device Mode button and following the network configuration of the device. Configuration with a Web Browser This feature is not currently available. Udp, Broadcast, Unicast, Multicast Art-Net and sACN are communication protocols based on the UDP/IP standard. These 2 protocols integrate DMX frames into Ethernet frames allowing simpler and more convenient wiring with the use of IP switches or WIFI terminals. Several DMX lines can be encapsulated in an Ethernet frame and therefore reduce wiring to 1 single Ethernet line for X DMX lines. Art-Net network data is transmitted in Broadcast or Unicast. Unicast is preferable when using multiple devices on the network and when managing more than 10 DMX universes. sACN network data is transmitted in Unicast and Multicast. 40 ... -
Page 41: Node Wiring Diagram
NODE wiring diagram Reset default device To restore the default values and reset your device, reconfigure the device via USB or Ethernet with the software or DEVICETOOL or app and restart it to take into account the new mode and settings. Change mode directly on the device with a 5 second long press on the mode button. Network NODEs detection Connect multiple devices into the same network to multiply the output DMX universes. Check previous steps ● Assigning IP addresses and subnet masks. ● Configuring devices via the software or DeviceTool. ● Connecting devices to the network. ● Powering devices. If the steps have been followed, the devices are visible on the network by the software or by other devices compatible with Art-Net frames. 41 ... - Page 42 42 ...
-
Page 43: Update Firmware In Bootloader Mode
Update firmware in bootloader mode Update the device when it is in bootloader mode. Bootloader mode failure: ● The USB signal LED(s) flash rapidly ● The LED display shows BL (CQSA/CQSA-E/SLIM) ● The device is not detected by the software, which indicates that an update is required Update the device via the software opening window Open the software : 1. Click on "update" 2. Unplug and replug USB cable, wait until the end of the update. 43 ... -
Page 44: Update The Device Via The Devicetool
3. click "ok" to Restart the software Update the device via the DeviceTool 1. Connect your device via the USB port 2. Click "Open USB Device" 3. Inside "Firmware" tab, click "Auto Update" 4. Unplug and replug USB cable, wait until the end of the update. 44 ... - Page 45 5. Close the DeviceTool to use the device normally 45 ...
-
Page 46: Housing Dimensions
Housing dimensions Dimensions in mm/in. Rear panel Side panels Bottom panel 46 ... -
Page 47: Troubleshooting
Troubleshooting The device is not detected by the DeviceTool or Unplug to restart the device. USB software. Change the USB cable Unplug to restart the device. The device is not detected by the DeviceTool or Change the Ethernet cable Ethernet software. Check the selection of the Ethernet network before opening. Check the mode of communication with LED signals and reconfigure the device via USB if necessary Verify that the IP addresses and subnet mask are configured correctly. Update the firmware of the device via the software or DeviceTool The device is not detected on the network. Update the software with the latest version and try again Open and allow communication ports used by the device. Some local networks may require manual opening of the following UDP Ports: 8011 + 8012 for communication between the device and software. Check the firmware and software version. Device with display When working properly: The screen indicates "ON" when connected to the computer, then it displays "SA" and "00" (or a scene number). When you start the software and the device is properly detected, you should see "PC". Device without display The device is blocked in standalone mode and Check the mode of communication with LED it cannot establish communication with the ... - Page 48 Before commissioning, plug the RJ45 cable before powering. Replugging the power supply Insert the SD card again (Reset) Device with display The device does not restore the Art-Net or Select ArtNet (Ar) mode again, sACN (AC) in sACN show. the advanced F3 menus of the device (mode button). Device without display Select ArtNet, sACN mode again via the software or DeviceTool. If you experience unlisted issues, contact your seller or manufacturer directly to indicate your problem and receive a solution. Product design and specifications are subject to change without prior notice. Older devices (sold before 2020) are not compatible with PRO DMX version 2 Wechat: Chromateq 191 Allée de Lauzard WhatsApp: +8613422062209 34980 St Gély du Fesc, FRANCE QQ: 2908265661 Web: www.chromateq.com Email: info@chromateq.com Guaranteed products: 1-3-5 years Phone: +33 952210755 Software pack: https://chromateq.com/dmx-software- downloads/ Copyright © 2021 - CHROMATEQ.All rights reserved. 48 ...
