Puls PISA-M-4CL2 Manual

P D
RODUCT ESCRIPTION
The PISA-M devices are miniature 4-channel protection
modules for 24 V and 12 V systems providing all benefits
of electronic circuit breakers in a tiny DIN rail mountable
housing: Voltage-dependent
independent output channels in one device – including
selection of tripping characteristic combined with different
options for remote signaling and communication, enabling
remote configuration, monitoring and control.
The PISA-M supports multiple, user-selectable, signaling
and communication methods, allowing the selection of
simple alerts and reset function.
All PISA-M devices are equipped with push-in terminals,
which are optimised for automated wiring and allow fast
and safe installation.
O N
RDER UMBERS
Electronic Circuit Breaker
PISA-M-4CL2 4 NEC Class 2 output channels
Accessory
ZM3.Wall Wall mounting bracket
All parameters are specified at 24 Vdc, 4 x 3.75 A, +25 °C ambient temperature and a 5 minutes run-in time unless otherwise noted.
Dec. 2024 / Rev. 1.0 DS-PISA-M-4CL2
tripping current for
www.pulspower.com
E
LECTRONIC
4 24 - 12 V, 3.75 - 5 A
X
•
4 current controlled output channels
•
Adaptive voltage-dependent tripping current for
maximal output power according to NEC Class 2
•
Selective tripping of overloaded output channels
•
Compatible even with large capacitive loads
•
24 V and 12 V operation
•
Width only 22.5 mm
•
Protection function in case of PSU overload
•
Local control and reset via push buttons
•
Configurable signaling and communication interface
•
ON/OFF feature for each individual output channel
•
Easy wiring via push-in terminals
•
3 year warranty
S -
HORT FORM
Input voltage
Input current
4
Internal
consumption
Output tripping
current per channel
Tripping
characteristics
Tripping delay
Max. capacitive
load
Efficiency
Signaling and
Communication
Temperature range -25 °C to +70 °C
Size (w x h x d)
Weight
M A
AIN PPROVALS
For details and the complete approval list, see chapter 22.
PISA-M-4CL2
C B
IRCUIT REAKER
D
ATA
DC 24 V - 20 % / + 25 %
DC 12 V
- 20 % / + 25 %
max. 20 A
30 mA at 24 V
20 mA at 12 V
3.75 A at 24 V automatic adjustment
between 3 A and 4.85 A
4.85 A at 12 V
acc. to the input voltage
slow or fast selectable
< 2 ms at short circuit
0.22 s for fast tripping at 1.5 x
tripping current
< 10 ms at short circuit
1.1 s for slow tripping at 1.5 x
tripping current
45 mF at 3.75 A, 24 max., per channel
V resistive load,
slow tripping
characteristic
> 99 % at 24 V
> 98 % at 12 V
Output channel status
Remote output channel reset
Digital Coded Interface
22.5 x 104 x 98 mm without DIN rail
100 g without accessories
1/22
