IstallatIon anD maIntenance InstructIons
nc-100r relay control module
specIfIcatIons
Normal Operating Voltage:
Maximum Current Draw:
Average Operating Current:
EOL Resistance:
Temperature Range:
Humidity:
Dimensions:
Accessories:
relay contact ratIngs:
CURRENT RATING
2 A
3 A
2 A
0.46 A
0.7 A
0.9 A
0.5 A
0.3 A
Before InstallIng
This information is included as a quick reference installation guide. Refer to
the control panel installation manual for detailed system information. If the
modules will be installed in an existing operational system, inform the opera-
tor and local authority that the system will be temporarily out of service. Dis-
connect power to the control panel before installing the modules.
NOTICE: This manual should be left with the owner/user of this equipment.
general DescrIptIon
The NC-100R Relay Control Module is intended for use in addressable, two-
wire systems, where the individual address of each module is selected using
the built-in rotary switches. It allows a compatible control panel to switch
discrete contacts by code command. The relay contains two isolated sets of
Form-C contacts, which operate as a DPDT switch and are rated in accordance
with the table in the manual. Circuit connections to the relay contacts are
not supervised by the module. The module also has a panel controlled LED
indicator. This module can be used to replace an C304 module that has been
configured for Form-C operation.
compatIBIlIty requIrements
To ensure proper operation, these modules shall be connected to listed com-
patible system control panels only.
mountIng
The NC-100R mounts directly to 4˝ square electrical boxes (see Figure 2A).
The box must have a minimum depth of 2
boxes (SMB500) are available. The module can also mount to the DNR(W)
housing.
NOTE: All wiring must conform to applicable local codes, ordinances, and
regulations. When using control modules in nonpower limited applications,
the CB500 Module Barrier must be used to meet UL requirements for the sepa-
ration of power-limited and nonpower-limited terminals and wiring. The bar-
rier must be inserted into a 4˝×4˝×2
must be placed into the barrier and attached to the junction box (Figure 2A).
NO-460-007
15 to 32 VDC
6.5 mA (LED on)
230μA direct poll; 255μA group poll
Not used
32°F to 120°F (0°C to 49°C)
10% to 93% Non-condensing
4.675" H x 4.275" W x 1.4" D (Mounts to a 4˝ square by 2
SMB500 Electrical Box; CB500 Barrier
MAXIMUM VOLTAGE
25 VAC
30 VdC
30 VdC
30 VdC
70.7 VAC
125 VdC
125 VAC
125 VAC
1
/
˝. Surface mounted electrical
8
1
/
˝ junction box, and the control module
8
1
/
˝ deep box.)
8
LOAD DESCRIPTION
PF = 0.35
ResistiVe
ResistiVe
(L/R = 20ms)
PF = 0.35
ResistiVe
PF = 0.75
PF = 0.35
The power-limited wiring must be placed into the isolated quadrant of the
module barrier (Figure 2B).
1.
Install module wiring in accordance with the job drawings and appropriate
wiring diagrams.
2.
Set the address on the module per job drawings.
3.
Secure module to electrical box (supplied by installer), as shown in
Figure 2A.
Wire should be stripped to the appropriate length (recommended strip length
is
1
/
" to
3
/
"). Exposed conductor should be secured under the clamping plate
4
8
and should not protrude beyond the terminal block area. Caution: Do not loop
wire under terminals. Break wire run to provide supervision of connections.
fIgure 1. controls anD InDIcators:
1
12 Clintonville Road
Northford, CT 06472-1653
Phone: 203.484.7161
APPLICATION
NoN-Coded
NoN-Coded
Coded
NoN-Coded
NoN-Coded
NoN-Coded
NoN-Coded
NoN-Coded
C0925-01
I56-3503-002
