BACNET-GW-3
Programming and Operation Manual
Document: LS10014-000NF-E
A2
8/7/12
Rev:
P/N: LS10014-000NF-E: Rev. A2
ECN: 12-0294

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOTIFIER BACNET-GW-3 and is the answer not in the manual?

Questions and answers

Related Manuals for Honeywell NOTIFIER BACNET-GW-3

Summary of Contents for Honeywell NOTIFIER BACNET-GW-3

  • Page 1 BACNET-GW-3 Programming and Operation Manual Document: LS10014-000NF-E 8/7/12 Rev: P/N: LS10014-000NF-E: Rev. A2 ECN: 12-0294...

  • Page 2: Fire Alarm System Limitations

    Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system— typically made up of smoke detec- bedrooms), smoking in bed, and violent explosions (caused by escap- tors, heat detectors, manual pull stations, audible warning devices, ing gas, improper storage of flammable materials, etc.).

  • Page 3: Installation Precautions

    Windows are registered trademarks of the Microsoft Corporation. © 2012 by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited Documentation Feedback Your feedback helps us keep our documentation up-to-date and online Help or manuals, please e-mail us at accurate.

  • Page 4: Manual Usage

    – Please include the following information: On-Line Help • Product name and version number (if applicable) • Topic title • The content you think should be corrected/improved • Detailed suggestions for correction/improvement – Please include the following information: Documents • Document part number and title •...
  • Page 5 BACNET-GW-3 Programming and Operation Manual – P/N: LS10014-000NF-E: Rev. A2 8/7/12...
  • Page 6 BACNET-GW-3 Programming and Operation Manual – P/N: LS10014-000NF-E: Rev. A2 8/7/12...

  • Page 7: Table Of Contents

    Table of Contents Section 1 Product Overview ....................9 1.1: Product Description ............................9 1.2: Features................................9 1.3: BACnet Clients ..............................9 1.4: Listing Document ............................9 1.5: Required Software ............................9 1.6: System Architecture.............................10 Figure 1.1 Single Panel Architecture....................10 Figure 1.2 NFN Network Architecture....................10 1.7: IP Port Requirements ...........................11 1.8: Installation Overview...........................11 1.8.1: Required Equipment ..........................11...
  • Page 8 Table of Contents Logic Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE)..........28 Special Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE) ..........28 Trouble Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE)..........28 Releasing Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE) ...........28 DAA Speaker Circuit ...........................28 Input, Output, and ZoneNotify (NOTIFICATION_CLASS)...............28 BACNET-GW-3 Programming and Operation Manual – P/N: LS10014-000NF-E: Rev. A2 8/7/12...

  • Page 9: Section 1 Product Overview

    Section 1 Product Overview 1.1 Product Description The BACNET-GW-3: • Provides a communication link between networks that use the BACnet communication protocol and Fire Alarm Control Panels (FACPs) resident on an NOTI•FIRE•NET (NFN) network or high- speed NFN network. • Acts like another node on an NFN network or high-speed NFN network. •...

  • Page 10: System Architecture

    Product Overview System Architecture 1.6 System Architecture An Internet or Intranet IP network connection is used with the architectures described in Figures 1.1 and 1.2. IP Network Ethernet Ethernet FACP BACnet/IP Client Figure 1.1 Single Panel Architecture IP Network Ethernet Ethernet Ethernet BACnet/IP Client...

  • Page 11: Ip Port Requirements

    IP Port Requirements Product Overview 1.7 IP Port Requirements The following IP ports must be available to the BACNET-GW-3: Port Type 4016 47808 62957 The following restrictions apply: Functionality Restriction • Must have a Static IP Address, DHCP is not supported. Infrastructure •...

  • Page 12: 2: Board Layout

    Product Overview Installation Overview 1.8.2 Board Layout USB “A” Host (J2) USB “B” Device (J1) Ethernet Connector LEDs (J3) (See Table NUP A Serial Data Connector (J4) Mounting Hole Not Used (J5) (1 of 12) Not Used (TB1) TB2: -24 V Out +24 V Out -24 V In +24 V In...

  • Page 13: Section 2 Configuration

    Section 2 Configuration 2.1 Configuration Web Page The BACNET-GW-3 is configured through a dedicated web page running on the embedded gateway itself. Microsoft Internet Explorer version 8 or later with the latest version of Java is required to configure the BACNET-GW-3.

  • Page 14: 3: Bacnet-Gw-3 Main Menus

    Configuration Configuring the BACNET-GW-3 2.3.3 BACNET-GW-3 Main Menus The configuration main menus are located at the upper left-hand area of the screen (see Figure 2.1). Menu Sub-Menu Description File Reboot Reboots the BACNET-GW-3. View Refresh Node Refreshes the node list in the BACnet Gateway navigation pane. List Gateway Opens the Gateway Activity screen.

  • Page 15: 5: Additional Properties

    Configuring the BACNET-GW-3 Configuration Property Value Notification Select the operating mode for the gateway from the drop-down menu: Type • Multi State • Life Safety Network Click the value to enter the base network number for the gateway. Number Note: If using more than one BACnet Gateway on the same network, separate network numbers by at least 100.

  • Page 16: 6: Node List

    Configuration Configuring the BACNET-GW-3 Sub-Item Property Value Connection Displays “Serial” when there is no NFN connection. Port Information (Read Only) Connection Describes how the gateway is connected to the NFN. Type NCM Version Displays the NCM version number. Note: NCM Version does not appear when there is no NFN connection. NCM Status Displays the NCM status, which can be: Piezo, UPS Failure, Network Fail Port A, Bits...

  • Page 17: Appendix A: Bacnet Protocol Implementation Conformance Statement (Normative)

    Appendix A: BACnet Protocol Implementation Conformance Statement (Normative) BACnet Protocol Revision: 1.2 A.1 Product Description ® This product presents NOTIFIER Fire Panel and Annunciator nodes (operating as part of an NFN network or stand-alone) and their associated objects as BACnet objects. Event notification for Alarms, Troubles, and other states are sent to registered BACnet client workstations.

  • Page 18: A.5: Standard Object Types Supported - Life Safety Point/Life Safety Zone

    BACnet Protocol Implementation Conformance Statement (Normative) Standard Object Types Supported - Life Safety Point/Life A.5 Standard Object Types Supported - Life Safety Point/Life Safety Zone BACnet BACnet NFN State Enumeration LifeSafetyState IssQuiet Normal IssPreAlarm PreAlarm IssAlarm Fire Alarm, Security Alarm (Life/Property), Critical Present Value Process Alarm, (Life/Property), Medical Emergency IssFault...
  • Page 19 Standard Object Types Supported - Life Safety Point/Life Safety Zone BACnet Protocol Implementation Conformance Statement BACnet NFN State Enumeration Silence State ssUnsilenced Audibles Unsilenced ssAudiblesSilenced Audibles Silenced BACnet NFN State Operation Enumeration Expected BACnet NFN State Maintenance Enumeration Expected BACnet Event Transition Bit Event Enable toOffNormal...

  • Page 20: A.6: Standard Object Types Supported - Multi-State Input Standard Object Types

    BACnet Protocol Implementation Conformance Statement (Normative) Standard Object Types Supported - Multi-State Input A.6 Standard Object Types Supported - Multi-State Input Standard Object Types BACnet NFN State Enumeration None Normal Present Value None All statuses other than those included in 3 and 4 below. None Security Trouble, Fire Trouble, Non-Fire Trouble None...

  • Page 21: A.7: Supported - Binary Output

    Supported - Binary Output BACnet Protocol Implementation Conformance Statement (Normative) A.7 Supported - Binary Output BACnet BACnet NFN State Enumeration LifeSafetyState IssQuiet Normal IssPreAlarm PreAlarm IssAlarm Fire Alarm, Security Alarm (Life/Property), Critical Present Value Process Alarm, (Life/Property), Medical Emergency IssFault Security Trouble, Fire Trouble, Non-Fire Trouble, Fire Device or Zone, Disabled, Non-Fire Device Disabled IssActive...

  • Page 22: A.8: Standard Object Types Supported - Notification Class

    BACnet Protocol Implementation Conformance Statement (Normative) Standard Object Types Supported - Notification Class BACnet NFN State Enumeration Silence State ssUnsilenced Audibles Unsilenced ssAudiblesSilenced Audibles Silenced BACnet NFN State Operation Enumeration Expected BACnet NFN State Maintenance Enumeration Expected BACnet Event Transition Bit Event Enable toOffNormal toFault...

  • Page 23: A.8.1: Device Address Binding

    Standard Object Types Supported - Notification Class BACnet Protocol Implementation Conformance Statement (Normative) Point-To-Point, modem, (Clause 10), baud rate(s): LonTalk, (Clause 11), medium: ______________ Other: ______________ A.8.1 Device Address Binding Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain other devices.) A.8.2 Networking Options Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
  • Page 24 BACnet Protocol Implementation Conformance Statement (Normative) Standard Object Types Supported - Notification Class BACNET-GW-3 Programming and Operation Manual – P/N: LS10014-000NF-E: Rev. A2 8/7/12...

  • Page 25: Appendix B: Gateway Settings

    Appendix B: Gateway Settings NOTE: The procedures in this Appendix require the use of a USB flash memory drive. B.1 Viewing Existing IP Settings 1. Connect the flash drive to the BACNET-GW-3. 2. Reboot the gateway. A file is created that matches the configured IP address of the gateway, followed by the extension “.txt”...
  • Page 26 Gateway Settings Resetting Factory Default Values BACNET-GW-3 Programming and Operation Manual – P/N: LS10014-000NF-E: Rev. A2 8/7/12...

  • Page 27: Appendix C: Bacnet-Gw-3 Equations

    BACNET-GW-3 Equations Appendix C: BACNET-GW-3 Equations Equations for Object IDs (Instance Numbers) In the BACNET-GW-3, each NFN Node has 10,000 object IDs available to it. For each NFN Node, multiply its Node Number by 10,000 and add the offset calculated below based on what type of point it is. These numbers define the 22 bits of the BACnet Object Identifier field.

  • Page 28: Panel Circuits (Binary_Output)

    BACNET-GW-3 Equations Panel Circuits (BINARY_OUTPUT) (Panel# x 10) + (circuit# - 1) + 350 Annunciators (MULTI_STATE_INPUT or LIFE_SAFETY_POINT) (ANNUN# + 699) Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE) ZONE (0 - 499) => (ZONE# + 1500) ZONE (500-999) => (ZONE# + 2000) Logic Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE) LZONE (1 to 499) =>...

  • Page 29: Manufacturer Warranties And Limitation Of Liability

    Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
  • Page 30 World Headquarters 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
