Kohler Loure 97840T Installation Instructions

ACCESSORY SERVICE PARTS
97840T Mirror With LED Lighting
97841T Mirror With LED Lighting
97843T Mirror With LED Lighting
1061576
1243778
1243811
1243778
1243812
1243797**
1243812
**Color code must be specified when ordering
NOTE: For all Asia pacific regions (excluding China) add SP (SPxxxxxxx**) in front of the part number when ordering.
1270474-2A-B
1243785**
1243810
1243785**
1282841**
1243810
1243811
1243778
1243779
1243786
ACCESSORY INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTE:
1. These products should be located and mounted to a wall. While it is possible to mount them to any surface, a
stud or concrete mounted product will yield the best results.
2. Don't place or install the product in the region where there may be water.
3. Don't touch the power button with wet hand.
Prior to drilling into walls, check there are no hidden electrical wires, cables or water supply pipes with the aid of
electronic detector. If you use power tools do not forget:
1. Wear eye protection.
2. Unplug equipment after use.
DANGER: (Risk of personal injury )
These products are not designed or intended for use as a grab bar or support bar. Do not install where the product
might be used as a grab or support bar.
ROUGH-IN DIMENSIONS
38
Ø6
4 1270474-2A-B
97840T Mirror With LED Lighting
97841T Mirror With LED Lighting
97843T Mirror With LED Lighting
354
6
154
68
97840T
1
