Maple Systems HMI5043LBv2 Series Installation Instruction page 2

EasyBuilder Pro Software Settings
6
Launch EasyBuilder Pro software, select your project file, press F7 shortcut key to open the download
dialog box: Select Ethernet > IP tab > Enter your HMI IP > Click Download to download this project
file to HMI.
Using screensaver and backlight saver is recommended in order to avoid image persistence caused
by displaying the same image on HMI for a long time.
( Please refer to EasyBuilder Pro User Manual for software operation details )
7 Communication Connections
NOTE: COM1 and COM3 [RS485] 2W support MPI 187.5K, please use one at a time.
9 Pin, Male, D-sub
COM1 [RS232]
COM1 [RS485]
COM3 [RS485]
8
Calibration Mode
Press and hold anywhere on the screen when HMI starts
until it enters touchscreen calibration mode. If "Enable
[Reset HMI to default] button in calibration mode" is
selected as described in Part 5 System Settings, then
[RESET HMI TO DEFAULT] and [SYSTEM SETTINGS]
buttons can be found in calibration mode. Follow the
onscreen guide and press [yes] to restore factory
default, and please note that the projects and data
stored in the unit will all be cleared after this.
9 Battery Replacement
Battery replacement shall be performed by qualified personnel only and care must be taken when
handling lithium batteries.
COM1
COM1 [RS485]
PIN# [RS232] [RS485]
4W 2W
2W
1 Rx- Data-
2 Rx+ Data+
3 Tx-
4 TX+
5 GND
6 TxD
7
8
9 RxD
NOTE: Make sure that all local and national electrical standards are met when
CAUTION
installing the unit. Contact your local authorities to determine which codes apply.
The unit can be powered by DC power only, voltage range: 22~28VDC, compatible with most
Power controller DC systems. The power conditioning circuitry inside the unit is accomplished by a
switching power supply. The peak starting current can be as high as 2A.
If the display does not come on within 5 seconds of power up, remove power. An internal fuse will
Fusing
prevent damage if the polarity of the DC power is incorrect. Check wiring for proper connections
Require-
and try to power up again.
ments
An Internal fuse will prevent damage for overcurrent condition however it isn't guaranteed. DC
High
voltage sources should provide proper isolation from main AC power and similar hazards.
COM3 Voltage
A Hard-wired EMERGENCY STOP should be fitted in any system using
2W
Emergency
Safety Recommendations.
Stop
Do not power the unit and inductive DC loads, or input circuitry to the controller, with the same
Supply
power supply. Note: The 24 VDC output from some controllers may not have enough current to
Voltage
power the unit
Condition
a. Power wire length should be minimized (Max: 500m shielded, 300m unshielded).
Wire
b. Please use twisted pair cables for power wire and signal wire and conform to the impedance
Routing
matching.
c. If wiring is to be exposed to lightning or surges, use appropriate surge suppression devices.
d. Keep AC, high energy, and rapidly switching DC power wiring separated from signal wires.
Data-
e. Add a resistor and capacitor in the parallel connection between the ungrounded DC power
Data+
supply and the frame ground. This provides a path for static and high frequency dissipation.
Typical values to use are 1M Ohm and 4700pF.
DANGER
Hardware The system designer should be aware that devices in Controller systems could fail and thereby
create an unsafe condition. Furthermore, electrical interference in an operator interface can lead to
Considerations
equipment start-up, which could result in property damage and/or physical injury to the operator.
If you use any programmable control systems that require an operator, be aware that this potential
safety hazard exists and take appropriate precautions. Although the specific design steps depend
on your particular application, the following precautions generally apply to installation of solid-state
programmable control devices, and conform to the guidelines for installation of Controllers
recommended in NEMA ICS 3-304 Control Standards.
To conform with ICS Safety Recommendations, checks should be placed in the controller to ensure
Programming that all writable registers that control critical parts of plant or machinery have limit checks built into
the program, with an out-of-limit safe shut down procedure to ensure safety of personnel.
Considerations
Limited Warranty
A copy of the Warranty and Limitation of Liability is contained in the product box. It can
also be found on the Maple Systems website.
.
HMI
to comply with ICS
1010-1143_rev01_250131
