- Page 1 OPERATION MANUAL DIGITAL NETWORK PUBLIC ADDRESS & VOICE ALARM SYSTEM VA-6000RM Thanks for using ITC Digital Network Public Address & Voice Alarm System. For better operation, please read this manual carefully before operating the system.
- Page 2 Digital Network Public Address & Voice Alarm System . Dear Readers Thank you for using ITC fire voice broadcasting system, in order to facilitate your understanding and the manual’s description, suggestion are as follows: The mentioned "Voice information" in the manual includes ...
- Page 3 Digital Network Public Address & Voice Alarm System —It represents that the host is offline. —It indicates that the network is connected. —It represents the host starts the PSTN calling function. —It indicates that MIC is calling. —Green indicates that the module is working. —Yellow indicates module failure.
- Page 4 Digital Network Public Address & Voice Alarm System 4) System equipment VA-6000MA / MS / BC, VA-P8500S are designed specifically for cabinet installation, if you install two or more units on a cabinet, between the device and the device you should set aside the corresponding space for ventilation to maintain good heat dissipation.
- Page 5 Digital Network Public Address & Voice Alarm System 2. Introduction Nowadays the building is higher and higher and the area need to be controlled at the same time is becoming wider and wider. If EVAC System also is designed based on the traditional analog technology, there are problems about signal attenuation from the long-distance, electromagnetic interference between different space, the cost of construction and maintain, the system centralized control and monitor, the data backup, the more redundancy and so on.
- Page 6 Digital Network Public Address & Voice Alarm System 3. PA Microphone —VA-6000RM VA-6000RM can be used in remote control VA-6000 system, can allow user to control system voice information and zone paging, support 8 zones/group selection, and can extended by MIC(VA-6000EM), can maxium add 7 keyboard, every extended keyboard can add 8 zones.
-
Page 7: Front Panel
Digital Network Public Address & Voice Alarm System 3.2 Front panel 1. Gooseneck microphone socket. 2. Fault reset/close partition. 3. All zones selection button. 4. Main power status indication of all devices. OFF- All devices or modules main power supply is normal. ... - Page 8 Digital Network Public Address & Voice Alarm System is faulty. 10. Partition working status indicator and selection button. OFF - Indicates that the current zoning status in the absence of broadcast or is not configured properly. Green - Indicates the current partition is broadcasting, the audio output is ordinary. ...
-
Page 9: Rear Panel
Digital Network Public Address & Voice Alarm System 3.3 Rear panel 1. Networking equipment main and backup interfaces (online interface to the host and the remote MIC on VA-6000MA is connected) 2. Equipment networking address and feature configuration (DIP switch “1, 2” to be device address control bit;... -
Page 10: Technical Specifications
Digital Network Public Address & Voice Alarm System 3.4 Technical Specifications Electric index DC power supply Voltage 24V DC, ±20% Maximum current 0.1A (Not including extension panel) consumption 2.4W (Not including extension panel) Performance index Balanced signal output Distortion <1% (rated output power), 1kHz Frequency response 80Hz~16kHz Sensitivity... - Page 11 4. Business microphone broadcast 4.1 Partition broadcast operation 1) Press ZONE 01 button on the VA-6000RM, a s shown in figure: ZONE 01 2) Press the TALK switch, after the goose rod indicator light, you can broadcast to ZONE 01 (other...
- Page 12 Digital Network Public Address & Voice Alarm System 4.2 All-zone broadcast operations 1) Press ALL CALL button on VA-6000RM, as shown in figure: Under normal circum- stances, press this button to broadcast and call all zones 2) Press the TALK switch, the goose pole indicator will light on, and you can broadcast the whole zones,...
-
Page 13: Block Diagram
Digital Network Public Address & Voice Alarm System 5. Block Diagram - 13 -... - Page 14 Version: 0.2 - 14 -...
