- Page 1 OPERATION MANUAL DIGITAL NETWORK PUBLIC ADDRESS & VOICE ALARM SYSTEM VA-6000FM Thanks for using ITC Digital Network Public Address & Voice Alarm System. For better operation, please read this manual carefully before operating the system.
- Page 2 Digital Network Public Address & Voice Alarm System . Dear Readers Thank you for using ITC fire voice broadcasting system, in order to facilitate your understanding and the manual’s description, suggestion are as follows: The mentioned "Voice information" in the manual includes ...
- Page 3 Digital Network Public Address & Voice Alarm System —It represents that the host is offline. —It indicates that the network is connected. —It represents the host starts the PSTN calling function. —It indicates that MIC is calling. —Green indicates that the module is working. —Yellow indicates module failure.
- Page 4 6) The system does not allow parallel amplifier, which may cause permanent failure. 7) Remote Microphone (VA-6000FM / RM) provides phantom power, real-time testing, please do not turn off the switch at work to avoid system to report failures misjudgment.
- Page 5 Digital Network Public Address & Voice Alarm System 2. Introduction Nowadays the building is higher and higher and the area need to be controlled at the same time is becoming wider and wider. If EVAC System also is designed based on the traditional analog technology, there are problems about signal attenuation from the long-distance, electromagnetic interference between different space, the cost of construction and maintain, the system centralized control and monitor, the data backup, the more redundancy and so on.
- Page 6 Digital Network Public Address & Voice Alarm System 3. Fireman remote MIC—VA-6000FM VA-6000FM is used for remote control of VA-6000 system, it allow user control system voice information and zone paging, support 8 zones/group selection, and can extended by MIC extension unit(VA-6000EM), support max 7 keyboard, every extension keyboard can add 8 zones.
-
Page 7: Front Panel
Digital Network Public Address & Voice Alarm System 3.2 Front panel 1. Handheld PTT(push to talk) MIC. 2. System status indicator(remind: not current MIC status indicator). OFF—All device or module or spare power of the system is normal. Yellow—All devices or module or spare power of the system is failure(all, part or one of them). 3. - Page 8 Digital Network Public Address & Voice Alarm System Green—Alert voice is playing. Yellow—Alert voice file lost or player failure. 11. Alert voice control button. 12. EVAC audio working status indicator. OFF—EVAC audio player and audio files in SD card is normal. ...
-
Page 9: Rear Panel
Digital Network Public Address & Voice Alarm System 28. Zone working status indicator. OFF—There is no broadcasting in this zone or no configuration. Green—This zone is broadcasting, output is normal audio. Red—This zone is broadcasting, output evac voice or remote paging audio like RM/FM/PSTN. ... -
Page 10: Technical Specification
Digital Network Public Address & Voice Alarm System 3.4 Technical specification Electric index Voltage 24V DC, ±20% Max current 0.1 A (including extension panel) Power consumption 2.4W(including extension panel) Performance index Balanced signal output Distortion <1%, 1kHz rated power Frequency response 80Hz~16kHz Sensitivity 500mV... - Page 11 3) Press the fault reset / close button, you can turn off the radio calls, as following: Press the button to turn off the zone’s broadcast and call 4.2 Operation of all-zone broadcast 1) Press the all-zone key on VA-6000FM, such as following pictures: Under normal circumstances, press this button to broadcast and call all zones...
- Page 12 (slow blinking red), while the VA-6000MA host of "Logo standby interface" will activate emergency mode " " icon. 2) Press the VA-6000FM panel, need to play "EVAC emergency voice message" partition / group or all zone keys, as shown: Zoning control buttons All zone control buttons 3) Press the "EVAC or ALERT"...
- Page 13 If need close all zone background music, simply click the all zone button until all of the partition status indicator lights red, press the RESET / OFF button then it close. (Note: same operating methods from VA-6000RM and VA-6000FM) - 13 -...
-
Page 14: Block Diagram
Digital Network Public Address & Voice Alarm System 5. Block Diagram - 14 -... - Page 15 Version: 0.2 - 15 -...
