Sitecom WL-308 Full Manual

Gaming router
Hide thumbs Also See for WL-308:

Advertisement

Quick Links

Download this manual
MARQUE: SITECOM
REFERENCE: RWIFI GAMING WL308
CODIC: 1196235

Advertisement

loading
Need help?

Need help?

Do you have a question about the WL-308 and is the answer not in the manual?

Questions and answers

Related Manuals for Sitecom WL-308

Summary of Contents for Sitecom WL-308

  • Page 1 MARQUE: SITECOM REFERENCE: RWIFI GAMING WL308 CODIC: 1196235...
  • Page 2 WL-308 Gaming Router Full Manual...
  • Page 3 WL-308 Gaming Router Full Manual INTRODUCTION..........................4 & B ..................5 EATURES ENEFITS ..................6 ACKAGE ONTENTS ..................6 AFETY UIDELINES .................... 7 RODUCT AYOUT ....................8 ACK LABEL ..................9 YSTEM EQUIREMENTS UNDERSTANDING THE HARDWARE ................10 .................10 ARDWARE...
  • Page 4 WL-308 Gaming Router Full Manual Firmware............................66 Syslog ..............................66 Administrator Settings ......................... 67 APPENDIX A – SPECIFICATIONS ....................69 ..................69 ARDWARE UMMARY ...................69 ADIO PECIFICATIONS ..................70 OUTER AND ATEWAY ....................71 ANAGEMENT & P ................72 NVIRONMENT HYSICAL APPENDIX B FCC INTERFERENCE STATEMENT ..............73...
  • Page 5 WL-308 Gaming Router Full Manual 1 Introduction The WL-308 is a draft 802.11n compliant device that delivers up to 6x faster speeds than 802.11g while staying backward compatible with 802.11g and 802.11b devices. It is not only a Wireless Access Point, which lets you connect to the network without wires.
  • Page 6 WL-308 Gaming Router Full Manual Features & Benefits Features Benefits High Speed Data Rate Up to Capable of handling heavy data 300Mbps payloads such as MPEG video streaming IEEE 802.11n draft Compliant and Fully interoperable with IEEE backward compatible with 802.11b/g/n devices...
  • Page 7 Open the package carefully, and make sure that none of the items listed below are missing. Do not discard the packing materials; in case of return, the device must be shipped in its original package. One WL-308 Gaming Router One 12V/1.25A Power Adapter Three 3dBi 2.4GHz Dipole Antennas UTP Cable One CD-ROM with User’s Manual...
  • Page 8 WL-308 Gaming Router Full Manual Product Layout Item Label Description LAN Ports (1 – 4) Use an Ethernet cable to connect each port to a computer on your Local Area Network (LAN). Link Port Use an Ethernet cable to connect this port to your WAN router/modem.
  • Page 9 WL-308 Gaming Router Full Manual Back label Item Label Description LAN LED This LED will light up once an Ethernet cable is connected to one of the LAN ports. Link LED This LED will light up once an Ethernet cable is connected to WAN (Internet) port.
  • Page 10 WL-308 Gaming Router Full Manual System Requirements The following are the minimum system requirements in order configure the device: PC/Notebook Operating System – Microsoft Windows XP/2000/VISTA 1 Free Ethernet port Wi-Fi card/USB dongle (802.11 b/g/n) – optional External xDSL (ADSL) or Cable modem with an Ethernet port (RJ-45)
  • Page 11 2 Understanding the Hardware Hardware Installation You can place the WL-308 on a desk or other flat surface, or you can mount it on a wall. For optimal performance, place your Wireless Broadband Router in the center of your office (or your home) in a location that is away from any potential source of interference, such as a metal wall or microwave oven.
  • Page 12 WL-308 Gaming Router Full Manual IP Address Configuration This device can be configured as a Bridge/Router or Access Point. The default IP address of the device is 192.168.0.1. In order to log into this device, you must first configure the TCP/IP settings of your PC/Notebook.
  • Page 13 WL-308 Gaming Router Full Manual 3 Internet Connection Wizard This device offers a quick and simple configuration through the use of a wizard. This chapter describes how to use the wizard to configure the internet settings. Please refer to Chapter 6 in order to configure the more advanced features of the device.
  • Page 14 WL-308 Gaming Router Full Manual Select your country from the Country list. Select your internet provider. Click Next. Depending on the chosen provider, you may need to enter your user name and password, MAC address or hostname in the following window. After you have entered the correct information, click Next.
  • Page 15 WL-308 Gaming Router Full Manual 4 Wi-Fi Protected Setup Wizard Wi-Fi Protected Setup is a feature that locks the wireless security settings and prevents the settings from being changed by any new external registrar using its PIN. Devices can still be added to the wireless network using Wi-Fi Protected Setup.
  • Page 16 WL-308 Gaming Router Full Manual Add a Wireless Device Click on Basic -> Wireless and click on the Add Wireless Device Wizard button. The wireless wizard will inform you that there are two major steps in the process. Select the configuration method for your wireless network Connect your wireless device Click on the Next button to continue.
  • Page 17 WL-308 Gaming Router Full Manual There are several ways to add a wireless device to your network. Access to the wireless network is controlled by a registrar. A registrar only allows devices onto the wireless network if you have entered the PIN, or pressed a special Wi-Fi Protected Setup button on the device.
  • Page 18 WL-308 Gaming Router Full Manual Select the Push Button radio button and then click on the Next button. Press the WPS button on the device (which is located on the left side of the front panel) and then click on the Next button.
  • Page 19 WL-308 Gaming Router Full Manual 5 Advanced Web Configuration Logging In Open a web browser and type in the IP address (default: http://192.168.0.1), the web-browser will display the login page. Fill in the username and password. The default credentials are shown below:...
  • Page 20 WL-308 Gaming Router Full Manual 5.1 Home Device All of your Internet and network connection details are displayed on this page. The firmware version is also displayed here. Wireless Click on the Wireless link in the navigation menu. The wireless section allows you to view the wireless clients that are connected to the device.
  • Page 21 WL-308 Gaming Router Full Manual WISH The WISH Sessions page displays full details of active local wireless sessions through your router when WISH has been enabled. A WISH session is a conversation between a program or application on a wirelessly connected LAN-side computer and another computer, however connected.
  • Page 22 WL-308 Gaming Router Full Manual Logs Click on the Logs link in the navigation menu. The router automatically logs (records) events of possible interest in its internal memory. If there is not enough internal memory for all events, logs of older events are deleted, but logs of the latest events are retained.
  • Page 23 WL-308 Gaming Router Full Manual Stats Click on the Statistics link in the navigation menu. This page displays the transmitted and received packet statistics of the wired (LAN & WAN) and wireless interface. Click on the Refresh button to refresh the statistics.
  • Page 24 WL-308 Gaming Router Full Manual DHCP Click on the DHCP link in the navigation menu. This page displays the routing details configured for your router. Local: The IP address and, where appropriate, port number of the local application. NAT: The port number of the LAN-side application as viewed by the WAN-side application.
  • Page 25 WL-308 Gaming Router Full Manual 5.2 BASIC Network This device can be configured as a Router or a Bridge. Select Router mode if the WAN port is connected to the Internet. Select Bridge if the device is connected to a local network downstream from another router.
  • Page 26 WL-308 Gaming Router Full Manual Router Mode In this mode, the device functions as a NAT router and is connected to the Internet. Select the Router Mode radio button. WAN Port Mode: Select the Router Mode radio button. Router IP Address: Specify the IP address of this device.
  • Page 27 WL-308 Gaming Router Full Manual Wireless These options allow you to enable/disable the wireless interface, switch between the 11n, 11b/g and 11b radio band and channel frequency Enable Wireless: Place a check in this box to enable the wireless interface.
  • Page 28 WL-308 Gaming Router Full Manual encryption then they could connect to your network. When Invisible mode is enabled, you must enter the Wireless Network Name (SSID) on the client manually to connect to the network. Click on the Apply button to store these settings.
  • Page 29 WL-308 Gaming Router Full Manual Authentication: Select Open, or Shared Key. Authentication method from the drop-down list. An open system allows any client to authenticate as long as it conforms to any MAC address filter policies that may have been set. All authentication packets are transmitted without encryption.
  • Page 30 WL-308 Gaming Router Full Manual TKIP. Use TKIP only. TKIP (Temporal Key Integrity Protocol) provides per-packet key generation and is based on WEP. AES. Use AES only. AES (Advanced Encryption Standard) is a very secure block based encryption. Note that, if the bridge uses the AES option, the bridge can associate with the access point only if the access point is also set to use only AES.
  • Page 31 WL-308 Gaming Router Full Manual TKIP. Use TKIP only. TKIP (Temporal Key Integrity Protocol) provides per-packet key generation and is based on WEP. AES. Use AES only. AES (Advanced Encryption Standard) is a very secure block based encryption. Note that, if the bridge uses the AES option, the bridge can associate with the access point only if the access point is also set to use only AES.
  • Page 32 WL-308 Gaming Router Full Manual The device offers several types of WAN connections in order to connect to the Internet. Static IP Address Dynamic IP Address PPPoE PPTP Select the type of Internet Connection from the drop-down list.
  • Page 33 WL-308 Gaming Router Full Manual Static IP Address Configuration The WAN interface can be configured as Static IP address. In this type of connection, your ISP provides you with a dedicated IP address (which does not change as DHCP). Select Static IP from the My Internet Connection drop-down list.
  • Page 34 WL-308 Gaming Router Full Manual MTU: The Maximum Transmission Unit (MTU) is a parameter that determines the largest packet size (in bytes) that the router will send to the WAN. If LAN devices send larger packets, the router will break them into smaller packets.
  • Page 35 WL-308 Gaming Router Full Manual Dynamic IP Address (DHCP) Configuration The WAN interface can be configured as a DHCP Client in which the ISP provides the IP address to the device. This is also known as Dynamic IP. Select the Dynamic IP (DHCP) from the My Internet Connection drop-down list.
  • Page 36 WL-308 Gaming Router Full Manual Primary / Secondary DNS Address: Specify the primary and secondary IP address, which are assigned by your ISP. MTU: The Maximum Transmission Unit (MTU) is a parameter that determines the largest packet size (in bytes) that the router will send to the WAN. If LAN devices send larger packets, the router will break them into smaller packets.
  • Page 37 WL-308 Gaming Router Full Manual PPPoE (Point-to-Point Protocol over Ethernet) The WAN interface can be configured as PPPoE. This type of connection is usually used for a DSL service and requires a username and password to connect. Select the PPPoE from the My Internet Connection drop-down list.
  • Page 38 WL-308 Gaming Router Full Manual is made as needed), Manual: You have to open up the Web-based management interface and click the Connect button manually any time that you wish to connect to the Internet. Maximum Idle Time: Specify the time after which the router will automatically disconnect the current session when no data-traffic has been detected for the set period of time.
  • Page 39 WL-308 Gaming Router Full Manual PPTP (Point-to-Point Tunneling Protocol) The WAN interface can be configured as PPTP. PPTP (Point to Point Tunneling Protocol) uses a virtual private network to connect to your ISP. This method of connection is primarily used in Europe. This method of connection requires you to enter a username and password (provided by your ISP) to gain access to the Internet.
  • Page 40 WL-308 Gaming Router Full Manual PPTP Gateway IP Address: Specify the IP address of the PPTP gateway. PPTP Server IP Address: If the PPTP Server’s IP address is different from the default gateway, then you may specify it here. User Name: Specify the user name which is provided by your ISP.
  • Page 41 WL-308 Gaming Router Full Manual Advanced Wireless This page allows you to configure the fragmentation threshold, RTS threshold, beacon period, transmit power, DTIM interval, wireless isolation, WMM and WDS (wireless distribution system). Transmit Power: You may control the output power of the device by selecting a value from the drop-down list.
  • Page 42 WL-308 Gaming Router Full Manual WDS: Place a check in this box to enable WDS (Wireless Distribution System). When WDS is enabled, this access point functions as a wireless repeater and is able to wirelessly communicate with other APs via WDS links.
  • Page 43 WL-308 Gaming Router Full Manual WAN Port Speed: You may select a WAN port speed from the drop-down list. It is recommended that you select Auto. Enable Multicast Streams: Place a check in this box to enable multicast streams. The router uses the IGMP protocol to support efficient multicasting - - transmission of identical content, such as multimedia, from a source to a number of recipients.
  • Page 44 WL-308 Gaming Router Full Manual 5.3 Firewall Virtual Server The Virtual Server option gives Internet users access to services on your LAN. This feature is useful for hosting online services such as FTP, Web, or game servers. For each Virtual Server, you define a public port on your router for redirection to an internal LAN IP Address and LAN port.
  • Page 45 WL-308 Gaming Router Full Manual Special Application An application rule is used to open single or multiple ports on your router when the router senses data sent to the Internet on a trigger port or port range. An application rule applies to all computers on your internal network.
  • Page 46 WL-308 Gaming Router Full Manual Portort Forwarding Multiple connections are required by some applications, such as internet games, video conferencing, Internet telephony, and others. These applications have difficulties working through NAT (Network Address Translation). This section is used to open multiple ports or a range of ports in your router and redirect data through those ports to a single PC on your network.
  • Page 47 WL-308 Gaming Router Full Manual Access Control The Access Control section allows you to control access in and out of devices on your network. Use this feature as Parental Controls to only grant access to approved sites, limit web access based on time or dates, and/or block access from applications such as peer-to-peer utilities or games.
  • Page 48 WL-308 Gaming Router Full Manual Select a schedule from the drop-down list: Always or Never, or you may define a new schedule. Click on the Next button to continue. Select a machine to which the policy applies. Address Type: Select the IP address or MAC address radio button.
  • Page 49 WL-308 Gaming Router Full Manual Select a filtering method: Log Web Access Only: Select this radio but in order to log web access. Block All Access: Select this radio but in order to block all web access. Block Some Access: Select this radio but in order to block some web access.
  • Page 50 WL-308 Gaming Router Full Manual Website Filter This is a type of parental control feature used to restrict certain websites form being accessed through your network. These filters can be used for securing and restricting your network. Website/URL/Domain: Specify the web address that you would like to filter.
  • Page 51 WL-308 Gaming Router Full Manual Schedules Click on the Schedules link in the navigation menu. Schedules can be created for use with enforcing rules. For example, if you want to restrict web access to Mon-Fri from 3pm to 8pm, you could create a schedule selecting Mon, Tue, Wed, Thu, and Fri and enter a Start Time of 3pm and End Time of 8pm.
  • Page 52 WL-308 Gaming Router Full Manual 5.4 Advanced Settings Dynamic DNS The Dynamic DNS feature allows you to host a server (Web, FTP, Game Server, etc.) using a domain name that you have purchased with your dynamically assigned IP address. Most broadband Internet Service Providers assign dynamic (changing) IP addresses.
  • Page 53 WL-308 Gaming Router Full Manual StreamEngine The StreamEngine feature helps improve the network performance by prioritizing applications. Enable Traffic Shaping: Place a check in the box to enable traffic shaping. When this option is enabled, the router restricts the flow of outbound traffic so as not to exceed the WAN uplink bandwidth.
  • Page 54 WL-308 Gaming Router Full Manual Click on the Apply button to store these settings. Routing This section adds a new entry into the routing table. Enable: Place a check in this box to enable the routing table entry. Name: Specify a name for the rule.
  • Page 55 WL-308 Gaming Router Full Manual MAC Address Filter This feature is used to restrict certain MAC address from accessing the Internet. These filters can be used for securing and restricting your network. Configure MAC Filtering: Select one of the options from the drop-down list.
  • Page 56 WL-308 Gaming Router Full Manual Firewall Settings The device provides a tight firewall by virtue of the way NAT works. Unless you configure the router to the contrary, the NAT does not respond to unsolicited incoming requests on any port, thereby making your LAN invisible to Internet cyber attacks.
  • Page 57 WL-308 Gaming Router Full Manual application to send data back through a port different from the one used when the outgoing session was created. Port And Address Restricted The NAT does not forward any incoming connection requests with the same port address as an already establish connection.
  • Page 58 WL-308 Gaming Router Full Manual Non-UDP/TCP/ICMP LAN Sessions: Place a check in this box to enable this feature. When a LAN application that uses a protocol other than UDP, TCP, or ICMP initiates a session to the Internet, the router's NAT can track such a session, even though it does not recognize the protocol.
  • Page 59 WL-308 Gaming Router Full Manual IPSec: (VPN) Allows multiple VPN clients to connect to their corporate networks using IPSec. Some VPN clients support traversal of IPSec through NAT. This option may interfere with the operation of such VPN clients. If you are having trouble connecting with your corporate network, try disabling this option.
  • Page 60 WL-308 Gaming Router Full Manual WISH WISH is short for Wireless Intelligent Stream Handling, a technology developed to enhance your experience of using a wireless network by prioritizing the traffic of different applications. Enable WISH: Place a check in this box to enable the WISH feature.
  • Page 61 WL-308 Gaming Router Full Manual Enable: Place a check in this box to enable the WISH rule. A WISH Rule identifies a specific message flow and assigns a priority to that flow. For most applications, the priority classifiers ensure the right priorities and specific WISH Rules are not required.
  • Page 62 WL-308 Gaming Router Full Manual Inbound Filter When you use the Virtual Server, Port Forwarding, or Remote Administration features to open specific ports to traffic from the Internet, you could be increasing the exposure of your LAN to cyber attacks from the Internet. In these...
  • Page 63 WL-308 Gaming Router Full Manual 5.5 Toolbox Time Configuration Click on the Time link in the navigation menu. This feature allows you to configure, update, and maintain the correct time on the device’s internal system clock as well as configure the time zone. The date and time of the device can be configured manually or by synchronizing with a time server.
  • Page 64 WL-308 Gaming Router Full Manual Set the Date and Time: Select a date and time from the drop-down list or do to use computer’s time and date click on the Copy Your Computer’s Time Settings button. Click on the Apply button once you have modified the settings.
  • Page 65 WL-308 Gaming Router Full Manual This option allows you to restore a backup configuration from a file to the device. Click on the Browse button to select the file and then click on Restore Configuration from a File button. The system then prompts you to reboot the device.
  • Page 66 WL-308 Gaming Router Full Manual Please wait while the system is rebooting. Note: Do no un-plug the device during this process as this may cause permanent damage. Reboot The Device Click on the Reboot the Device button to reboot the device using its current settings.
  • Page 67 WL-308 Gaming Router Full Manual Firmware Click on the Firmware link in the navigation menu. This page allows you to upgrade the firmware of the device in order to improve the functionality and performance. This page also displays the current firmware version and its release date.
  • Page 68 WL-308 Gaming Router Full Manual Enable Logging to a Syslog Server: Place a check in this box to enable Syslog logging. Syslog Server IP Address: Specify the IP address of the Syslog server. Click on the Apply button once you have modified the settings.
  • Page 69 WL-308 Gaming Router Full Manual System Name Gateway Name: Name of your router. Remote Management The remote management function allows you to configure the Broadband router from a remote site. Inactivity Time Out: Time after which you will be automatically logged out of the web-interface.
  • Page 70 WL-308 Gaming Router Full Manual Appendix A – Specifications Hardware Summary Physical WAN: One 10/100/1000 Gigabit RJ-45 Interface LAN: Four 10/100/1000 Gigabit RJ-45 Reset Button (1 second for Reboot, 5 second for Reset to Factory Default ) Power Jack JTAG (for debug only)
  • Page 71 WL-308 Gaming Router Full Manual 19 dBm @6Mbps 16 dBm @54Mbps 2.412~2.472G(IEEE802.11N) 20 dBm MCS 8 16 dBm MCS 15 Antenna Gain Peak Gain = 2 dBi Average Gain = 1.08 dBi (@ 2.45GHz, H-Plan) Router and Gateway Topology Infrastructure...
  • Page 72 WL-308 Gaming Router Full Manual SPI (Stateful Packet Inspection) Rule Based (IP Address Ranges, Port Ranges & Schedule) DMZ (Demilitarized Zone) Host Policy Based Parental Controls Time Based Internet Access Port Range / Service Filtering Internet Domain Restriction Dynamic URL Filtering (OEM...
  • Page 73 WL-308 Gaming Router Full Manual monitoring Log, Email Alarm Environment & Physical Temperature 0 to 50° C (32 °F to 122 °F) - Operating Range -40 to 70 ° C(-40 °F to158 °F) - Storage Humidity (non- 15%～95% typical condensing)
  • Page 74 WL-308 Gaming Router Full Manual Appendix B FCC Interference Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
