Operating instructions
Heat-pump dryer
To avoid the risk of accidents or damage to the appliance it is essen-
tial to read these instructions before it is installed and used for the
first time.
en-GB, IE
M.-Nr. 12 701 550

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TQ 1000 WP and is the answer not in the manual?

Questions and answers

Related Manuals for Miele TQ 1000 WP

Summary of Contents for Miele TQ 1000 WP

  • Page 1 Operating instructions Heat-pump dryer To avoid the risk of accidents or damage to the appliance it is essen- tial to read these instructions before it is installed and used for the first time. en-GB, IE M.-Nr. 12 701 550...

  • Page 2: Table Of Contents

    Contents Warnings and safety instructions ................Sustainability and environmental protection............14 Disposal of fluff or accessories ..................14 Perfect use of energy and time ..................15 Reusing condensed water..................... 16 Energy-saving heat-pump technology................. 16 Familiarisation........................ 17 Your tumble dryer ......................17 Control panel........................
  • Page 3 Contents Timed drying........................28 Programme modifications after starting the programme......... 29 Moving a programme..................... 29  Favourites ........................30 Using the condensate container .................. 31 Using the FragranceDos fragrance system ..............33 Programmes ........................37 Programme chart......................37 Extras..........................47 Consumption data......................48 Consumption data......................
  • Page 4 Contents Cleaning and care ......................60 Cleaning the casing, drum and control panel............. 60 Cleaning the fluff filters ....................60 Cleaning the residual moisture sensor................ 62 Cleaning the plinth filter ....................63 Cleaning the rubber seal on the condensate container..........67 Troubleshooting......................

  • Page 5: Correct Application

    Miele cannot be held liable for damage caused by non-compliance with these instructions. Keep these operating instructions in a safe place and pass them on to any future owner.

  • Page 6: Safety With Children

    If using dry cleaning kits, do so at your own risk, and follow the instructions provided on the packaging. Any other applications may be dangerous. Miele cannot be held liable for damage resulting from incorrect or improper use or operation. ...
  • Page 7 It is essential that this standard safety re- quirement is met. If in any doubt, please have the household wiring system tested by a qualified electrician. Miele cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).
  • Page 8 This special lamp must only be used for the purpose it is intended for. It is not suitable for room light- ing. Replacement lamps may only be fitted by a Miele authorised per- son or the Miele Service Department.

  • Page 9: Correct Use

    Warnings and safety instructions Correct use The maximum dry laundry load size is 9 kg.  The maximum recommended load sizes for individual programmes are given in “Programmes”. Risk of fire due to an unauthorised electrical installation.  This tumble dryer must not be connected to a controllable socket. This includes clocks/timers or electrical systems with peak-load ne- gotiation.
  • Page 10 Warnings and safety instructions cleaned, there is a danger that they might ignite when heated, even after they have been removed from the tumble dryer at the end of the programme - Accumulations of inflammable cleaning agents or residues of acet- one, alcohol, petrol, kerosene, stain remover, turpentine, wax, wax remover or chemicals in general.
  • Page 11 Warnings and safety instructions There is a risk of injury from electric shock and the tumble dryer  may become defective. To prevent water from penetrating, do not spray-wash or hose down the tumble dryer. Risk of injury if the tumble dryer tips over. For this reason, do not ...
  • Page 12 Eyes may become irritated, injured or show signs of poisoning. Seek medical attention immediately if the fragrance comes in con- tact with the eyes or is swallowed. Only use genuine Miele original fragrance flacons.  The fragrance flacon must be stored in its packaging so please ...

  • Page 13: Accessories And Spare Parts

     If you order a plinth for this tumble dryer (available from Miele as an optional accessory - depending on country), make sure it is the correct one.

  • Page 14: Sustainability And Environmental Protection

    Sustainability and environmental protection with Miele, free of charge. By law, you Disposing of the packaging ma- are solely responsible for deleting any terial personal data from the old appliance The packaging material is used for hand- prior to disposal. You are legally obliged...

  • Page 15: Perfect Use Of Energy And Time

    Sustainability and environmental protection Perfect use of energy and time Spin the laundry thoroughly in the wash- ing machine. The electricity consump- tion and the programme running time is reduced during drying because it takes less time to dry the laundry. To spin the laundry at a harder level, select a max- imum spin speed when washing.

  • Page 16: Reusing Condensed Water

    Sustainability and environmental protection Reusing condensed water Energy-saving heat-pump tech- nology Condensed water from the drying pro- cess is collected in the condensate con- A compressor is used to compress refri- tainer and reused for the SteamCare. gerant and raise the temperature in a closed cooling circuit in an energy-effi- Condensed water can be used for iron- cient manner.

  • Page 17: Familiarisation

    Familiarisation Your tumble dryer          a Mains connection cable f Opening tag b Control panel g Fluff filter c Condensate container h Holder with plinth filter d Tumble dryer door i Cooling fan e Plinth flap...

  • Page 18: Control Panel

    Familiarisation Control panel     a  On/Off switch b Optical interface (for Customer Service) c Movement sensor (MotionReact) d Display Main menu in display       a Side trim b Programmes c Name of the highlighted programme d Parameters for the programme e Start f Other parameters...

  • Page 19: Symbols In The Display

    Familiarisation Symbols in the display Operation Various different symbols are used on Switching the tumble dryer on or off the display. The  On/Off switch is recessed.  Menu  Press the  On/Off switch until the tumble dryer switches on or off. ...

  • Page 20: Network Connection

    (e.g. Extras) or adjust them on a scale tegrated WiFi module. The WiFi module (e.g. the Duration). makes it possible to connect to your home network and to use the Miele app Switching parameters on or off on a mobile device. Activated parameters are highlighted in Networking the tumble dryer allows you colour.

  • Page 21: Comfortopen

    Familiarisation Depending on the operating status of PerfectDry the tumble dryer, you can trigger various PerfectDry dries the laundry precisely, actions using the movement sensor although the result is also influenced by such as switching on the tumble dryer the calcium content of the water used or switching off the buzzers.

  • Page 22: Steamcare

    Miele Services. The condensate container must be The washing machine transfers the pro- emptied regularly, otherwise the drying gramme data to the Miele Cloud at the programme will stop. end of the programme. Tip: You no longer need to empty the...

  • Page 23: Commissioning

    Before commissioning the tumble Have the WiFi password ready. dryer for the first time, make sure it 2. The Miele app is available on a mo- has been installed correctly. Perform bile device. the installation correctly. Please fol- 3.

  • Page 24: Operation

    Operation Via the app Operating sequence 1. Preparing the laundry We recommend the operating se- 2. Switching on the tumble dryer quence listed below which is custom- ised to your tumble dryer. This allows 3. Loading the laundry you to perfectly use all the special fea- 4.

  • Page 25: Preparing The Laundry

    Operation  Remove any remaining items and ob- Preparing the laundry jects that have been left inside the Prepare the laundry as described in drum. “Good to know”. Damage due to objects which were not removed from the laundry. Otherwise textiles or the tumble dryer may be damaged.

  • Page 26: Selecting A Programme

    Operation Closing the door The selectable Drying levels are indic- ated by symbols, such as  (Cupboard Dry) or  (Hand iron). Selecting the duration For some programmes such as Warm air or Basket programme, you can se- lect Duration. ...

  • Page 27: Starting A Programme

    Operation Removing the laundry Starting a programme  Select  Start. The programme starts and the time left is displayed in hours and minutes. The programme running time can vary depending on various factors such as residual moisture, load size and the mix of textiles.

  • Page 28: Special Features For Operation Via App

    Operation  Change the delay start and select  Special features for operation Confirm. via app Deleting delay start Loading the laundry A delay start that has been started can  Open the door. be deleted.  Load the laundry. ...

  • Page 29: Programme Modifications After Starting The Programme

    Operation  Drag the programme to the required Programme modifications after place. starting the programme  Confirm with . Changing programmes The change will be saved. To protect against unintentional changes, it is not possible to change the programme after the programme has started.

  • Page 30: Favourites

    Operation  Move your finger on the display until  Favourites the required Favourite lights up. You can save up to 12 programmes as  Touch the  Other parameters sym- favourites. You can change the pro- bol. gramme name and certain parameters for your Favourite programmes.

  • Page 31: Using The Condensate Container

    Operation Emptying the condensate container Using the condensate container Interval: empty the condensate con- Pulling out the condensate container tainer after drying.  Damage to the dryer door and the condensate container. Damage and scratches may occur. First close the dryer door and then pull out the condensate container.
  • Page 32 Operation Preparing the condensate container The nozzle can clog up. for SteamCare It should only be filled with clean The condensate container must be filled condensed water. The water must up to the mark ―min―. not contain any fragrance, detergent or other substances.

  • Page 33: Using The Fragrancedos Fragrance System

    Operation FragranceDos sockets Using the FragranceDos fra- grance system There are 2 sockets in the fluff filter. Removing the protective seal from the fragrance flacon  Risk of fire if fragrance flacons are used incorrectly. Leaked fragrance can cause fire. Before using a fragrance flacon, please read “Warnings and safety notes”, “Using the fragrance flacon...
  • Page 34 Operation Inserting the fragrance flacon Controlling the fragrance intensity  Insert the fragrance flacon as far it  To adjust the fragrance intensity, turn will go into the FragranceDos socket. the outer ring to the right. - The further you open the fragrance flacon, the more intense the fragrance.
  • Page 35 Operation Closing the fragrance flacon Removing the fragrance flacon After drying, the fragrance flacon should be closed to prevent the fragrance from escaping needlessly.  Turn the outer ring anti-clockwise a little. The marking b is located at the a posi-  Turn the outer ring anti-clockwise a tion.
  • Page 36 Operation Storing the fragrance flacon - Store the fragrance flacon in the ori- ginal packaging in a cool, dry place. - Do not expose the fragrance flacon to direct sunlight. - When purchasing new fragrance flac- ons, only remove the protective seal just before use.

  • Page 37: Programmes

    Programmes Programme chart Load: specifications refer to the weight of the dry laundry. Wash2Dry The programme is selected automatically in conjunction with the programme se- lection on the connected washing machine. Cottons Load 9 kg Use for Cotton items such as those described under Cottons Normal with normal residual moisture - This programme is the most energy-efficient for drying cotton items with normal residual moisture levels.
  • Page 38 Programmes Load 9 kg Use for Cotton items such as those described under Cottons Normal with normal residual moisture - This programme is the most energy-efficient for drying cotton items with normal residual moisture levels. - In this programme, the Normal degree of dryness is achieved. Note for test institutes (Valid until 30 June 2025 in accordance with regulations, EU only) - The ECO programme is the test programme in accordance with Regulations...
  • Page 39 Programmes Cottons Drying levels HygieneDry, Extra dry, Cupboard Dry plus, Cupboard Dry, Hand iron plus, Hand iron Load 9 kg and only 4.5 kg for HygieneDry Use for HygieneDry - Cottons and linen fabric which will be in direct contact with the skin, e.g. underwear, baby clothes, bed linen, towelling - Hard-wearing fabrics with the  care symbol on the care label Extra dry, Cupboard Dry plus, Cupboard Dry - T-shirts, workwear, jackets, blankets, aprons, smocks...
  • Page 40 Woollens programme. Instead, dry them in the Basket programme programme with the Miele dryer basket. Alternatively, you can leave woollen gar- ments to air dry flat. Shirts/Blouses Drying levels Cupboard Dry plus, Cupboard Dry, Hand iron plus, Hand iron Load 2 kg...
  • Page 41 Programmes PowerFresh Drying levels Cupboard Dry, Hand iron plus Load 1 kg Use for Washed, damp textiles - For freshening up and smoothing with steam - Use the DryFresh fragrance flacon (optional accessories). - Insert the DryFresh fragrance flacon and adjust the fragrance in- tensity: see “Operation –...
  • Page 42 Programmes Denim Drying levels HygieneDry, Extra dry, Cupboard Dry plus, Cupboard Dry, Hand iron plus, Hand iron Load 3 kg Use for Denim garments, e.g. jeans, jackets, shirts, skirts - Close any zips or do up buttons. - Do not cancel HygieneDry. Otherwise the hygienic drying result will not be achieved.
  • Page 43 Programmes Sportswear Drying levels Cupboard Dry plus, Cupboard Dry, Hand iron plus, Hand iron Load 3 kg Use for Sportswear such as singlets and leggings as well as microfibre and fleece garments Extras DryCare 40, Quick, Energy saving, Pre-ironing, SingleDry, Extra- Quiet, Buzzer Express Drying levels Extra dry, Cupboard Dry plus, Cupboard Dry, Hand iron plus, Hand iron...
  • Page 44 Programmes Woollens handcare Load 1 kg Use for Woollen garments and fabric containing wool blends, e.g. pullovers, cardigans, socks/tights - Wool and wool blend items contain a finish and are only fluffed up; they are not dried completely. - Remove the laundry at the end of the programme and spread the individual items out to dry.
  • Page 45 Programmes QuickHygiene Load 4 kg Use for - Hard-wearing fabrics with the  care symbol on the care label - Cottons and linen fabric which will be in direct contact with the skin, e.g. underwear, baby clothes, bed linen, towelling - Also suitable for clean, dry laundry - Longer temperature holding time with a constant temperature.
  • Page 46 Programmes Basket programme Load 3.5 kg basket load Use for Items suitable for tumble drying for which mechanical stress should be avoided. - This programme may only be used with the dryer basket (op- tional accessory). - Follow the operating instructions supplied with the dryer basket. Cool air Load 9 kg...

  • Page 47: Extras

    Programmes SingleDry Extras A small number of individual textiles can Pre-ironing be dried in a short time (PowerDry). Clean, damp laundry is smoothed by Maximum load: 1 kg steam. Save energy Maximum load: 1 kg Energy savings during longer drying pro- The condensate container must be grammes.

  • Page 48: Consumption Data

    Programmes Consumption data Consumption data in accordance with Regulations 932/2012/EU and 392/2012/EU only valid for GB Load size Final spin speed in Residual Energy Running washing machine moisture time Cottons 1000 1.44 1000 0.75 Cottons Normal 1200 1.30 1400 1.25 1600 1.10 Cottons Hand iron...

  • Page 49: Consumption Data

    Programmes Consumption data Consumption data in accordance with Regulations 932/2012/EU and 392/2012/ EU valid until 30 June 2025 Load size Final spin speed in Residual Energy Running washing machine moisture time 1000 1.44 1000 0.75 Cottons Normal 1200 1.30 1400 1.25 1600 1.10...

  • Page 50: Consumption Data

    Programmes Consumption data Consumption data in accordance with Regulations (EU) 2023/2533 and (EU) 2023/2534 valid from 1 July 2025 Final moisture content after dry- Programmes Load size Running time Energy h:min 3:51 1,44 2:12 0,75 Cottons 3:30 1,72 Extra dry 2:10 1,00 Cottons...
  • Page 51 392/2012 is valid for GB. Data sheet for household tumble driers In acc. with delegated regulation (EU) No. 392/2012 MIELE Model name/identifier TQ 1000 WP Nova Edi- tion Rated capacity 9,0 kg Type of tumble drier (Air-vented / condenser) - / ●...
  • Page 52 Programmes based on 160 drying cycles of the standard cotton programme at full and partial load, and the con- sumption of the low-power modes. Actual energy consumption per cycle will depend on how the ap- pliance is used. If the household tumble drier is equipped with a power management system. This programme is suitable for drying normal wet cotton laundry and is the most efficient programme in terms of energy consumption for cotton.

  • Page 53: Good To Know

    Good to know Inadequately spun laundry increases  Risk of fire due to incorrect use the tumble dryer’s energy consump- and operation. tion and programme running time. A The laundry can burn and destroy the fault may occur. tumble dryer and the surroundings. See the section on “Warnings and - Select a maximum spin speed for safety notes”...

  • Page 54: Protecting Tumble Dryers

    Good to know Protecting tumble dryers Pure linen fabric must be labelled as suitable for tumble drying. To prevent the tumble dryer from being damaged, check that the textiles are in - If in doubt, use the Smoothing pro- perfect condition. gramme.
  • Page 55 Good to know The right delay start The right programme For some programmes, such as the Follow the instructions in “Pro- Warm air programme, you can select a grammes”. You will also find tips on se- time. lecting the right programme. Tip: Do not select the longest drying Selecting the correct drying level time to start with.

  • Page 56: Adjusting Settings

    Adjusting settings Settings overview Appliance functions  Memory  Settings: overview ComfortOpen * Follow the instructions on the Anti-crease  display. Anti-crease General  Duration  Software update  0:30  2:00 h Language  * Drying levels  Date & Time  * Automatic Brightness ...

  • Page 57: General

    Networking. machine from being used unintention- ally. Networking allows you to operate your appliance using the Miele app or ex- - Set up ternal voice assistant, as well as to up- You are prompted to select an input date the software.

  • Page 58: Remote Control

    You are only able to operate your appli- from damper (left) to drier (right), which ance via the Miele app or external voice affects the programme running time and assistants if the Remote control setting energy consumption.

  • Page 59: Information

    Copyrights and licences for operator You can set whether Miele Customer and control software Service should gain access to the soft- Miele uses their own and third party ware for servicing purposes. software which is not subject to any so- Remote Access...

  • Page 60: Cleaning And Care

    Cleaning and care Cleaning the casing, drum and Environmental impact due to fluff control panel which has been disposed of incor- rectly.  Risk of electric shock from mains To prevent microplastics from voltage. spreading into the waste water sys- The mains voltage is applied to the tem, fluff must not be drained away tumble dryer even if it is switched off.
  • Page 61 Cleaning and care Removing the upper fluff filter  Open the tumble dryer door.  Use a damp cloth to remove any fluff .  Remove the fluff .  Pull the fluff filter out. Tip: Alternatively, use a vacuum cleaner Removing the fluff with a dusting brush.

  • Page 62: Cleaning The Residual Moisture Sensor

    Cleaning and care Cleaning the residual moisture sensor The residual moisture sensor in the tumble dryer measures the residual laundry moisture to improve the drying results. When to clean Clean the residual moisture sensor once or twice a year with a soft cloth. Fault when measuring the residual moisture.

  • Page 63: Cleaning The Plinth Filter

    Cleaning and care Cleaning the plinth filter The plinth flap can break off. Do not place anything on the plinth Environmental impact due to fluff flap when it is open. which has been disposed of incor- rectly. Removing the holder with plinth filter To prevent microplastics from spreading into the waste water sys- tem, fluff must not be drained away...
  • Page 64 Cleaning and care A fastening element (arrow) is activated when the holder is pulled out. The Tip: To speed up the removal of residue fastening element prevents the plinth from the surface, run a water jet vertic- flap from closing without the holder in- ally over the front of the plinth filter.
  • Page 65 Cleaning and care  Carefully squeeze the plinth filter with Cleaning the edges in front of the heat the back of your hand until all of the exchanger water has been removed. Tip: To soak up water, place the damp plinth filter between 2 hand towels.
  • Page 66 Cleaning and care Inserting the holder and plinth filter  Faults caused by a dripping plinth filter. A dripping plinth filter can cause op- erational faults while drying. Carefully squeeze the water out of the plinth filter several times.  Slide the holder into place by the handle.

  • Page 67: Cleaning The Rubber Seal On The Condensate Container

    Cleaning and care Closing the plinth flap  Close the plinth flap. Cleaning the rubber seal on the condensate container Cleaning recommendation: Clean once or twice a year and as re- quired.  Use a damp cleaning cloth and a small amount of soapy water to care- fully remove any residues from the rubber seal ...

  • Page 68: Troubleshooting

    You can save time and money in many cases, as you do not need to call the Miele Customer Service Department. Information to help you remedy faults yourself can be found at www.miele.com/ service. The following tables are designed to help you to find the cause of a malfunction or a fault and to resolve it.

  • Page 69: Display Information

    Troubleshooting Message Cause and remedy Fault F66 • Airways Fluff or detergent residues have clogged the fluff fil- ters and the plinth filter.  To switch off the message, you must switch off the tumble dryer and switch it on again after a short while.
  • Page 70 Troubleshooting Message Cause and remedy Drying level changed The drying level you selected previously cannot be combined with the extra option. The closest possible drying level is selected automatically. Clean the fluff and plinth The tumble dryer is not working correctly or econom- filters ically.

  • Page 71: The Drying Programme Takes A Long Time

    Troubleshooting The drying programme takes a long time Problem Cause and remedy The drying programme This can be caused by many factors. takes a very long time.  Switch the tumble dryer off.  Check for the possible causes described below. ...

  • Page 72: Noises And Odours

    Troubleshooting Problem Cause and remedy The laundry is still damp. There is too much laundry in the drum or it has be- come tangled.  Disentangle the laundry and remove a few items. The load consisted of different types of fabric. ...

  • Page 73: Other Problems

    Troubleshooting Problem Cause and remedy Laundry or feather-filled The natural properties of feathers or grease residues pillows smell unpleas- cause odours to develop. ant. The laundry was washed with insufficient detergent.  Use FragranceDos.  Take pillows out of the tumble dryer and air them. ...
  • Page 74 Troubleshooting Problem Cause and remedy The fluff filters are visibly Detergent residues can cause incrustations and clog clogged or blocked. the fluff filters.  Rinse the fluff filters under running water. See “Troubleshooting – Cleaning the fluff filters with wa- ter”.
  • Page 75 The drum lighting is designed to last a long time and should not normally need to be replaced.  If you have tried everything but the drum lighting still does not come on, contact the Miele Customer Ser- vice Department. Defective drum lighting can only be replaced by the...

  • Page 76: Signs Of Wear On The Plinth Filter

    Troubleshooting Poor fit and deformations Signs of wear on the plinth filter Poor fit and deformations are clear If the plinth filter shows signs of wear, signs of wear. As a result, the edges of it must be replaced. the plinth filter are no longer posi- tioned correctly in the tumble dryer.
  • Page 77 Troubleshooting Cracks, tears, indentations Cracks and tears are clear signs of wear. Discolouration and incrustations are particu- larly visible on the side edges. Tip: Reactivate the plinth filter in the washing machine. If reactivating does not improve the situation, you will need to replace the plinth filter.

  • Page 78: Reactivating The Plinth Filter

    Troubleshooting Reactivating the plinth filter Checking the heat exchanger Tip: To reprocess the clogged plinth fil- The heat exchanger can become ter, you can reactivate the plinth filter in clogged if the plinth filter shows signs the washing machine. of wear. First check the plinth filter for signs of ...

  • Page 79: Cleaning The Fluff Filters With Water

    Troubleshooting Removing the lower fluff filter Cleaning the fluff filters with water Only remove the fluff filter when neces- sary. Rinse the fluff filters under running wa- ter: Try out which of the following removal options works best. - If the programme running time is increased excessively.

  • Page 80: Cleaning The Fluff Filter In The Condensate Container

    Troubleshooting Checking the airways Inserting the upper fluff filter Check the airways on a regular basis. A large build-up of fluff is a sign that the fluff filters are damaged. The drying time may be extended and the tumble dryer may be damaged. Replace the fluff filters if they are damaged.

  • Page 81: Replacing The Nozzle For Steamcare

    Troubleshooting Pulling out the condensate container  Damage to the dryer door and the condensate container. Damage and scratches may occur. First close the dryer door and then pull out the condensate container.  Hold the hose firmly. The hose may come loose. Do not pull on the hose.
  • Page 82 Troubleshooting  Attach the tool to the nozzle.  Using the wrong tool can cause damage. Doing so can damage the nozzle or the tumble dryer. Only use the tool supplied. Do not use any other tool.  To unscrew the nozzle, turn the tool anti-clockwise.

  • Page 83: Service

    Contact in the event of a fault In the event of any faults which you can- not remedy yourself, please contact your Miele dealer or the Miele Cus- tomer Service Department. You can book a Miele Customer Ser- vice Department call-out online at www.miele.com/service.

  • Page 84: Eprel Database

    Warranty For information on the appliance war- ranty specific to your country please contact Miele. See back cover for ad- dress. In the UK, your appliance warranty is valid for 2 years from the date of pur- chase. However, you must activate your cover by calling 0330 160 6640 or re- gistering online at www.miele.co.uk.

  • Page 85: Installation

    Installation Rear view  If transporting the tumble dryer, make sure its left or right side panel is: a Protruding lid for holding when mov- - Horizontally (e.g. in a car) or ing the appliance - Upright on a sack truck b Drain hose for condensed water c Hook for winding up the mains con- Transporting the tumble dryer to the...

  • Page 86: Levelling The Tumble Dryer

    Installation Levelling the tumble dryer Additional installation require- ments Room doors and furniture doors  Danger if the dryer door cannot be fully opened. Reliable operation of the tumble dryer is otherwise not guaranteed. The tumble dryer must not be in- stalled in places where doors prevent the dryer door from being fully opened.
  • Page 87 - Disconnect the tumble dryer from the electrical supply. - Air the room where the tumble dryer is located. - Contact the Miele Customer Service Department.
  • Page 88 A plinth with drawer (optional accessor- Preventing excessive heat build-up ies) is available for this tumble dryer You can reduce excessive heat build-up from your Miele dealer or Miele Cus- by taking certain measures. tomer Service Department.  Unscrew the screw feet on the...

  • Page 89: External Condensed Water Connection

     Allow any residual water to run into a container. Hose length: 1.49 m Maximum delivery head: 1.00 m Maximum drainage length: 4.00 m Optional accessories for drainage Accessories are available from your Miele dealer or from the Miele Cus- tomer Service Department.
  • Page 90 Installation Adapter for drainage Installation conditions with non-return valve Miele offers an adapter for washing ma- chines and tumble dryers as an optional  Damage if the end of the hose is accessory. A non-return valve is integ- immersed in water.
  • Page 91 Installation b Union nut c Hose clips d Hose extension e Hose holder f Non-return valve g Drain hose, tumble dryer  Fit the adapter  to the sink drain outlet using the union nut . If this union nut has a flat disc in it, the disc must be taken out first.

  • Page 92: Electrical Connection

    Miele product must also be maintained in isolated operation or in operation that The electrical system must comply with is not synchronised with the mains...

  • Page 93: Technical Data

    Installation Technical data Height 850 mm Height-adjustable 845–855 mm Width 596 mm Depth 643 mm Depth with dryer door open 1110 mm Slot-in Stackable Height/width/depth for building under 850/600/600 mm Weight 55 kg Drum volume 120 l Load size 9 kg (weight of dry laundry) Condensate container, volume 4.2 l Drain hose, length 1.49 m Maximum delivery head...

  • Page 94: Eu Conformity Declaration

    UK Conformity declaration Miele hereby declares that this heat-pump tumble dryer complies with UK Radio Equipment Regulations 2017, as amended. The complete text of the UK declaration of conformity is available from one of the following internet addresses: - Products, Download from www.miele.co.uk...
  • Page 95 United Kingdom Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW Tel: 0330 160 6600, Internet: www.miele.co.uk, E-mail: info@miele.co.uk Australia Ireland South Africa Miele Australia Pty. Ltd. Miele Ireland Ltd. Miele (Pty) Ltd. ACN 005 635 398 2024 Bianconi Avenue...
  • Page 96 TQ 1000 WP en-GB, IE M.-Nr. 12 701 550 / 00...
