5088
GATEWAY
Fire alarm solutions
technical description
www.panasonic-fire-security.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5088 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic 5088

Summary of Contents for Panasonic 5088

  • Page 1 5088 GATEWAY Fire alarm solutions technical description www.panasonic-fire-security.com...

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION ABBREVIATIONS GENERAL DESCRIPTION 3.1. CABINET 3.2. ETHERNET COMMUNICATION (10 BASE-T) 3.3. PLC COMMUNICATION (RS232) 3.4. MODEM COMMUNICATION (RS485/RS232) 3.5. LED INDICATORS POWER SUPPLY 4.1. EBL512 G3 4.1.1. MAIN BOARD 5010 4.1.2. MAIN BOARD 5012 4.2. EBLONE SOFTWARE 5.1.
  • Page 3 5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.2. USER LOGOUT 8.3. SILENCE PC BUZZER (SOUND OFF) 8.4. STATUS 8.4.1. FIRE ALARM 8.4.2. PRE-WARNING/CO-INCIDENCE/QUIET/DELAYED ALARM 8.4.3. FAULT 8.4.4. DISABLEMENTS 8.4.5. TECHNICAL WARNING 8.4.6. INTERLOCKING 8.4.7. DOOR OPEN 8.4.8. ZONES IN TEST MODE 8.4.9.
  • Page 4 8.12. TEST OPERATIONS 8.12.1. ZONE TEST 8.12.2. ZONE RANGE TEST 8.12.3. ALARM DEVICES 8.13. MAINTENANCE OPERATIONS 8.13.1. SET CALENDAR TIME 8.13.2. SYNCHRONIZE 8.13.3. SILENCE ALARM DEVICES 8.13.4. EVACUATE 8.13.5. CALIBRATE OUTPUTS 8.13.6. CLOSE FIRE DOOR 8.13.7. FIRE DRILL MODE MOUNTING INSTALLATION AND WIRING 10.1.

  • Page 5: Introduction

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 1. INTRODUCTION This document describes the Gateway, type number 5088. The document contains information about the product and instructions on how to mount and connect it. It also describes the EBLWeb functions.

  • Page 6: Abbreviations

    2. ABBREVIATIONS Control and indicating equipment Software Hardware Network Time Server Two or more control units connected to a TLON / 5040 System network Local Area Network Site Specific Data...

  • Page 7: General Description

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 3. GENERAL DESCRIPTION The gateway is a hardware. The gateways function is depending on the software (EBLWeb) and on which configuration that is downloaded to the gateway. It is intended for indoor use and in dry premises.
  • Page 8 Example of an EBL512 G3 system Internet/Intranet EBL system EBL512 G3 EBL512 G3 RS232 Gateway TLON / 5040 Network The gateway is used when one CIE or a system with two or more CIE in a TLON / 5040 Network shall be connected to Internet/ Intranet (LAN), to a Security Management System and/or as a Gateway.

  • Page 9: Cabinet

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 3.1. CABINET The gateway consists of a black plastic cabinet, which shall be vertically mounted on the symmetric 35 mm DIN rail inside the CIE. 3.2. ETHERNET COMMUNICATION (10 BASE-T) Two 10BaseT (RJ-45) connectors for a standard Ethernet cable (Ethernet cable is not supplied). This interface is used to connect the gateway to the Internet / intranet (LAN);...

  • Page 10: Power Supply

    4. POWER SUPPLY 24 V DC (Molex 3.5) connector. One power cables is supplied. 4.1. EBL512 G3 4.1.1. MAIN BOARD 5010 The 24V DC cable (1 m) has two plug-in connectors. One is for the gateway and the other cable connector has to be removed. The wires shall then be connected to the following screw terminals on the main board: Brown to "J3:1"...

  • Page 11: Configuration Of Eblweb

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 6. CONFIGURATION OF EBLWEB The EBLWeb is configured via EBLWin. The EBLWeb software, the configuration data and the site specific data (SSD) will be down- loaded to the gateway via TCP/IP, See EBLWin menu Tools.
  • Page 12 a) Right click on the Gateway in the treeview and select Setup wizard. b) In the pop-up window, select the gateway in the list and click Next. c) Log on. The default username/password is admin/admin, but the password can be changed, see section on page 22.
  • Page 13 5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION e) In this step the wizard will retrieve the current setting from the gateway, change if necessary or click Next. f) In this step you can choose a program file to download together with the configuration.

  • Page 14: General Information

    6.1.2. GENERAL INFORMATION Since there is a limitation of the maximum numbers of gateways for an EBL system, each gateway must have a unique technical address (0-4). A default gateway name is shown. The gateway name is shown in the treeview of EBLWin. 6.1.3.

  • Page 15: Browser Settings

    The custom logo will be shown in the lower-left corner in General information. Browse: Opens a dialog to select an appropriate image (jpg, gif, bmp) used for logo. Recommended format size of image is 210 x 56 pixels. If no custom logo is selected, the Panasonic logo will be used.

  • Page 16: Browser Access

    WEB LINK If an alarm point is presented, it is possible to click the hyperlink for example a document or a camera to get more information about the alarm point. Up to 500 links can be used. Web Links Settings The web links are based on three levels: •...

  • Page 17: Gateway/Eblnet Settings

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 6.1.6. GATEWAY/EBLNET SETTINGS The EBLWeb is not only a web-server but can also be used as a protocol interface to another system. The following protocol can be selected: None: No protocol interface function will be used.

  • Page 18: Notification Settings

    EBLNET SETTINGS EBLnet is used to connect the EBL system to a Security Management system. EBLnet license 5097 is a kit containing: • EBLnet license number document • EBLnet license number label • User instructions (MEW01479) Use EBLnet: Has to be selected to activate the EBLnet function. This has to be done before the gateway can be connected to the Security Management system.

  • Page 19: Authentication Type

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION AUTHENTICATION TYPE Type: Select authentication type, depending on SMTP server SMTP Verify SSL: Requires certificate for verification. • Unchecked checkbox: SSL verification with certificate not used • Checked checkbox: Sender web browser certificate will be used or an existing certificate has to be selected (Browse) to verify...
  • Page 20 FIRE ALARM / PRE-WARNING E-MAIL The following parameters can be used together with any other text in the subject and body text. {Project name}: The custom name of the project which is configured in Browser settings, see section 6.1.5. BROWSER SETTINGS on page 15.
  • Page 21 5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION SERVICE / CONTAMINATION E-MAIL {Project name}: The custom name of the project which is configured in Browser settings, see section on page 15. 6.1.5. BROWSER SETTINGS {Date time}: Date and time for occurrence an event.

  • Page 22: Service Connection (Eth1)

    EBLNET CERTIFICATE As of version 3.6.0 of the EBLnet SDK, a certificate is required to be installed on the Gateway 5088. Such a certificate comes installed by default on the Gateway so no action is required from your side, unless you want to cross-sign the certificate.

  • Page 23: Convert Web-Server To Gateway

    Right-click on the web-server in the EBLWin treeview and select Convert to Gateway 5088. Change the hardware ID in the Unit settings tab. This ID can be found in the label on the backside of the gateway, ETH0:MAC-ID...

  • Page 24: Software And Configuration

    7. SOFTWARE AND CONFIGURATION The EBLWeb is mainly consisting of two parts that need to be downloaded into the gateway, to be fully functional. • The software package (eblweblnx290_english.bin) • The gateway configuration data and the EBL-system SSD. 7.1. EBLWEB SOFTWARE PACKAGE The software package consists of all necessary files and configurations to make EBLWeb function as default, without any specific configuration.

  • Page 25: Download Eblweb Configuration

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.2.1. DOWNLOAD EBLWEB CONFIGURATION Click Download EBLWeb configuration in the Tools menu of EBLWin. The gateway list in the top only shows all gateways that are configured with a valid hardware id, see on page 11, 6.1.

  • Page 26: Download Via Configuration Data

    7.3.1. DOWNLOAD VIA CONFIGURATION DATA This is done by checking Include SSD Data via the download of EBLWeb configuration dialog, see section on page 25. 7.2.1. DOWNLOAD EBLWEB CONFIGURATION 7.3.2. DOWNLOAD VIA DOWNLOAD SSD FOR CIE When downloading SSD for control units in EBLWin, there is a choice to Download webserver SSD in the dialog box. If this is selected, the SSD will be downloading for each connected gateway in each CIE.

  • Page 27: Eblweb

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8. EBLWEB The following chapter describes all EBLWeb functions. There is no support for anonymous login. A user with at least lowest priority level is required to be configured via EBLWin, even if the gateway is to be used for status information only.

  • Page 28: User Login

    8.1. USER LOGIN Username: Type the Username for the user level Password: Type the Password for the user level Click LOGIN to open the status page. Operations are user dependant, which means that some menus or operations will be hidden from users with insufficient user level (which is depending on Username and Password).

  • Page 29: Silence Pc Buzzer (Sound Off)

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.3. SILENCE PC BUZZER (SOUND OFF) When a fire alarm is activated, the buzzer/speaker in the computer is used for sound alert. Click the Silence PC buzzer button to silence the buzzer/speaker in the computer. The buzzer/speaker will be re-activated for a new alarm.
  • Page 30 LED buttons explanation: Fire alarm Pre-warning/Co-incidence/Quiet/Delayed alarm Fault Disablement Technical warning Interlocking Door open Zones in test mode Service signal Output activation WEB function disablement Communication error The colour on the LED buttons is not visible until the event is activated. Each of the different summary items in the list will be described in the following pages.

  • Page 31: Fire Alarm

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.4.1. FIRE ALARM In case of fire alarm, click on the Fire alarm LED button or List button to view the fire alarm list. The Time (date and time), Zone, Address and text (alarm text) are displayed.

  • Page 32: Disablements

    8.4.4. DISABLEMENTS In case of disablements, click on the Disablement LED button or List button to view the corresponding disablement list. The list is separated into tab pages for respective disablement type. Click the Reset button for re-enabling the disablement (Requires login on User level 2 or 3). ZONE OR ZONE-ADDRESS DISABLEMENT The Time (date &...

  • Page 33: Technical Warning

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.4.5. TECHNICAL WARNING In case of technical warning, click on the Technical warning LED button or the List button to view the Technical warning list. The Time (date & time), Text (technical warning text), and State (Serviced / “Blank” = Not Serviced) are displayed.

  • Page 34: Communication Error

    8.4.10. COMMUNICATION ERROR In case of any communication error, click on the Communication error LED button or the List button to view the communication error list. This view shows the current communication state for several kinds of communication errors as listed. If in error state, the state will be ‘blinking’...

  • Page 35: Event Log

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.5. EVENT LOG Click the Event log button to show the Event log view. The event log of EBLWeb consists of different types of logs, where three of them are the same as in the control unit, namely, Alarm log, Interlocking log and General log.

  • Page 36: Maintenance (Web Function)

    8.6. MAINTENANCE (WEB FUNCTION) Click the Maintenance button to show the Maintenance view. This view contains two tab pages, one for WEB functions and the other for Web links. 8.6.1. WEB FUNCTION The tab page shows WEB function disablement page with operations to enable or disable the WEB function. Each function is Enabled or Disabled by a clicking the corresponding switch button.

  • Page 37: Gateway Function

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION PC BUZZER FUNCTION This disablement is related to the PC-buzzer, which sounds for each new fire alarm or control unit communication fault. There is also a button for test of the PC-buzzer (four long beeps).

  • Page 38: E-Mail Address

    8.7.2. E-MAIL ADDRESS The e-mail handling in EBLWeb handles six different types of e-mails. Each e-mail type can be disabled, see section on page 36. The EBLWin configured e-mail addresses for recipients are shown in this tab page. Each 8.6.1. WEB FUNCTION e-mail address shown has a button to send a test mail to the configured e-mail address.

  • Page 39: Control Unit Statistics (System Information)

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.8.1. CONTROL UNIT STATISTICS (SYSTEM INFORMATION) This page shows the system information of selected CU and consists of momentary statistics data asked from the connected CU. The current consumption for rectifier, current consumption for charger, battery temperature, low capacity voltage differ- ence, site name (also time of SSD download), and software version for the CU is displayed.

  • Page 40: Disablement Operations

    8.10. DISABLEMENT OPERATIONS Click the Disablement operations button to access a list of different disablement operations. Click on each item to see the corresponding disablement operations. 8.10.1. ZONE A specified Zone can be disabled / re-enabled and an automatic re-enable time can be set. 8.10.2.

  • Page 41: Output

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.10.4. OUTPUT A sub menu for several types of outputs: LOOP OUTPUT UNIT A specified loop unit (tech.no.), output (0-3) can be disabled / re-enabled. VOLTAGE OUTPUT (S) A specified voltage output (0-3) in a specified CIE can be disabled / re-enabled.

  • Page 42: Alarm Devices

    EXTINGUISHING OUTPUT All outputs of type "extinguishing” can be collectively disabled / re-enabled (all at the same time) in all CIE (**) or in a specified CIE. INTERLOCKING OUTPUT All outputs of type "interlocking” can be collectively disabled / re-enabled (all at the same time) in all CIE (**) or in a specified CIE. 8.10.6.

  • Page 43: Activation Operations

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.11. ACTIVATION OPERATIONS Click the Activation operations button to access a list of different activation operations. Click on each item to see the corresponding activation operations. 8.11.1. ZONE-ADDRESS A specified alarm point (Zone-Address) can be activated, i.e. set in fire alarm mode.

  • Page 44: Test Operations

    8.12. TEST OPERATIONS Click the Test operations button to access a list of different test operations. Click on each item to see the corresponding test operations. 8.12.1. ZONE TEST A specified zone can be set in test mode, i.e. test mode activated / de-activated. Zones in test mode can also be de-activated from the Zones in test mode list, see section on page 33.

  • Page 45: Maintenance Operations

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.13. MAINTENANCE OPERATIONS Click the Maintenance operations button to access a list of different maintenance operations. Click on each item to see the corresponding maintenance operations. 8.13.1. SET CALENDAR TIME The date and time can be set for the gateway and the EBL system. Click Get to choose the current date and time from the computer or set the date and time manually.

  • Page 46: Mounting

    9. MOUNTING Gateway shall be vertically mounted on the symmetric 35 mm DIN rail inside the CIE. Cable and accessories kit is supplied with the gateway.

  • Page 47: Installation And Wiring

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 10. INSTALLATION AND WIRING Screen wire termination is not provided. 10.1. EBL512 G3 10.1.1. MAIN BOARD 5010 Ethernet COM Yellow Green Black 0.65 m cable, supplied with the gateway USB connector (RS485/RS232C)

  • Page 48: Main Board 5012

    10.1.2. MAIN BOARD 5012 Ethernet COM COM1 Yellow Green Black (0V) GND 0.65 m cable, supplied with the gateway USB connector COM2 COM1 G1 G1 (0V) GND (RS485/RS232C) COM2 S/- R/+ S/- R/+ 1 m cable, supplied with the gateway S/- E G2 G2 Brown...

  • Page 49: Eblone

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 10.2. EBLONE Ethernet COM COM1 Yellow Green Black (0V) GND 0.65 m cable, supplied with the gateway USB connector COM2 COM1 G1 G1 (0V) GND (RS485/RS232C) COM2 S/- R/+ S/- R/+ 1 m cable, supplied with the gateway...

  • Page 50: Commissioning

    11. COMMISSIONING This chapter describes the correct sequence to install and set the gateway. Make sure to read the complete technical description before commissioning the system. PREPARATIONS AND MOUNTING a) Mount the gateway on the DIN rail inside the CIE. The length of the attached cables is 3 meters. CONNECTIONS b) Connect the cables according to on page 47.

  • Page 51: Technical Data

    5088 GATEWAY - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 12. TECHNICAL DATA All current consumptions are valid by nominal voltage and by 25 °C. Voltage: Allowed 10.8 – 30.0V DC Normal 24V DC Current: Quiescent 75 mA Active 75 mA Short circuit isolator...

  • Page 52: Approvals

    13. APPROVALS Applicable directive/ Approval Applicable standards Notified body EN 61326-1:2013 (Emission & Immunity) Declaration made by manufacturer (Panasonic Electric Works Europe AG) RoHS EN IEC 63000:2018...
  • Page 53 DOCUMENT NAME: TECHNICAL DESCRIPTION GATEWAY DOCUMENT NUMBER: MEW02670 DATE OF ISSUE: 2020-11-11 REV: 6 DATE OF REVISION: 2024-09-13 Panasonic Fire & Security Europe AB Jungmansgatan 12 SE-211 11 Malmö Tel: +46 (0)40 697 70 00 www.panasonic-fire-security.com...
