WRKT22245NC
WRKT22255NC
611055-KNX-EN
General Informat on
The KNX DALI Gateway product s an nterface
dev ce that works on l ght ng control between
the KNX bus and the DALI bus n accordance w th
the DALI-IEC 62386 (DALI-1 / DALI-2) standard.
The dev ce allows KNX to manage and mon tor
ballasts n the DALI bus as nd v dual, group and
broadcast. The dev ce has opt ons w th 1 or 2
channel DALI outputs and prov des energy to the
DALI bus w th the nternal DALI power supply.
Therefore, t s not allowed to connect an external
DALI power supply to the DALI l ne. User and
manager level operat ons can be performed and
var ous warn ngs and dev ce nformat on can be
accessed w th the button, LED and segment
nterface on the dev ce. The dev ce has 2 solated
relay outputs and these outputs can be used n
var ous appl cat ons. The dev ce also has an
Ethernet port and can be mounted on a DIN ra l.
Ma n Features
• For each DALI channel, 64 ballasts, 16 groups, 16
scenar os and broadcast control
• For each DALI ballast and group, sta rcase, n ght,
pan c and burn- n mode control over KNX
• Faults mon tor ng of DALI ballasts v a KNX
• Automat c address ng of ballasts n DALI bus
• Manual control and mon tor ng of ballasts on
the DALI bus v a the user nterface
• Feature of DALI power supply
• Software update over Ethernet
1
WRKT22245NC
WRKT22255NC
Installat on should only be carr ed out by a techn cal personnel hav ng cert f cate of competency
Product Components
1
A
DALI bus faults
12
01 /6 4 : ECG
F
F6 5 : Gateway
F66 : Overload
B
F6 7 : Overvoltage
11
F68 : Short circuit
F6 9 : Device replace
10
ESC
SET
DALI GATEWAY DL102
8
1- DALI Channels (There s no B channel n the
s ngle channel opt on.)
2- Relay Outputs*
3- Menu Act ve LED
4- Status LED
5- IP Connect on Status LED
6- KNX programm ng button and LED
7- KNX bus term nal
8- Ethernet connector
9- Power Supply 230V AC, 50Hz
10 - Manual operat on buttons
11- DALI Bus faults descr pt on
12- 7 segment d splay and channels LED
(Channel's LED turn on, when channel s selected)
* Relay outputs are for s gnal ng purposes. To use
w th the load, a contactor must be used.
Product Vers ons
Product Features WRKT22245NC
Number of DALI Channel 1
Relay Outputs 2
2
KNX DALI GATEWAY DL101 (1 Channel)
KNX DALI GATEWAY DL102 (2 Channels)
2
SUPPLY VOLTAGE
Voltage range
Power consumpt on
total v a ma ns
DALI
Number of outputs
Number of DALI dev ces
3
Protect on
MENU
4
STATUS DALI voltage
5
No-load voltage
IP LINK
Max mum supply current
6
Guaranteed supply current
WRKT2225
7
DALI cable lengths
(for copper w re)
DALI transm ss on rate
KNX
KNX voltage
KNX current consumpt on
KNX nterface
Conf gurat on mode
IP
Connect ons Speed
RELAY OUTPUT
Output Contact 1
Output Contact 2
BUTTONS AND DISPLAY
Control buttons
D splay and LED elements
ENVIRONMENTAL CONDITIONS
Protect on degree
(IEC60529)
Protect on class
(IEC61140)
Isolat on category
Temperature range
Hum d ty
MECHANICAL DESIGN
D mens ons (HxWxD)
Mount ng (IEC60715)
2
Mount ng w dth
2
KNX bus connect on
IP Connector
Connect on type
(Power/Relay/DALI)
We ght
STANDARDS
Product
EMC
LVD
230 V AC, 50/60 Hz
Max. 8W (at 230 V AC and max. load) (for 1 ch.)
Max. 12W (at 230 V AC and max. load) (for 2 ch.)
2 channel
Max mum 64 ballast per output
Short c rcu t, Overload, Over-voltage (230VAC)
18 V DC
18 V DC
2x250 mA
250 mA
230 mA 2x190 mA
The DALI control voltage s a funct onal
extra-low voltage (FELV).
- 2.5 mm² max. 300 m
- 1.5 mm² max. 300 m
- 1.0 mm² max. 224 m
- 0.75 mm² max. 168 m
- 0.5 mm² max. 112 m
1200 b t / s
DC 21 ... 32 V SELV
<5 mA
TP1
S-Mode
10/100 Mb ts
1 N/O, 2A-230V AC Res st ve, 2A 30V DC
1 N/O, 2A-230V AC Res st ve, 2A 30V DC
< , SET , > , ESC (Total 4 button)
MENU, STATUS 1/2, IP LINK/TRAFFIC, KNX
PROG., A, B (only 2 channels) - Total 6 LED
nd cators 3 D g t 7-Segment LED D splay
IP20
II
Overvoltage category III (IEC60664)
Pollut on degree 2 (IEC60664)
Operat on -5...+45 °C
Storage -10...+55 °C
Transport -25...+70 °C
5...93% (non-condens ng)
90mmx71,8mmx65,8mm
35 mm top-hat ra l (TH35)
DIN ra l 72mm (4 modules)
KNX connector (243-211 Wago)
Ethernet (RJ45, female)
Screw term nal
S ngle w re: 1,5mm²...4mm² or
2x1,5mm²...2x2,5mm²
Stranded w re w thout ferrule:
0,75mm²...4mm²
Stranded w re w thout ferrule:
0,5mm²...2,5mm²
0.22 kg
EN 62386 (DALI), EN 50090 (KNX)
EN 50428 / EN 60669-2-5
EN60669-1, EN 60669-2-1,
EN 50428 / EN 60669-2-5
