INSTRUCTION MANUAL
Flexible Wire-saving Link System S-LINK V
S-LINK V Gateway Controller for CC-Link
SL-VGU1-C
MJE-SLVGU1C No.0101-17V
Thank you very much for purchasing Panasonic products. Read this Instruc-
tion Manual carefully and thoroughly for the correct and optimum use of this
product. Kindly keep this manual in a convenient place for quick reference.
Never use this product with a device for personnel protection.
In case of using devices for personnel protection, use products which
meet laws and standards, such as OSHA, ANSI or IEC etc., for person-
nel protection applicable in each region or country.
Before touching this product, remove any electrostatic charge that may
be present on your body. There is a danger of this product getting dam-
aged due to the electrostatic charge.
For a detailed description of the S-LINK V gateway controller, refer to
the "S-LINK V Gateway Controller User's Manual."
Please refer to the "S-LINK V User's Manual" for details of the entire
S-LINK V system.
1 OUTLINE
This is an S-LINK V gateway controller having slave functions of the
open network CC-Link.
A distributed bit level network can be constructed by incorporating an
S-LINK V system as a lower level network of CC-Link.
2 SPECIFICATIONS
Designation S-LINK V gateway controller for CC-Link
Item Model No. SL-VGU1-C
Supply voltage 24V DC %
300mA or less (excluding error output load and power supply
Current consumption
for driving I/O units) (Note 2)
Allowable through current 7A (Note 3)
Transmission speed A mode: 110kbps, B mode: 27.5kbps, C mode: 6.9kbps
A mode: 0.29 to 10.32ms, B mode: 1.18 to 41.29ms
Refresh time
C mode: 4.70 to 165.15ms
128 inputs max., 128 outputs max. (Note 4)
I/O points
256 inputs max., 256 outputs max. (Note 5)
Connected node No. 256 nodes max.
Transmission distance A mode: 50m max., B mode: 200m max., C mode: 800m max.
Total wiring length A mode: 100m or less, B mode: 400m or less, C mode: 1,600m or less
2
Transmission ) or Conductor cross-section
2
cable area 0.3 to 2.0mm 4-core VCTF cable (without shield) (Note 6)
I/O combination I/O settable in units of 32 Nos.
Error output NPN open-collector transistor
Compatible network CC-Link Ver.1.10
Occupied station No. 1 to 4 stations (varies with S-LINK V I/O control points.)
Transmission speed 10Mbps 5Mbps 2.5Mbps 625kbps
Total extension 100m 160m 400m 900m
Transmission cable
Remote unit
Remote device unit
Ambient temperature 0 to +55ºC (No dew condensation), Storage: -20 to +70ºC
Ambient humidity 10 to 90% RH, Storage: 10 to 90% RH
Material Enclosure: ABS
Weight Approx. 200g
Notes: 1) Mainly the S-LINK V
ner Association.
2) The current consumption value shown here is the total of the maximum current (D-G
line only) supplied to the S-LINK V I/O units and the current consumption of the
S-LINK V gateway controller.
3) This product is not equipped with any short-circuit protective function. For this rea-
son, select a power supply unit having short-circuit protective function (fuse, etc.).
mote I/O (RX / RY) and the balance 16 channels are assigned to remote register
(RWrm / RWwm).
remote registers (RWrm / RWwm).
6) The VCTF cable is the vinyl cabtyre cable that conforms to the requirements of JIS
3 CAUTIONS
This product has been developed / produced for industrial use only.
This product is not incorporated with a short-circuit protection circuit.
Please use a power supply having a short-circuit protection function (fuse, etc.)
Take care that wrong wiring will damage the product.
Do not run the wires together with high-voltage lines or power lines or put
them in the same raceway. This can cause malfunction due to induction.
Verify that the supply voltage variation is within the rating. Also, check
the voltage fluctuation at the end terminal of the transmission route,
since voltage drop occurs depending on the diameter and the length of
the transmission cable.
If power is supplied from a commercial switching regulator, ensure that
the frame ground (F.G.) terminal of the power supply is connected to an
actual ground.
Do not use during the initial transient time after the power supply is
switched on. Further, transmission is not possible when the system is in
BUSY state (during switching on the power supply or system setting).
Make sure to use an isolation transformer for the DC power supply. If an
auto-transformer (single winding transformer) is used, this product or the
power supply may get damaged.
In case a surge is generated in the used power supply, connect a surge
absorber to the supply and absorb the surge.
In case noise generating equipment (switching regulator, inverter motor,
etc.) is used in the vicinity of this product, connect the frame ground (F.G.)
terminal of the equipment to an actual ground.
This product does not have a dustproof or waterproof construction. Do
not use it in places having excessive vapor, dust, etc.
Take care that the product does not come in contact with water, oil,
chemicals, or organic solvents, such as, thinner, etc. Do not use it in an
environment containing corrosive gas.
Any protection or safety circuits against system malfunction should be
designed to be external to the S-LINK V system.
porated into your system, install this product in a conducting box as per
User's Manual (issued by Mitsubishi Electric Corporation) of the sequencer.
4 MOUNTING
In case of mounting on DIN rail
1. Pushing the stopper in the direction of
the mounting section on the 35mm width
DIN rail.
When pushing in the stopper, lightly
press the groove of the stopper down-
wards.
2. Press down the rear portion of the
mounting section on the 35mm width
screwdriver in the DIN rail stopper and
Flathead
pulling outwards.
screwdriver
In case of using screws
• If mounting by screws, use M4 (length 12mm or less) pan head screws
and the tightening torque should be 1.2N·m or less. (Please arrange the
M4 pan head screws separately.)
156kbps
Refer to " DIMENSIONS" for the mounting hole dimensions.
1,200m
5 ERROR DISPLAY
If an error occurs on the S-LINK V system side, SL-VGU1-C displays the
following 7 types of errors.
<S-LINK V system error display>
Error No. Cause of error Transmission state during error
Error 0 Fault in system (controller) Transmission stopped
Short-circuit between +24V
Transmission stopped.
Error 1
-
and D
Restarted automatically 5 sec. after
Error 2 Short-circuit between D and G
Fault or disconnection of rec-
Error 3
Error 4
Transmission continued
Output short-circuit of output
-
unit
Error 5
Drive power supply of I/O de-
System setting not done cor- Automatically restored when system
Error 6
rectly. setting is correctly done.
Note: If two or more errors are detected at the same time, errors 1 and 2 will be given priority
in indication.
6 FUNCTIONAL DESCRIPTION
6. Transmission indicator (Green)
9. Operation indicators
(Green, Red)
10. Station No. setting
switches
11. Transmission
speed setting switch
12. CC-Link terminal
block connector
Designation
Hexadecimal indicator
1 • Lights up: Hexadecimal display mode
(Orange)
•
<RUN mode>
• LEDs light up in each transmission mode (3 types,) and
• When an error occurs, the type of error is shown.
Note: When the cause of the error is removed, the error
-
Address display
2 <CHECK mode>
(Red)
•
Note:
• When an error occurs, the node number having the er-
<CONFIG mode>
2
• Each setting is displayed successively. The settings
1
Stopper 35mm width DIN rail
•
3 ENTER key
4 SELECT keys
Stopper
5 Mode selection switch
Transmission indicator
6
(Green)
7 Error indicator (Red) • Lights up: Error occurrence
•
S-LINK V terminal
8
block connector
L RUN • Lights up: When the correct data is received from the master station.
(Green) • Turns off: When there is error in data receiving or
Operation
9
indicators
L ERROR
(Red)
RD (Green)
SD (Green)
Station No. setting
10 switches
• "x10" sets the tens position of the station No.
(ST.NO)
• "x1'"sets the ones position of the station No.
Transmission speed
11 setting switch
(B RATE)
CC-Link terminal
12
block connector
7 CONNECTION
4. SELECT keys Take care that wrong wiring will damage the product.
1. Hexadecimal indicator
Do not short-circuit "0V" and "G" on the S-LINK V terminal block con-
(Orange)
nector side.
2. Address display (Red)
3. ENTER key
ther, when supplying power to the load from SL-VGU1-C, make sure
not to exceed the allowable through current.
5. Mode selection switch
not come out. The tightening torque should be 0.5N·m, or less, on the
S-LINK V terminal block connector side and 0.2N·m, or less , on the
7. Error indicator (Red)
CC-Link terminal block connector side.
Do not apply solder, etc., on the tips of the wires to be connected to the
8. S-LINK V terminal
block connector
terminal block. This can cause loosening of the screws, resulting in wire
disconnection.
The F.G. terminal on the S-LINK V terminal block connector side and
the S terminal on the CC-Link terminal block connector side are not
connected. When grounding, ground them separately.
<S-LINK V terminal block connector side terminal arrangement>
Description
It indicates the display mode of the address display.
8
7
The display contents differ in "RUN mode," "CHECK 6
mode" and "CONFIG mode." The mod e can be 5
changed with the mode selection switch.
4
3
2
trace out a rectangle in the clockwise direction.
1
A mode B mode C mode
<CC-Link terminal block connector side terminal arrangement>
display can be erased by pressing ENTER key and
SELECT keys (2 types) simultaneously.
-
quently, the addresses are displayed at every press of SELECT keys.
Connected node No.: I/O unit node No. is displayed in
decimal / hexadecimal.
Address: I/O unit addresses are displayed successively
in decimal / hexadecimal.
Note: In case SL-VGU1-C is the end terminal of CC-Link, connect the termination resistance
In case of hexadecimal display, the hexadecimal indicator lights up.
between DA and DB. However, as the termination resistance is not supplied, please
arrange it separately.
ror and the error addresses are displayed successively.
DIMENSIONS (Unit: mm)
8
can be changed by using SELECT key.
and when a change is made from RUN mode.
When ENTER key is pressed, the setting value of each
setting is entered.
When system set is displayed, if ENTER key is pressed
for 3 sec., or more, system set is performed.
They are used to change the displayed item or setting
item, and to change the numerical value of each setting.
It is used to change to RUN / CHECK / CONFIG modes.
It blinks during transmission (signal generation). The frequen-
It shows the error condition.
+24V, 0V, and F.G. are supplied from the external power
6.3
supply, and +24V, 0V, D, and G are supplied to I/O units.
Further, the error output is connected to the external device.
It indicates whether data transmission is being carried out
normally between SL-VGU1-C and the master station.
transmission (CRC error), or when time-over occurs.
(However, lights up when the correct data is received.)
Lights up: When transmission error (CRC error) occurs
or when there is a mistake in station No. / transmission
-
Blinks: When station No. setting / transmission speed
setting is changed in-between
Lights up when data is received.
Lights up when data is transmitted.
Make sure to set the station No. of SL-VGU1-C from 01 to 64. (The
occupied station No. changes depending on S-LINK V I/O control No.)
It sets the transmission speed of CC-Link.
Setting Transmission speed Setting Transmission speed
0 156kbps 3 5Mbps
Panasonic Industry Co., Ltd.
1 625kbps 4 10Mbps
2 2.5Mbps
1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8506, Japan
Make sure to set the transmission speed setting switch
https://industry.panasonic.com/
in the range of 0 to 4.
Please visit our website for inquiries and about our sales network.
It is the terminal block connector for connection of CC-
Panasonic Industry Co., Ltd. 2024
Link transmission signal.
April, 2024
No. Designation Description
8 ERR Error output
7 G Black
6 D White
Main line
5 0V Blue
4 24V Brown
3 0V
Input External power supply input
2 24V
1 FG Frame ground
No. Designation Description
8
8
7
DA Comprises of two terminals for cascade wiring.
6 7
5
6
4
DB Comprises of two terminals for cascade wiring.
3 5
2
4
1
DG Comprises of two terminals for cascade wiring.
3
2
Connect the shield wire of the CC-Link cable to
S
one terminal, and ground the other terminal.
1
(12)
66
5
8
37.5
48
100
Suitable for 35mm width DIN rail
2-ø4.4 mounting holes
92
40
PRINTED IN JAPAN
-
-
