- Page 1 Products Solutions Services BA02378C/07/EN/02.24-00 71687426 2024-12-09 Operating Instructions Dipfit CYA10 Immersion assembly for wastewater, surface water and industrial applications...
-
Page 3: Table Of Contents
Dipfit CYA10 Table of contents Table of contents About this document ... 4 Warnings ......4 Symbols used . -
Page 4: About This Document
About this document Dipfit CYA10 About this document Warnings Structure of information Meaning This symbol alerts you to a dangerous situation. DANGER Failure to avoid the dangerous situation will result in a fatal or serious injury. Causes (/consequences) If necessary, Consequences of non- compliance (if applicable) ‣... -
Page 5: Basic Safety Instructions
Dipfit CYA10 Basic safety instructions Basic safety instructions Requirements for the personnel • Installation, commissioning, operation and maintenance of the measuring system may be carried out only by specially trained technical personnel. • The technical personnel must be authorized by the plant operator to carry out the specified activities. -
Page 6: Electromagnetic Compatibility
Product description Dipfit CYA10 Electromagnetic compatibility Electromagnetic compatibility • The product has been tested for electromagnetic compatibility in accordance with the applicable international standards for industrial applications. • The electromagnetic compatibility indicated applies only to a product that has been connected in accordance with these Operating Instructions. - Page 7 Dipfit CYA10 Product description A0056129 1 Product description of the individual parts Hose gland Plug cap Assembly housing Protective cap and cable mounting tool Endress+Hauser...
-
Page 8: Incoming Acceptance And Product Identification
Incoming acceptance and product identification Dipfit CYA10 Incoming acceptance and product identification Incoming acceptance On receipt of the delivery: Check the packaging for damage. Report all damage immediately to the manufacturer. Do not install damaged components. Check the scope of delivery using the delivery note. -
Page 9: Scope Of Delivery
Click the product overview. A new window opens. Here you fill information pertaining to your device, including the product documentation. 4.2.3 Manufacturer address Endress+Hauser Conducta GmbH+Co. KG Dieselstraße 24 70839 Gerlingen Germany Scope of delivery The scope of delivery comprises: •... - Page 10 Installation Dipfit CYA10 5.1.2 Dimensions Ø 36 (1.42) Ø 33 (1.2) A0056114 2 Dimensions, CYA10 assembly. Unit of measurement mm (in) 91 (3.58) A0056507 3 Dimensions, chain holder process connection. Unit of measurement mm (in) Endress+Hauser...
- Page 11 Dipfit CYA10 Installation Ø 58 (2.28) G1 1/4" A0056508 4 Dimensions, CYA10-ISO228-G1_1_4 process connection. Unit of measurement mm (in) 16,3 (0.64) 4xØ9 (0.35) 150 (5.81) 180 (7.09) A0056509 5 Dimensions, CYA10 oval flange process connection. Unit of measurement mm (in)
- Page 12 Installation Dipfit CYA10 Ø165 (6.50) Ø 102 (4.02) A0056510 6 Dimensions, CYA10-ASME-B16.5-2 inch process connection. Unit of measurement mm (in) Endress+Hauser...
- Page 13 Dipfit CYA10 Installation Ø165 (6.50) Ø 102 (4.02) A0056510 7 Dimensions, CYA10-EN1092-DN50 process connection. Unit of measurement mm (in) Endress+Hauser...
-
Page 14: Mounting The Assembly
Installation Dipfit CYA10 Mounting the assembly 5.2.1 Mounting the sensor cable The assembly is designed for the digital measuring cable CYK10 with open ferrules. Remove or fit the crown screw for the sensor cable The protective cap also serves as a cable mounting tool. The protective cap is used to unscrew the crown screw in the plug cap in order to fit the sensor cable. - Page 15 Dipfit CYA10 Installation Guide the sensor cable (6) through the plug cap (4) up to the nozzle (5). The fixing ring (3) must be aligned with the groove in the plug cap (4) and pushed in. The Memosens coupling (2) remains in the plug cap (4).
- Page 16 Installation Dipfit CYA10 Remove the protective cap ‣ A0056113 Unscrew the protective cap (1) at the lower end of the assembly housing (2). Mount the protective cap Press the protective cap (1) at the lower end of the assembly housing (2) straight onto the thread.
-
Page 17: Post-Installation Check
Dipfit CYA10 Installation A0056229 8 Installation using a sample process connection Guide the hose (6) for the sensor cable through the hose gland (5) and the clamping ring (4). Guide the sensor cable (3) through the hose. Thread the sensor cable (3) into the nozzle (2) through the process connection. Make sure that the cable cores (1) do not bend. -
Page 18: Maintenance
Maintenance Dipfit CYA10 Maintenance WARNING Rough or slippery surfaces. Risk of injury from tripping or falling. ‣ Wind up the hose so that it is not kinked or tangled. ‣ Wear protective gloves, protective goggles and protective clothing. ‣ Secure the assembly against falling. -
Page 19: Maintenance Work
Dipfit CYA10 Maintenance WARNING Risk of injury if medium escapes ‣ Before each maintenance task, ensure that the process pipe is empty and rinsed. ‣ The assembly may contain residual medium; rinse thoroughly before commencing work. WARNING Wastewater There is a risk of infection when working with wastewater! ‣... -
Page 20: Repair
The product must be returned if repairs or a factory calibration are required, or if the wrong product was ordered or delivered. As an ISO-certified company and also due to legal regulations, Endress+Hauser is obliged to follow certain procedures when handling any returned products that have been in contact with medium. -
Page 21: Accessories
Dipfit CYA10 Accessories Accessories The following are the most important accessories available at the time this documentation was issued. Listed accessories are technically compatible with the product in the instructions. Application-specific restrictions of the product combination are possible. Ensure conformity of the measuring point to the application. This is the responsibility of the operator of the measuring point. -
Page 22: Technical Data
Technical data Dipfit CYA10 Memosens CPS31E • pH sensor for standard applications in drinking water and swimming pool water • Digital with Memosens 2.0 technology • Product Configurator on the product page: www.endress.com/cps31e Technical Information TI01574C 8.2.2 Oxygen sensors Memosens COS22E •... -
Page 23: Mechanical Construction
Dipfit CYA10 Technical data Pressure/temperature ratings p[pa] p[psi] p[bar] 500000 400000 300000 200000 100000 T[°C] 140 158 T[°F] 104 122 A0056350 9 Pressure/temperature rating Temperature Pressure Mechanical construction 9.3.1 Design, dimensions → Section "Installation" 9.3.2 Weight Hose length Weight 1 m (3.28 ft) - Page 24 Technical data Dipfit CYA10 Non-hazardous area Hazardous area Lap joint flanges Oval flange parts Chain holder PA6/1.4404/A4 PA6/1.4404/A4 Cable gland 1.4305 1.4305 Clamping ring PP ELS* Plug fuse PBT-GF30 PBT-GF30 * ELS = Electrically conductive Endress+Hauser...
-
Page 25: Index
Dipfit CYA10 Index Index Accessories ..... 21 Warnings ..... . . 4 Dimensions . - Page 28 *71687426* 71687426 www.addresses.endress.com...
