Ninja DETECT DUO TB300 Instructions

NINJA
Recipe Book Not Included
DETECT ™ DUO ® POWER BLENDER
WITH BLENDSENSE ™ TECHNOLOGY
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS BEFORE USE • FOR HOUSEHOLD USE ONLY
mi
Read and review instructions for operation and use.
A
Indicates the presence of a hazard that can cause personal Injury, death, or substantial property damage If
the warning inc1u· d ed with this symbol is ignored.
(}
For indoor and household use only.
When using electrical appliances, basic safety precautions should always be followed, including the following:
AWARNING: To reduce the risk of injury, fire, electrical shock or property damage, basic
safety precautions must always be followed, including the following numbered warnings and
subsequent instructions. Do not use appliance for other than intended use.
1 Read all instructions prior to using the appliance and its accessories.
2 Carefully observe and follow all warnings and instructions. This unit contains electrical connections
and moving parts that potentially present risk to the user.
3 ALWAYS take your time and exercise care during unpacking and appliance setup. Blades are sharp.
ALWAYS exercise care when handling blade assemblies. This appliance contains sharp, loose blades
that can cause injury if mishandled.
4 Take inventory of all contents to ensure you have all parts needed to proper . ly and safely operate your
appliance.
5 ALWAYS exercise care when handling the Hybrid Edge'" Blades Assembly. The blades are sharp.
ONLY grasp the Hybrid Edge Blades Assembly by the outer perimeter of the blade assembly base.
Failure to use care when handling the blade assembly will result in a risk of laceration.
6 This product is provided with a Ninja Detect ™
Assembly). ALWAYS exercise care when handling blade assemblies. The blade assemblies are sharp
and are NOT locked in place in their containers. The blade assemblies are designed to be removable
to facilitate cleaning and replacement if needed. ONLY grasp the blade assembly by the top of the
shaft. Failure to use care when handling the blade assemblies will result in a risk of laceration.
7 Turn the appliance OFF, then unplug the appliance from the outlet when not in use, before assembling
or disassembling parts, and before cleaning. To unplug, grasp the plug by the body and pull from the
outlet. NEVER unplug by grasping and pulling the flexible cord.
8 Before use, wash all parts that may contact food. Follow washing instructions covered in this
instruction manual.
9 Before each use, inspect blade assemblies for damage. If a blade is bent or damage is suspected,
contact a service center.
10 DO NOT use this appliance outdoors. It is designed for indoor household use only.
11 DO NOT blend hot, effervescent, or carbonated liquids. Doing so may cause excessive pressure
buildup, resulting in risk of laceration and/or the user being burned.
12 This appliance has a polarized plug (one prong is wider than the other). To reduce the risk of electric
shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet reverse
the plug. If it still does not fit, contact a qualified electrician. DO NOT modify the plug in any way.
13 DO NOT operate any appliance with a damaged cord or plug, or after the appliance malfunctions
or is dropped or damaged in any manner.
14 This appliance has important markings on the plug blade. The entire supply cord is not suitable for
replaceroent. If damaged, please contact a service center.
15 Extension cords should NOT be used with this appliance.
16 To protect against the risk of electric shock, DO NOT submerge the appliance or allow the power
cord to contact any form of liquid.
17 DO NOT allow the cord to hang over the edges of tables or counters. The cord may become snagged
and pull the appliance off the work surface.
18 DO NOT allow the unit or the cord to contact hot surfaces, including stoves and other heating appliances.
19 ALWAYS use the appliance on a tlry and level surface.
20 DO NOT allow children to operate this appliance or use as a toy. Close supervision is necessary when
any appliance is used near children.
21 This appliance is NOT intended to be used by people with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
22 ONLY use attachments and accessories that are provided with the product or are recommended by
SharkNinja. The use of attachments, including canning jars, not recommended or sold by SharkNinja
may cause fire, electric shock, or injury.
23 NEVER place a blade assembly on the motor base without it first being attached to its corresponding
container (pitcher or cup) with the lid also in place.
24 Keep hands, hair, and clothing out of the container when loading and operating.
25
During operation and handling of the appliance, avoid contact with moving parts.
26 DO NOT fill containers past the MAX FILL or MAX LIQUID lines.
27 DO NOT operate the appliance with an empty container.
28 DO NOT microwave any containers or accessories provided with the appliance.
29 NEVER leave the appliance unattended while in use.
30 DO NOT blend hot liquids. Doing so may result in pressure buildup and steam exposure that can pose
a risk of the user being burned.
31 DO NOT process dry ingredients with the Single-Serve Blending and Hybrid Edge Blades Assembly or the
pitcher and Stacked Blade Assembly.
32 DO NOT perform grinding operations with the Single-Serve Cup and Hybrid Edge Blades Assembly
or the pitcher and Stacked Blade Assembly .
33 NEVER operate the appliance without lids and caps in place. DO NOT attempt to defeat the interlock
mechanism. Ensure the container and lid are properly installed before operation.
34
Before operation, ensure all utensils are removed from containers. Failure to remove utensils can
cause containers to shatter and potentially result in personal injury and property damage.
35
Keep hands and utensils out of containers while chopping to reduce the risk of severe personal injury or
damage to the blender. A scraper may be used ONLY when the blender is not running.
36 If you find unmixed ingredients sticking to the sides of the cup, stop the appliance, remove the blade
assembly, and use a scraper to dislodge ingredients.
37 DO NOT open the pitcher's pour spout cap while blender is operating.
38 If you find unmixed ingredients sticking to the sides of the pitcher, stop the appliance, remove the
lid, and use a spatula to dislodge ingredients. NEVER insert your hands into the pitcher, as you may
contact one of the blades and experience a laceration.
39 DO NOT attempt to remove the container or lid from the motor base while the blade assembly is still
spinning. Allow the appliance to come to a complete stop before removing lids and containers.
40
If the appliance overheats, a thermal switch will activate and temporarily disable the motor.
To reset, unplug the appliance and allow it to cool for approximately 30 minutes before using again.
41 DO NOT expose the containers and accessories to extreme temperature changes. They may
experience damage.
42 Upon completion of processing, ensure the blade assembly is removed BEFORE emptying container's
contents. Remove the blade assembly by carefully grasping the top of the shaft and lifting it from the
container. Failure to remove the blade assembly before emptying the container results in a risk
of laceration.
43
If using the pitcher's pour spout, hold the cover in place on the container or ensure lid lock is engaged
when pouring to avoid risk of injury.
44 Remove the Hybrid Edge Blades Assembly from the Single-Serve Cup upon completion of blending.
DO NOT store ingredients before or after blending them in the cup with the blade assembly attached.
Some foods may contain active ingredients or release gases that will expand if left in a sealed container,
resulting in excessive pressure buildup that can pose a risk of injury. For ingredient storage in the cup,
use only Spout Lid to cover .
45 The maximum wattage rating for this appliance is based on the configuration of the Hybrid Edge
Blades Assembly and Single-Serve Cup. Other configurations may draw less power or current.
46 DO NOT submerge the motor base or control panel in water or other liquids. DO NOT spray motor
base or control panel with any liquid.
47 DO NOT attempt to sharpen blades.
48 Turn off the appliance and unplug the motor base before cleaning.
SAVE THESE INSTRUCTIONS
Total Crushing ® & Chopping Blades (Stacked Blade
PARTS
A Pitcher Lid With Pour Spout
B Ninja Detect'" Total Crushing•
& Chopping Blades
(Stacked Blade Assembly)
C * Full-Size Pitcher
D
Spout Lid
E Hybrid Edge'" Blades Assembly
F Single-Serve Cup
G Motor Base
(attached power cord not shown)
• max liquid capacity.
Accessory type and quantity may
vary depending on the model.
BEFORE FIRST USE
IMPORTANT: Review all warnin!;Js at the beginning of this Owner's Guide before proceeding.
Remove all packaging materials from the unit. Exercise care when unpacking the Stacked Blade Assembly
and Hybrid Edge Blades Assembly as the blades are sharp.
2 The Stacked Blade Assembly is NOT locked in place in the pitcher. Handle the Stacked Blade
Assembly by grasping the top of the shaft.
3 Handle the Hybrid Edge Blades Assembly by grasping around the perimeter of the blade assembly base.
4
Wash containers, lids, and blade assemblies in warm, soapy, water using a dishwashing utensil with a
handle to avoid direct contact with the blades. Exercise care when handling blade assemblies, as the
blades are sharp.
5
Thoroughly rinse and air-dry all parts.
6
Wipe control panel with a soft cloth. Allow it to dry completely before using.
NOTE: All attachments are BPA free. Accessories are top-rack dishwasher safe and should NOT be
cleaned with a heated dry cycle. Ensure blade assemblies and lids are removed from the containers
before placing in the dishwasher. Exercise care when handling blade assemblies.
BLENDSENSE TECHNOLOGY
™
Intelligent BlendSense program revolutionizes traditional blending by sensing your ingredients and
blending to perfection every time. The BlendSense program will be active by default. Press(!) button,
then START/STOP. Once the program begins, it will automatically stop when blending is complete. To
stop blending before the end of the program, press the dial again.
Simply press the dial to start the BlendSense program.
0
BLEND
SENSE
Starts blending Automatically chooses
to sense your the blending speed,
time, and pulses.
ingredients.
BlendSense is best used to achieve smooth blends such as smoothies,
frozen drinks, smoothie bowls, dips, purees, and sauces.
INITIAL BLENDING
SENSING
In the first lS seconds, actively adjusts speed and time based on ingredients and recipe size.
BLENDING POSSIBILITIES
CRUSH AND MAX-CRUSH
BLENDING
Detects tougher and frozen
Blends continuously
ingredients, then adjusts the pulsing
without pulsing.
pattern for a smooth blend.
NOTE: Once blending possibility is selected, runtime will count up on the display in seconds. Total
time varies from seconds up to almost two minutes.
ERROR DETECTION
INSTALL
Illuminates if no vessel
is installed or if a vessel
is installed incorrectly.
To resolve, reinstall
the vessel.
NOTE: Press the dial to START or STOP any program. Turn to select.
POWER'
Press to power
BLENDSENSE'"
the unit on and off.
Intelligent one-touch program
that senses your ingredients
MANUAL
and blends to perfection.
Adjustable speed for
MODE (Pitcher only) _____ _,
total blending control
Preset processing program (CHOP)
that chops for you.
PROCESSING MODE PROGRAM
A
D
�
�
i
B
A E
C
lfJ
F
tm
e
G
0 0
ENJOY
Blends to perfection,
no matter the
portion size.
THICK MODE
Creates thick
spoonable results.
ADD LIQUID()
When using the Single-Serve Cup, this illuminates
if, during blending, your recipe requires more
0"
liquid to blend. When "ADD LIQUID displays
on the dial, press START/STOP and remove the
cup from the base. Add 1/2 to 1 cup of additional
liquid. Reinstall the cup, then press START/STOP
to run the BlendSense program again.
'
PULSE
Operates only when PULSE
is pressed. Us<; short presses
for short pulses and long
presses for long pulses.
