THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting of
refrigerant (CFCs, HCFCs and HFCs) as of July 1, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for noncompliance.
NOTICE
A thermostat is not included and must be ordered
separately.
• A Lennox communicating thermostat must be used in
communicating applications.
• In non-communicating applications, the Lennox
ComfortSense® thermostat may be used, as well as
other non-communicating thermostats.
In all cases, setup is critical to ensure proper system
operation.
Field
wiring
for
both
communicating applications is illustrated in diagrams,
which begin on page 4.
WARNING
Every working procedure that affects safety means shall
only be carried out by competent persons. This appliance
is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not
play with the appliance.
CAUTION
Leak Detection System installed. Unit must be powered
except for service.
WARNING
Maximum Altitude of application is 3200m above sea
level.
Disponible en español en LennoxPros.com
Disponible en Français sur le LennoxPros.com site
©2024 Lennox Industries Inc.
Dallas, Texas, USA
communicating
and
non-
INSTALLATION
INSTRUCTIONS
Dave Lennox Signature
Collection CBK48MVT Units - R454B
MULTI-POSITION AIR HANDLERS
508444-01
06/2024
Table of Contents
General Information .......................................................2
Shipping and Packing List .............................................3
Field Control Wiring .......................................................4
Target CFM Tables ......................................................16
Requirements ..............................................................18
Upflow and Downflow Unit Dimensions .......................19
Installation Clearances ................................................21
Installing the Unit .........................................................21
Sensor Connections and Wiring Requirements............27
Sensor / Bracket Installation .........................................31
Brazing Connections ...................................................33
Installing the Condensate Drain ..................................35
Condensate Drain.........................................................36
Sealing the Unit ...........................................................37
Unit Operating Sequences ..........................................38
Heat Pump Operation (Heating and Cooling) ..............45
Cooling Operation ........................................................46
Error Code / Recall Mode ............................................47
Indoor Blower Test .......................................................48
Operation .....................................................................48
Repairing or Replacing Cabinet Insulation ..................49
Homeowner Maintenance ............................................49
Professional Maintenance ...........................................49
Sensor Maintenance ....................................................50
Decommissioning ........................................................52
NOTE - This unit is a PARTIAL UNIT AIR CON DITIONER,
complying with PARTIAL UNIT requirements of this Stan-
dard, and must only be connected to other units that have
been confirmed as complying to corre sponding PARTIAL
UNIT requirements of this Standard, UL 60335-2-40/CSA
C22.2 No. 60335-2-40, or UL 1995/CSA C22.2 No 236.
Partial units shall only be connected to an appliance suit-
able for the same refrigerant.
Ducts connected to an appliance shall not contain a
potential ignition source
IMPORTANT: Special procedures are required for clean-
ing the all-aluminum coil in this unit. See page 49 in this
instruction for information.
Page 1
®
