Credenza
Trestle Collection | Model 428841
Scan to rate and review
your piece at Sauder.com
Your opinion matters!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
It stands. You sit.
A thing of beauty,
this one.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-32
Français pg 33-36
Español pg 37-40
Lot # 573152
Purchased: __________________
10/14/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trestle 428841 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Trestle 428841

Summary of Contents for Sauder Trestle 428841

  • Page 1 SAFETY INFORMATION. Trestle Collection | Model 428841 PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-32 Français pg 33-36 Scan to rate and review Español pg 37-40 your piece at Sauder.com Your opinion matters! Lot # 573152 10/14/21 Purchased: __________________...
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with flat panel televisions weighing less than 70 pounds. Never use with a TV that weighs more.

  • Page 3: Part Identification

    RIGHT DRAWER SIDE (2) RIGHT FRONT LEG (1) DRAWER FRONT (2) LEFT DRAWER SIDE (2) LEFT FRONT LEG (1) BACK (1) D128 DRAWER BACK (2) CENTER FRONT LEG (1) D730 DRAWER BOTTOM (2) RIGHT REAR LEG (1) D128 D730 www.sauder.com/service 428841 Page 3...

  • Page 4: Hardware Identification

    10S SILVER 1-1/8" FLAT HEAD SCREW - 12 30S BLACK 1-9/16" FLAT HEAD SCREW - 10 38S SILVER 1/2" MACHINE SCREW - 4 62S BLACK 9/16" EURO SCREW - 4 113S BLACK 1-15/16" FLAT HEAD SCREW - 8 Page 4 428841 www.sauder.com/service...
  • Page 5 Push a HIDDEN CAM into Insert the CAM SCREW into the HIDDEN CAM. the part. The arrow in the Tighten the HIDDEN CAM. HIDDEN CAM must point toward the hole in the edge of the board. Hole www.sauder.com/service 428841 Page 5...
  • Page 6 Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
  • Page 7 LEFT UPRIGHT (C). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #4. Roller end Finished edge GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end Edge with holes Finished edge www.sauder.com/service 428841 Page 7...
  • Page 8 CAM DOWEL (2F) into each HIDDEN CAM. å Push four HIDDEN CAMS (1F) into the short edges of the SMALL SHELF (D). Do not tighten the HIDDEN CAMS in this step. Arrow Arrow Metal end Arrow Page 8 428841 www.sauder.com/service...
  • Page 9 Finished edge Edge with Finished edge CAM DOWELS D E N H I D i t h f a c S u r 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/service 428841 Page 9...
  • Page 10 Step 5 å Turn four CAM SCREWS (8F) into the CENTER REAR LEG (O). Page 10 428841 www.sauder.com/service...
  • Page 11 Fasten the CENTER REAR LEG (O) to the LEFT UPRIGHT (C). Use one SILVER 1-1/8" FLAT HEAD SCREW (10S). SILVER 1-1/8" FLAT HEAD SCREW (1 used in this step) The hole is closer to this edge. www.sauder.com/service 428841 Page 11...
  • Page 12 å Push four HIDDEN CAMS (1F) into one of the LARGE SHELVES (E). Arrow å Fasten the LARGE SHELF (E) to the CENTER REAR LEG (O). Tighten one HIDDEN CAM. Arrow These holes must be here. Page 12 428841 www.sauder.com/service...
  • Page 13 Step 8 å Turn four CAM SCREWS (8F) into the CENTER FRONT LEG (L). Don't worry. It isn't Rome. This can be built in a day. www.sauder.com/service 428841 Page 13...
  • Page 14 Fasten the CENTER FRONT LEG (L) to the LEFT UPRIGHT (C). Use one SILVER 1-1/8" FLAT HEAD SCREW (10S). SILVER 1-1/8" FLAT HEAD SCREW (1 used in this step) The hole is closer to this edge. Page 14 428841 www.sauder.com/service...
  • Page 15 Push four HIDDEN CAMS (1F) into the remaining set of UPRIGHTS (B and C). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Metal end www.sauder.com/service 428841 Page 15...
  • Page 16 LEFT UPRIGHT (C). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #4. Roller end Finished edge GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end Edge with holes Finished edge Page 16 428841 www.sauder.com/service...
  • Page 17 CAM DOWEL (2F) into each HIDDEN CAM. å Push four HIDDEN CAMS (1F) into the short edges of the SMALL SHELF (D). Do not tighten the HIDDEN CAMS in this step. Arrow Arrow Metal end Arrow www.sauder.com/service 428841 Page 17...
  • Page 18 Finished edge Edge with Finished edge CAM DOWELS D E N H I D i t h f a c S u r 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) Page 18 428841 www.sauder.com/service...
  • Page 19 Push four HIDDEN CAMS (1F) into the remaining LARGE SHELF (E). å Fasten the LARGE SHELF (E) to the LEGS (L and O). Tighten two HIDDEN CAMS. SILVER 1-1/8" FLAT HEAD SCREW (2 used in this step) Arrow These holes must be here. Arrow www.sauder.com/service 428841 Page 19...
  • Page 20 Push six HIDDEN CAMS (1F) into the FRONT SKIRTS (G). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Metal end Page 20 428841 www.sauder.com/service...
  • Page 21 SMALL SHELVES (D). Tighten six HIDDEN CAMS. Now might be a good time to refresh å Fasten the FRONT SKIRTS (G) to the LARGE your drink. SHELVES (E). Tighten six HIDDEN CAMS. These surfaces should be even. www.sauder.com/service 428841 Page 21...
  • Page 22 Step 17 å Turn four CAM SCREWS (8F) into the REAR LEGS (M and N). Page 22 428841 www.sauder.com/service...
  • Page 23 Fasten the LEFT REAR LEG (N) to the LEFT UPRIGHT (C). Use one SILVER 1-1/8" FLAT HEAD SCREW (10S). SILVER 1-1/8" FLAT HEAD SCREW (2 used in this step) These surfaces should be even. These surfaces should be even. www.sauder.com/service 428841 Page 23...
  • Page 24 Step 19 å Turn four CAM SCREWS (8F) into the FRONT LEGS (J and K). Page 24 428841 www.sauder.com/service...
  • Page 25 Fasten the LEFT FRONT LEG (K) to the LEFT UPRIGHT (C). Use one SILVER 1-1/8" FLAT HEAD SCREW (10S). SILVER 1-1/8" FLAT HEAD SCREW (2 used in this step) The hole is closer to this edge. www.sauder.com/service 428841 Page 25...
  • Page 26 Step 21 å Fasten the SIDE SKIRTS (H) to the LEGS (J, K, M, and N). Use four SILVER 1-1/8" FLAT HEAD SCREWS (10S). SILVER 1-1/8" FLAT HEAD SCREW (4 used in this step) Page 26 428841 www.sauder.com/service...
  • Page 27 Fasten the TOP (A) to the UPRIGHTS (B and C). Tighten eight help a friend, don't HIDDEN CAMS. leave without a bite. å NOTE: Be sure the WOOD DOWELS in the LEGS insert into the TOP. www.sauder.com/service 428841 Page 27...
  • Page 28 NOTE: Be sure to tap NAILS into the holes that line up over the CENTER REAR LEG (O). NAIL (38 used in this step) BLACK 9/16" EURO SCREW These holes (4 used in this step) must line up over the LEG (O). Page 28 428841 www.sauder.com/service...
  • Page 29 DOWEL (2F) into the HIDDEN CAM. Use five BLACK 1-9/16" FLAT HEAD SCREWS (30S). å Fasten the DRAWER BRACE (M65) to the DRAWER å Repeat this step for the remaining drawer. FRONT (P). Tighten one HIDDEN CAM. www.sauder.com/service 428841 Page 29...
  • Page 30 SLIDES with holes in DRAWER SIDES Roller end 176K SILVER 1/2" MACHINE SCREW (4 used for the PULLS) Drawer Slide GOLD 5/16" FLAT HEAD SCREW (8 used for the SLIDES) Center the screw in the oval hole. Page 30 428841 www.sauder.com/service...
  • Page 31 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. www.sauder.com/service 428841 Page 31...
  • Page 32 Note: This is a permanent label. Do not try to remove. Surface will be damaged. 6/19 2 6 9 2 2 4 269224 Scan to rate and review your piece at Sauder.com Your opinion matters! Page 32 428841 www.sauder.com/service...

  • Page 33: Liste De Pièces

    REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en DESSUS ................1 40CA ÉLÉMENT DROIT ............2 ce qui concerne cet MONTANT DROIT ............2 40CB ÉLÉMENT GAUCHE ..........2 élément, faire référence MONTANT GAUCHE ..........2 40CC TIROIR DROIT ..............2 au numéro de lot et...
  • Page 34 ! en métal de la CHEVILLE D'EXCENTRIQUE (2F) dans chaque • Cette unité Sauder est conçue pour les téléviseurs à écrans plats EXCENTRIQUE ESCAMOTABLE. pesant moins de 32 kg. Ne jamais utiliser avec des téléviseurs plus lourds.
  • Page 35 Fixer la PETITE TABLETTE (D) aux MONTANTS (B et C). Utiliser quatre VIS TÊTE PLATE 50 mm NOIRES (113S). REMARQUE : Il est préférable de donner quelques tours de tournevis à chaque VIS avant de les serrer toutes à bloc. www.sauder.com/service 428841 Page 35...
  • Page 36 REMARQUE : Prière de lire les informations importantes sur la en métal de la CHEVILLE D'EXCENTRIQUE (2F) dans sécurité figurant sur les pages arrière du manuel d’instructions. l'EXCENTRIQUE ESCAMOTABLE. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 36 428841 www.sauder.com/service...

  • Page 37: Lista De Partes

    40CA GABINETE DERECHO ..........2 su referencia futura. Si necesita ponerse en PARAL DERECHO ............2 40CB GABINETE IZQUIERDO ..........2 contacto con Sauder en PARAL IZQUIERDO ............2 40CC CAJÓN DERECHO .............2 cuanto a esta unidad, ESTANTE PEQUEÑO ..........2 40CD CAJÓN IZQUIERDO ..........2 refiérase al número...
  • Page 38 PASADOR DE EXCÉNTRICO (2F) en cada abajo - antes de comenzar el ensamblaje! EXCÉNTRICO ESCONDIDO. • Esta unidad Sauder está diseñada para ser usada con televisores de panel plano cuyo peso sea inferior a 32 Kg. Nunca PASO 2 la use para un televisor de mayor peso.
  • Page 39 Fije el ESTANTE PEQUEÑO (D) a los PARALES (B y C). Utilice cuatro PATAS DELANTERAS (J y K). TORNILLOS NEGROS DE CABEZA PLANA de 50 mm (113S). NOTA: Debe apretar cada TORNILLO unas vueltas antes de apretar cualquier tornillo firmemente. www.sauder.com/service 428841 Page 39...
  • Page 40 Esto completa el ensamblaje. Limpiar con un trapo húmedo. 3. Empuje un EXCÉNTRICO ESCONDIDO (1F) en la RIOSTRA DE Seque con un paño. CAJÓN (M65). A continuación, inserte el extremo de metal de un PASADOR DE EXCÉNTRICO (2F) en el EXCÉNTRICO ESCONDIDO. Page 40 428841 www.sauder.com/service...
