- Page 1 KERN & Sohn GmbH www.kern-sohn.com Ziegelei 1 +0049-[0]7433-9933-0 72336 Balingen-Frommern +0049-[0]7433-9933-149 Germany info@kern-sohn.com Operating instructions Ioniser KERN ABP-A01 TABP-A01-A Version 1.0 2024-12 TABP-A01-A-BA-e-2410...
-
Page 2: Table Of Contents
KERN ABP Version 1.0 2024-12 Operating instructions Ioniser Contents About this document ..................4 Document purpose ..................4 Other versions of the document ..............4 Presentation conventions ................4 General safety information ................5 Meaning of the warnings ................5 Safe handling of packaging material.............. - Page 3 7.1.1 Safety during cleaning ..................17 7.1.2 Recommended cleaning ................... 17 Maintenance ....................18 7.2.1 Safety during maintenance ................18 7.2.2 Maintenance schedule ..................18 Warranty and returns ..................19 Guarantee ....................19 Return shipment (returns) ................19 Waste disposal ....................20 Troubleshooting ...................
-
Page 4: About This Document
This document was created in German. We reserve the right to make subsequent changes to the product documentation. The current version and other language ver- sions of the document can be found on our website www.kern-sohn.com. 1.3 Presentation conventions Representation Meaning ... -
Page 5: General Safety Information
2 General safety information 2.1 Meaning of the warnings Warnings warn you of possible safety risks during certain activities. Read the warnings in full and follow the instructions. Failure to do so may result in injury, damage to prop- erty, environmental damage, malfunctions or incorrect results. Meaning of the signal words Signal word Meaning... -
Page 6: Safe Handling Of Power Supply Units
• Only use original power supply units and connection cables. If you need a replacement, please contact your dealer or KERN & SOHN Ser- vice. • Work on the electrical equipment of the appliance may only be carried out by KERN &... -
Page 7: Required Qualification Of Users
• Commissioning outdoors and in vehicles is not permitted, as this will invalidate any warranty 2.6 Required qualification of users The appliance may only be operated and maintained by trained personnel. The user must be mentally and physically capable of operating the appliance. 2.7 Safe handling of ionisers •... -
Page 8: Authorised Use Environment
2.8 Authorised use environment • Never operate the ioniser in potentially explosive atmospheres. • Do not use the device in environments with flammable gases or solvents. • Avoid operation in environments with water, oil, high humidity, dust or vapours. • Take particular care to avoid condensation on the appliance. This can occur if a cold appliance is brought into a significantly warmer environment. -
Page 9: Description Of The Device
3 Description of the device 3.1 General product description This device is an ioniser. Ionisers are used together with electronic scales to neutral- ise electrostatic charges on samples or containers that could affect the accuracy of weighing. 3.2 Overview of the device Pos. -
Page 10: Unpacking, Transport And Handling
4 Unpacking, transport and handling 4.1 Unpacking and checking the device ⚠ WARNING Risk of tripping or suffocation due to packaging material Packaging material lying on the floor can be a tripping hazard. Unattended packaging material can be a choking hazard for children or animals. -
Page 11: Scope Of Delivery
4.2 Scope of delivery Ioniser Ioniser holder Power supply unit Cleaning brush Mains cable Connection cable Operating instructions The illustrations are examples (actual appearance may vary 4.3 Transporting the device • Always transport the appliance carefully to avoid damage. • Use the original packaging for transport to protect the device from dirt and im- pact. -
Page 12: Assembly, Installation And Commissioning
5 Assembly, installation and commissioning 5.1 Install holder Attach the ioniser to the holder at the desired height using the adjusting screw (attachment is possible on the back or on the side [1]) 5.2 Connecting the ioniser to the scale Example: Here the connection is labelled "IONIZER"... -
Page 13: Network Operation
5.3 Network operation ⚠ WARNING Serious injuries due to damaged power supply units Damaged power supply units can lead to short circuits, fires and se- rious injuries. Before each use, check the power supply unit and power cable for visible damage. -
Page 14: Operation
6 Operation 6.1 Switching on and off Switch on Switch on / off switch to ( I ) o Green LED lights up o Device is switched on Switch off Switch on / off switch to ( O ) o Green LED goes out o Device is switched off If the red LED lights up, switch off the appliance, wait briefly and then... - Page 15 • The ioniser generates noise during ion generation. This is not a malfunction. • The ioniser may heat up slightly during operation. This does not constitute a malfunction. • Any options for controlling the ioniser via the scale can be found in the relevant operating instructions for the scale.
- Page 16 Examples for the application Application Remark Application with Electrostatically charged samples or contain- holder: ers can lead to unstable measurements. Adjust the height and angle of the ion- Remove electro- static charge from iser so that it is aligned with the sam- samples or contain- ples or containers.
-
Page 17: Care, Maintenance And Servicing
7 Care, maintenance and servicing 7.1 Cleaning gung 7.1.1 Safety during cleaning ⚠ DANGER Electric shock due to live parts Contact with live parts can lead to electric shock and burns Disconnect live parts from the power supply Disconnect the mains plug from the power supply ... -
Page 18: Maintenance
The device may only be opened by trained service technicians authorised by KERN. 7.2.2 Maintenance schedule Maintenance Interval Personnel Cleaning the electrode pro- Trained user Every 1000 hours Replacing the electrode Service technicians authorised Every 30000 hours probes by KERN TABP-A01-A-BA-e-2410... -
Page 19: Warranty And Returns
8 Warranty and returns 8.1 Guarantee Warranty expires with • Non-compliance with our specifications in the operating instructions • Use outside the described applications • Modifying or opening the device • Mechanical damage damage caused media, liquids , natural wear and tear •... -
Page 20: Waste Disposal
9 Waste disposal Damage to people and the environment due to improper disposal Non-degradable materials (e.g. plastics or metals) can enter the environment and cause damage. Non-recycled material is a waste of resources and leads to increased environmental pollution. Electrical appliances may contain substances that are not biodegradable and are harmful to the environment and human health. -
Page 21: Troubleshooting
10 Troubleshooting If there is a fault in the programme sequence, the appliance should be switched off briefly and disconnected from the mains. Malfunction Possible cause Power LED does not light up • Device is not switched on. • Connection to the mains is interrupted (mains ca- ble not plugged in/defective). -
Page 22: Product Specification
AC 100 - 240 V, 50 / 60 Hz Degree of soiling Overvoltage category Installation site Only in closed rooms Weight 0.85 kg Dimensions 124 x 87 x 49 mm 11.2 Declaration of Conformity You can find the current EC/EU Declaration of Conformity online at www.kern- sohn.com/ce TABP-A01-A-BA-e-2410...
