Summary of Contents for Vivo PS-M-100
- Page 1 100” Manual Projector Screen 16:9 PS-M-100 Assembly Manual...
- Page 2 Better Products for a Better Workspace Experience We are dedicated to creating high-end ergonomic solutions for the office with top of the industry support. Explore Endless Workspace Solutions www.vivo-us.com...
- Page 3 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 4: Package Contents
Package Contents A (x1) Projector Screen Included Hardware & Tools W-A (x2) W-B (x2) W-C (x2) Mounting ST4.2x30mm Concrete Hook Screw Anchor Tools Needed: Ladder Tape Level Pencil Drill Measure Hammer Wrench Phillips Screwdriver... - Page 5 Choose a Mounting Option Determine your intended mounting surface and follow instructions as identified below.
-
Page 6: Assembly Steps
Assembly Steps STEP 1 - Mounting Option 1 - Solid Wood Wall Mounting Using a pencil and a level, mark two mounting holes 7.562ft (2305mm) apart on the wall, ensuring they are aligned horizontally. The Projector Screen must be installed over 8.2’(2.5m) off the ground to allow for full extension. - Page 7 Solid Wood Wall Mounting -Cont’d Partially insert ST4.2x30mm Screw (W-B) into the wall, leaving a 4mm gap between the screw head and the wall. Do NOT use included Anchors (W-B) for wood or drywall. Carefully hang Projector Screen (A) onto Screws using the Keyhole Slots. Use the Keyhole Slots on the back of the Housing.
- Page 8 - Mounting Option 2 - Concrete/Brick Wall Mounting Using a pencil and a level, mark two mounting holes 7.562ft (2305mm) apart on the wall, ensuring they are aligned horizontally. The Projector Screen must be installed over 8.2’(2.5m) off the ground to allow for full extension. Drill mounting holes at marked locations using the infographic below.
- Page 9 Concrete/Brick Wall Mounting -Cont’d Insert Concrete Anchors (W-C) into mounting holes. Partially insert ST4.2x30mm Screws (W-B) into the Anchors, leaving a 4mm gap between the screw head and the wall. Carefully hang Projector Screen (A) onto Screws using the Keyhole Slots. Use the Keyhole Slots on the back of the Housing.
- Page 10 - Mounting Option 3 - Concrete Ceiling Mounting Using a pencil, mark two mounting holes 7.562ft (2305mm) apart on the ceiling, ensuring they are aligned horizontally. Drill mounting holes at marked locations using the infographic below. Drill Bit: 5/16” (8mm) Hole Depth: 1.4”...
- Page 11 Concrete Ceiling Mounting -Cont’d Using a hammer, insert Mounting Hooks (W-A) into drilled mounting holes until the Washers (W-A1) are against the ceiling. W-A1 Turn the Nut (W-A2) with a wrench until the metal sleeve expands, securing the Mounting Hook (W-A) in place. W-A2...
- Page 12 Concrete Ceiling Mounting -Cont’d Carefully hang Projector Screen (A) onto Mounting Hooks (W-A) using the Rings. Ring...
- Page 13 STEP 2 Pull Down To pull the Screen down, use steady pressure to pull downward. The Screen will lock automatically when you stop pulling. Be sure to stop pulling the Screen downward when top Black Border appears, as over-pulling can damage product. Release Back Up To release the Screen back up, pull the Screen slightly downward, which will release automatic lock.
- Page 14 Cleaning If Screen becomes dirty, wipe gently with a soft cloth. Do NOT use solvents to clean screen surface.
- Page 15 Love Your New Setup? Tag Us on Social! @ VIVO-us @ vivo_us @VIVOus VIVO...
- Page 16 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
