INSTRUCTION MANUAL
REGULATED DC POWER SUPLY
PAK-A SERIES
PAK-AM SERIES
PAK6-60A
PAK10-35A
PAK35-10A
PAK60-6A
PAK10-70A
PAK20-36A
PAK60-12A
PAK6-160A
PAK20-50A
PAK35-30A
PAK6-60AM
PAK10-35AM
PAK35-10AM
PAK60-6AM
PAK10-70AM
PAK20-36AM
PAK60-12AM
PAK6-160AM
PAK20-50AM
PAK35-30AM
Part No. Z1-001-872, IA001036
Oct. 2009
PAK20-18A
PAK6-120A
PAK35-20A
PAK10-100A
PAK60-18A
PAK20-18AM
PAK6-120AM
PAK35-20AM
PAK10-100AM
PAK60-18AM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kikusui PAK-A Series
Summary of Contents for Kikusui PAK-A Series
- Page 1 Part No. Z1-001-872, IA001036 Oct. 2009 INSTRUCTION MANUAL REGULATED DC POWER SUPLY PAK-A SERIES PAK-AM SERIES PAK6-60A PAK10-35A PAK20-18A PAK35-10A PAK60-6A PAK6-120A PAK10-70A PAK20-36A PAK35-20A PAK60-12A PAK6-160A PAK10-100A PAK20-50A PAK35-30A PAK60-18A PAK6-60AM PAK10-35AM PAK20-18AM PAK35-10AM PAK60-6AM PAK6-120AM PAK10-70AM PAK20-36AM PAK35-20AM...
- Page 2 If you find any incorrectly arranged or missing pages in this manual, they will be replaced. If the manual it gets lost or soiled, a new copy can be provided for a fee. In either case, please contact Kikusui distributor/agent, and provide the “Kikusui Part No.” given on cover.
-
Page 3: Power Requirements Of This Product
Power Requirements of this Product Power requirements of this product have been changed and relevant sections of the Operation Manual should be revised accordingly. (Revision should be applied to items indicated by a check mark ✓ Input voltage The input voltage of this product is Vac, and the voltage range is Vac. -
Page 4: Power Cord
Black (LIVE) Brown (LIVE) Green/Yellow (GND) Green or Green/Yellow (GND) Plug for USA Plug for China Plug for Europe NEMA5-15 CEE7/7 GB1002 Provided by Kikusui distributor/agent Kikusui agents can provide you with suitable power cord. For further information, contact Kikusui distributor/agent. -
Page 5: Installation
AC power cable. • Do not remove the cover when performing maintenance or inspection. There are parts inside the product which may cause physical hazards. Consult your Kikusui distributor or agent before uncover the products in case if it is so necessary. - Page 6 TABLE OF CONTENTS Page GENERAL......................1-1 1.1 Description ......................1-1 SPECIFICATIONS ....................2-1 2.1 PAK350W Specifications................2-1 2.2 PAK700W Specifications................2-5 2.3 PAK1000W Specifications................2-9 2.4 PAK-A/AM Series Block Diagram ..............2-13 2.5 Mechanical Outline Drawing.................2-14 2.6 Accessories ....................2-16 OPERATION INSTRUCTIONS ................3-1 3.1 General Precautions..................3-1 3.2 Layouts and Functions of Panel Items ............3-5 3.3 Remote Sensing and Remote Control............3-12 3.3.1...
- Page 7 www.valuetronics.com...
- Page 8 www.valuetronics.com...
-
Page 9: Specifications
2. SPECIFICATIONS 2.1 PAK350W Specifications Standard type 6-60A 10-35A 20-18A 35-10A 60-6A Module type 6-60AM 10-35AM 20-18AM 35-10AM 60-6AM AC input 85 V to 132 VAC (170 V to 250 VAC 47 Hz to 63 Hz, single phase DC output Voltage Variable range 0 V to 6 V... - Page 10 Standard type 6-60A 10-35A 20-18A 35-10A 60-6A Module type 6-60AM 10-35AM 20-18AM 35-10AM 60-6AM Constant-current characteristics Stability Source effect For ±10 % change of line voltage 0.2 %+5 mA Load effect For 1 V to 100 % change of output current 0.2 %+5 mA Ripple and noise (PARD) 120 mA 70 mA...
- Page 11 Standard type 6-60A 10-35A 20-18A 35-10A 60-6A Module type 6-60AM 10-35AM 20-18AM 35-10AM 60-6AM Environment conditions Operating ambient 0 ˚C to 50 ˚C temperature range Operating ambient 30 % to 80 % RH humidity range -20 ˚C to 70 ˚C Storage temperature range Storage humidity range 20 % to 80 % RH...
- Page 12 50 % voltage→ For conversion into the nominal 200V system (170 V to 250 VAC), consult your Kikusui agent. Do not attempt to convert the power supply for yourself. The output as delivered via the rear output terminals and measured at the rear output terminals.
- Page 13 2.2 PAK700W Specifications Standard type 6-120A 10-70A 20-36A 35-20A 60-12A Module type 6-120AM 10-70AM 20-36AM 35-20AM 60-12AM AC input 85 V to 132 VAC (170 V to 250 VAC 47 Hz to 63 Hz, single phase DC output Voltage Variable range 0 V to 6 V 0 V to 10 V 0 V to 20 V 0 V to 35 V 0 V to 60 V Adjustment...
- Page 14 Standard type 6-120A 10-70A 20-36A 35-20A 60-12A Module type 6-120AM 10-70AM 20-36AM 35-20AM 60-12AM Constant-current characteristics Stability Source effect For ±10 % change of line voltage 0.2 %+10 mA Load effect For 1 V to 100 % change of output current 0.2 %+10mA Ripple and noise (PARD) 260 mA 160 mA...
- Page 15 Standard type 6-120A 10-70A 20-36A 35-20A 60-12A Module type 6-120AM 10-70AM 20-36AM 35-20AM 60-12AM Environment conditions Operating ambient 0 ˚C to 50 ˚C temperature range Operating ambient 30 % to 80 % RH humidity range -20 ˚C to 70 ˚C Storage temperature range Storage humidity range 20 % to 80 % RH...
- Page 16 100 % voltage→ For conversion into the nominal 200V system (170 V to 250 VAC), consult your Kikusui agent. Do not attempt to convert the power supply for yourself. The output as delivered via the rear output terminals and measured at the rear output terminals.
- Page 17 2.3 PAK1000W Specifications Standard type 6-160A 10-100A 20-50A 35-30A 60-18A Module type 6-160AM 10-100AM 20-50AM 35-30AM 60-18AM AC input 85 V to 132 VAC (170 V to 250 VAC 47 Hz to 63 Hz, single phase DC output Voltage Variable range 0 V to 6 V 0 V to 10 V 0 V to 20 V 0 V to 35 V 0 V to 60 V Adjustment...
- Page 18 Standard type 6-160A 10-100A 20-50A 35-30A 60-18A Module type 6-160AM 10-100AM 20-50AM 35-30AM 60-18AM Constant-current characteristics Stability Source effect For ±10 % change of line voltage 0.2 %+15 mA Load effect For 1 V to 100 % change of output current 0.2 %+15 mA Ripple and noise (PARD) 340 mA 220 mA...
- Page 19 Standard type 6-160A 10-100A 20-50A 35-30A 60-18A Module type 6-160AM 10-100AM 20-50AM 35-30AM 60-18AM Environment conditions Operating ambient 0 ˚C to 50 ˚C temperature range Operating ambient 30 % to 80 % RH humidity range -20 ˚C to 70 ˚C Storage temperature range Storage humidity range 20 % to 80 % RH...
- Page 20 100 % voltage→ For conversion into the nominal 200V system (170 V to 250 VAC), consult your Kikusui agent. Do not attempt to convert the power supply for yourself. The output as delivered via the rear output terminals and measured at the rear output terminals.
- Page 21 www.valuetronics.com...
- Page 22 www.valuetronics.com...
- Page 23 www.valuetronics.com...
- Page 24 www.valuetronics.com...
- Page 25 www.valuetronics.com...
- Page 26 www.valuetronics.com...
- Page 27 www.valuetronics.com...
- Page 28 www.valuetronics.com...
- Page 29 www.valuetronics.com...
- Page 30 www.valuetronics.com...
- Page 31 www.valuetronics.com...
- Page 32 www.valuetronics.com...
- Page 33 3.2 Layouts and Functions of Panel Items Front view (350 W) Front view (700 W) Rear view (350 W) Rear view (700 W) 3−5 www.valuetronics.com...
- Page 34 Front view (1000 W) Rear view (1000 W) 3−6 www.valuetronics.com...
- Page 35 www.valuetronics.com...
- Page 36 www.valuetronics.com...
- Page 37 www.valuetronics.com...
- Page 38 www.valuetronics.com...
- Page 39 www.valuetronics.com...
- Page 40 www.valuetronics.com...
- Page 41 www.valuetronics.com...
- Page 42 www.valuetronics.com...
- Page 43 www.valuetronics.com...
- Page 44 www.valuetronics.com...
- Page 45 www.valuetronics.com...
- Page 46 www.valuetronics.com...
- Page 47 www.valuetronics.com...
- Page 48 www.valuetronics.com...
- Page 49 www.valuetronics.com...
- Page 50 www.valuetronics.com...
- Page 51 www.valuetronics.com...
- Page 52 www.valuetronics.com...
- Page 53 www.valuetronics.com...
- Page 54 www.valuetronics.com...
- Page 55 www.valuetronics.com...
- Page 56 www.valuetronics.com...
- Page 57 www.valuetronics.com...
- Page 58 www.valuetronics.com...
- Page 59 www.valuetronics.com...
- Page 60 www.valuetronics.com...
- Page 61 www.valuetronics.com...
- Page 62 www.valuetronics.com...
- Page 63 www.valuetronics.com...
- Page 64 www.valuetronics.com...
- Page 65 www.valuetronics.com...
- Page 66 www.valuetronics.com...
- Page 67 www.valuetronics.com...
- Page 68 www.valuetronics.com...
- Page 69 www.valuetronics.com...
- Page 70 www.valuetronics.com...
- Page 71 www.valuetronics.com...
- Page 72 www.valuetronics.com...
- Page 73 www.valuetronics.com...
