Instruction Manual
VWR
LCD Digital Rotary Evaporator
®
North America Catalogue Number(s):
76533-248 （VWR EVAPORATOR
LCD ROTARY SET V17）
76533-250 （VWR EVAPORATOR
LCD ROTARY SET V17C）
76533-252（VWR EVAPORATOR
LCD ROTARY SET D17）
76533-254（VWR EVAPORATOR
LCD ROTARY SET V12）
Main Unit
Heating Bath
76533-232
76533-246
76533-232
76533-246
76533-232
76533-246
76533-232
76533-246
Glassware
76533-238(Vertical, 1700cm²)
76533-240(Vertical,1700cm²,
Coated)
76533-242(Diagonal, 1700cm²)
76533-244(Vertical, 1200cm²)
Version01
Issue 12/06/2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VWR 76533-248
Summary of Contents for VWR 76533-248
- Page 1 Instruction Manual LCD Digital Rotary Evaporator ® North America Catalogue Number(s): Main Unit Heating Bath Glassware 76533-248 （VWR EVAPORATOR 76533-232 76533-246 76533-238(Vertical, 1700cm²) LCD ROTARY SET V17） 76533-250 （VWR EVAPORATOR 76533-240(Vertical,1700cm², 76533-232 76533-246 LCD ROTARY SET V17C） Coated) 76533-252（VWR EVAPORATOR...
- Page 2 Legal address of Manufacturer United States VWR International LLC 100 Matsonford Rd Radnor, PA 19087 +1 800-932-5000 www.vwr.com Country of Origin China Version01 Issue 12/06/2021...
-
Page 3: Table Of Contents
Table of Contents Warning ............................4 Safety Information ........................4 Package Contents ..........................7 Unpacking ............................ 7 Installation ............................8 Intended use ..........................11 Symbols and conventions ......................11 Product Specifications ........................ 12 Overview ............................ 13 Description of Buttons and Switches ...................13 Operation ........................... 15 Troubleshooting .......................... -
Page 4: Warning
Warning Please carefully read the Instructions and use the product safely under the direction of the Instructions. • Our products are under the patent protection of the origin country and other countries and regions (including obtained patents and patents being applied for). •... - Page 5 surface. • Ensure that there is sufficient space above the device as the glass assembly may exceed the height of the device. • Prior to each use, always check the device, accessories and especially the glass parts for damage. Do not use damaged components. •...
- Page 6 during the heating phase. • The glassware is designed for operation under a vacuum of up to 10 mbar. The equipment must be evacuated prior to heating (see chapter “Commissioning”). The equipment must only be aired again after cooling. When carrying out vacuum distillation, uncondensed vapors must be condensed out or safely dissipated.
-
Page 7: Package Contents
Package Contents Product Description Quantity Main unit (76533-232) Instruction manual Quick Guide Wrench Fuse12.5A Main unit Fuse12.5A Vapor Tube Fastening Frame Loop Fastener Power Cable (USA Plug) Heating bath Heating bath (76533-246) 76533-238(Vertical condenser, 1700cm²) 76533-240(Vertical condenser,1700cm², Coated) 76533-242(Diagonal condenser, 1700cm²) 76533-244 (Vertical condenser, 1200cm²) Glassware set Evaporating flask(1000ml) -
Page 8: Installation
Installation • Adjustable base (Figure 1). Figure 1 CAUTION! Loosen transportation lock Figure 2). • Hold the lift with your hand on the height position and remove the thumb screw on the back of the appliance (a). • Once the transportation lock has been removed, the lift moves slowly to its upper end position. The distance is 150mm. - Page 9 Figure 3 • Open the locking device on the drive head by turning it 60° counter clockwise (e), (Figure 4). • Feed the steam pipe in until it stops. • Then lock the locking device by turning it clockwise by 60°. •...
- Page 10 the cap nut firmly. Figure 7 Figure 8 • Installing the vertical glassware condenser locking device (Figure 9). Use the transportation screw on the back of the appliance (a) Figure 9 • Connecting tubes (Figure 10). Figure 10 10 / 20...
-
Page 11: Intended Use
Intended use This instrument is designed for such application environments as schools, labs and factories, in conjunction with the optional accessories recommended by the manufacturer, which may be used for: • Rapid softening of distilled liquid • Distillation of solutions or suspensions •... -
Page 12: Product Specifications
Product Specifications Item Specifications Voltage [VAC] 100-120 Frequency [Hz] 50/60 Power [W] 1400 Motor External rotor brushless motor Speed Range [rpm] 20-280 Speed Display Reversible Direction of Rotation Temperature range [°C] RT -180 Heat Control Accuracy [°C] ±1 Temperature Display Heat Output[W] 1300 Lift... -
Page 13: Overview
Overview Welcome to choose our products. Users should read this Manual carefully, follow the instructions and procedures, and be aware of all the cautions when using this instrument. Fig. 1 Description of Buttons and Switches Fig. 2 Fig. 3 13 / 20... - Page 14 Fig. 4 Name Description Speed key Speed Push the key and then rotate control knob to set the rated speed in the range from 20 to 280. Temperature key Temp Push the key and then rotate control knob to set the rated temperature in the range from room temperature to 180°C.
-
Page 15: Operation
Display Description Temperature display When setting temperature, displaying the setting value. When the heating function is area switched ON, displaying the real value. Temperature Display when the heating function is switched ON. Timer display area When setting timer, displaying the rated time. When the timer function is switched ON, displaying remaining time. -
Page 16: Maintenance And Cleaning
Maintenance and Cleaning Operate and maintain the product properly, so that it is in a good working state, which can extend the service life of the product. In routine service, keep the product dry and clean, remove the spilled liquid quickly, clean the outer surface with a non-grinding cleaner, and do not connect the power supply until all surfaces are dry. -
Page 17: User Replaceable Accessories And Spare Parts
76533-288 VWR CONNECTOR NS24/40 NS14/20 76533-290 VWR BRAKE FOAM 250ML 76533-292 VWR VAPOR TUBE 76533-294 VWR DISTILLATION SPIDER 50ML W/OUT FLASK 76533-296 VWR RUBBER RING PTFE 76533-298 VWR RING RUBBER FULL FLUORINE ETHER 76533-300 VWR CLIP EVAPORATION FLASK RED 76533-302... -
Page 18: Technical Service
(2) years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the purchase price of this product to the customer, provided it is returned during the warranty period. -
Page 19: Equipment Disposal
Equipment disposal This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not be disposed of with unsorted waste. Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling it over to an authorized facility for separate collection and recycling. - Page 20 2360 Argentia Road Mississauga, Ontario L5N 5Z7 Tel.: +1 800 932 5000 Email: canadainfo@avantorsciences.com Mexico VWR International S. de R.L. de C.V Carretera Tlalnepantla-Cuautitlán Km 14.5 Colonia Lechería, Tultitlan, Edo. México, CP 54940 Tel.: +800 759 8974 Email: mdl_mx_csr@AvantorSciences.com Puerto Rico VWR Advanced Instruments LLC Bo.
