VWR
European Catalogue Number(s):
LCD Rotary Evaporator, set V17, bath
LCD Rotary Evaporator, set V17C, bath
LCD Rotary Evaporator, set D17, bath
LCD Rotary Evaporator, set V12, bath
Version:
1
Issued:
25, May, 2020
®
LCD Digital Rotary Evaporator
INSTRUCTION MANUAL
Main Unit
531-1368
531-1368
531-1368
531-1368
Heating Bath Glassware
531-1382
531-1375(
531-1382
531-1376(
531-1382
531-1378(
531-1382
531-1380(
)
Vertical, 1700cm²
Vertical,1700cm² ,Coated
)
Diagonal, 1700cm²
)
Vertical, 1200cm²
)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VWR 531-1368
Summary of Contents for VWR 531-1368
- Page 1 ® LCD Digital Rotary Evaporator INSTRUCTION MANUAL European Catalogue Number(s): Main Unit Heating Bath Glassware LCD Rotary Evaporator, set V17, bath 531-1368 531-1382 531-1375( Vertical, 1700cm² LCD Rotary Evaporator, set V17C, bath 531-1368 531-1382 531-1376( Vertical,1700cm² ,Coated LCD Rotary Evaporator, set D17, bath...
- Page 2 Legal Address of Manufacturer Europe VWR International bv ResearchparkHaasrode 2020 Geldenaaksebaan 464 B-3001 Leuven + 32 16 385011 http://be.vwr.com Country of origin P. R. CHINA 2 / 20...
-
Page 3: Table Of Contents
Table of Contents Warning ............................ 4 Safety Information ........................4 Package Contents ........................7 Unpacking ..........................7 Installation ..........................8 Intended use ..........................11 Symbols and conventions ......................11 Product Specifications ......................12 Overview ..........................13 Description of Buttons and Switches ..................13 Operation .......................... -
Page 4: Warning
Warning Please carefully read the Instructions, and use the product safely under the direction of the Instructions. • Our products are under the patent protection of the origin country and other countries and regions (including obtained patents and patents being applied for). •... - Page 5 surface. • Ensure that there is sufficient space above the device as the glass assembly may exceed the height of the device. • Prior to each use, always check the device, accessories and especially the glass parts for damage. Do not use damaged components. •...
- Page 6 during the heating phase. • The glassware is designed for operation under a vacuum of up to 10 mbar. The equipment must be evacuated prior to heating (see chapter “Commissioning”). The equipment must only be aired again after cooling. When carrying out vacuum distillation, uncondensed vapors must be condensed out or safely dissipated.
-
Page 7: Package Contents
Package Contents Product Description Quantity Main unit Instruction manual Quick Guide Wrench Fuse6.3A Main unit Fuse1A Vapor Tube Fastening Frame Loop Fastener Power Cable(Euro/UK/CH Plug) Heating bath Heating bath 531-1375(Vertical condenser, 1700cm² ) 531-1376(Vertical condenser,1700cm² ,Coated) 531-1378(Diagonal condenser, 1700cm² ) 531-1380(Vertical condenser, 1200cm²... -
Page 8: Installation
Installation • Adjustable base (Figure 1). Figure 1 CAUTION! Loosen transportation lock Figure 2). • Hold the lift with your hand on the height position and remove the thumb screw on the back of the appliance (a). • Once the transportation lock has been removed, the lift moves slowly to its upper end position. The distance is 150mm. - Page 9 Figure 3 • Open the locking device on the drive head by turning it 60° counter clockwise (e), (Figure 4). • Feed the steam pipe in until it stops. • Then lock the locking device by turning it clockwise by 60° . •...
- Page 10 the cap nut firmly. Figure 7 Figure 8 • Installing the vertical glassware condenser locking device (Figure 9). Use the transportation screw on the back of the appliance (a) Figure 9 • Connecting tubes (Figure 10). Figure 10 10 / 20...
-
Page 11: Intended Use
Intended use This instrument is designed for such application environments as schools, labs and factories, in conjunction with the optional accessories recommended by the manufacturer, which may be used for: • Rapid softening of distilled liquid • Distillation of solutions or suspensions •... -
Page 12: Product Specifications
Product Specifications Item Specifications Voltage [VAC] 100-240 Frequency [Hz] 50/60 Power [W] 1400 Motor External rotor brushless motor Speed Range [rpm] 20-280 Speed Display Reversible Direction of Rotation Temperature range [° C] RT -180 ±1 Heat Control Accuracy [° C] Temperature Display Heat Output[W] 1300... -
Page 13: Overview
Overview Welcome to choose our products. Users should read this Manual carefully, follow the instructions and procedures, and be aware of all the cautions when using this instrument. Fig. 1 Description of Buttons and Switches Fig. 2 Fig. 3 13 / 20... - Page 14 Fig. 4 Name Description Speed key Speed Push the key and then rotate control knob to set the rated speed in the range from 20 to 280. Temperature key Temp Push the key and then rotate control knob to set the rated temperature in the range from room temperature to 180°...
-
Page 15: Operation
Display Description Temperature display When setting temperature, displaying the setting value. When the heating function is area switched ON, displaying the real value. Temperature Display when the heating function is switched ON. Timer display area When setting timer, displaying the rated time. When the timer function is switched ON, displaying remaining time. -
Page 16: Maintenance And Cleaning
Maintenance and Cleaning Operate and maintain the product properly, so that it is in a good working state, which can extend the service life of the product. In routine service, keep the product dry and clean, remove the spilled liquid quickly, clean the outer surface with a non-grinding cleaner, and do not connect the power supply until all surfaces are dry. -
Page 17: User Replaceable Accessories And Spare Parts
User replaceable accessories and spare parts Description Quantity Cat. No. Glassware set V17 531-1375 Glassware set V17C 531-1376 Glassware set D17 531-1378 Glassware set V12 531-1380 Evaporating flask 50ml 531-1384 Evaporating flask 100ml 531-1385 Evaporating flask 250ml 531-1386 Evaporating flask 500ml 531-1387 Evaporating flask 1000ml 531-1388... -
Page 18: Technical Service
(2) years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the purchase price of this product to the customer, provided it is returned during the warranty period. - Page 19 Equipment disposal This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not be disposed of with unsorted waste. Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling it over to an authorized facility for separate collection and recycling.
- Page 20 Local VWR offices in Europe and Asia Pacific Austria Germany Poland VWR International GmbH VWR International GmbH VWR International Sp. z o.o. Graumanngasse 7 Hilpertstrasse 20a Limbowa 5 1150 Vienna D - 64295 Darmstadt 80-175 Gdansk Tel.: +43 1 97 002 0 Freecall: 0800 702 00 07 Tel.: +48 058 32 38 210...
