User manual
Wireless keyboard Prestigio Click&Touch 2
Read Before Using
Thank you for choosing the Prestigio Click&Touch 2
multimedia keyboard. Please read this manual before you
start. This will help you operate it safely and make the best
use of all its features. Do not discard the manual, as you
may have to refer to it in the future.
Please note that the design and position of certain
elements may differ from the images and descriptions you
will find below because, as part of its commitment to
continuous improvement, the manufacturer reserves the
right to alter the charger's specifications without prior
notice.
The company will not be held liable for damage caused by
improper use of the charger.
The purpose of this manual is to provide information, and
it does not constitute any overt or covert warranty.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Prestigio Click&Touch 2
Summary of Contents for Prestigio Click&Touch 2
- Page 1 User manual Wireless keyboard Prestigio Click&Touch 2 Read Before Using Thank you for choosing the Prestigio Click&Touch 2 multimedia keyboard. Please read this manual before you start. This will help you operate it safely and make the best use of all its features. Do not discard the manual, as you may have to refer to it in the future.
- Page 2 For the latest updates, as well as Warranty and Service Conditions and valid Certificates, go to www.prestigio.com. Benefits of Prestigio Click&Touch 2 wireless keyboard The Prestigio Click&Touch 2 is a multimedia wireless keyboard with a built-in keys touch panel. Its features and ergonomic design ensure unlimited control in any position.
- Page 3 • Various connections: 3x Bluetooth (10 m) and 1x USB Cable (1.4 m); • Mobile application for settings and feature updates; • Support of keyboard media functions on Windows, Mac OS, iPad OS and Android devices; • Wide multimedia capabilities. Product Bundle Wireless keyboard 1 pc.
- Page 4 1. Area of Left/Right key simulation. It is used for video scrolling, cursor movements in the text, etc. (F1 to F6) 2. Volume control keys (F7 to F12) 3. On/Off switch 4. LED status and charge indicator: • Purple (On): USB Cable connection; •...
- Page 5 When the Keyboard is OFF • Red (On): the battery is charging; • Green (On): the battery is charged (charge level above 95%). 5. Touch panel keys 6. Non-touch panel keys 7. Left-side mouse button 8. Right-side mouse button. F1-F3 Keys to connect via Bluetooth channel Key to connect via USB Cable Setting mode (connection to the application) Back key...
- Page 6 Mac OS Android 6.0 and higher iPad 13.6 and higher Operating frequency 2.4 GHz Connection Bluetooth 4.2 / USB Type-C cable Signal range Up to 10 meters Operating voltage 5.0 V Battery type Li-ion Polymer Non- Removable Battery Charging current 1800 mA Charging time Up to 2 hours...
- Page 7 Warranty period 1 year Service life 2 years Certificates CE, RoHS, EAC, UA.TR Operation guide When first powered on, the keyboard is recommended to be connected to the power supply via the USB cable for battery charging. 1. Turn on the keyboard (ON/OFF switch located on its top side panel.
- Page 8 1. Press and hold for 3 seconds the selected channel (F1, F2 or F3 buttons). The LED indicator will start blinking quickly, which means that the keyboard is in the pairing mode and will be available for search for 2 minutes. 2.
- Page 9 Connect the keyboard to the selected device (PC, Mac, Android, etc.) via the USB-A / USB-C cable – the keyboard will automatically switch to the USB interface from any previously used interface. If the keyboard was previously connected to any device via another communication channel, then reconnection to the device connected via the USB-A / USB-C cable will occur.
- Page 10 Fn + R Activate multimedia keys on an iPad OS device Fn + Tab Turn off the touch function (until the keyboard restarts) Fn + Esc Switch between F key usage modes: multimedia functions / standard F1-F12 key functions Fn + Delete Reset to factory settings Аlt + space Language switching in Samsung-...
- Page 11 Press and hold Reboot the keyboard the start button 5 sec * On the first start, keyboard layout for Windows is used by default. To call the menu in smart TV – you must click on Win (for some models). ** The recommended scrolling speed setting on OSX is minimal.
- Page 12 the keyboard surface or touch it with a finger. Cursor moving and clicks shall be performed as follows: - left click: (tap) the keyboard surface with one finger; - right клик: Touch (tap) the keyboard surface with two fingers; - cursor control: move one finger over the keyboard surface;...
- Page 13 fingers): - left / right – to switch between open windows; - up – to view all open windows; - down – to display the desktop. Mac OS (gestures using 3-4 fingers): - left / right – to switch between desktops;...
- Page 14 left side or only the right side Space Click Mouse click simulation using the Mode (switched space bar will be performed as off by default) follows: - left click: Hold one finger on a touch panel and press the space bar;...
- Page 15 type-C cable. Two hours after entering sleep mode, keyboard turns off. If you connect the USB Type-C cable to the keyboard during sleep mode, it will turn on in the USB interface. If the keyboard is connected to a power source, it will turn on in the last interface used.
- Page 16 Attention The use of a keyboard may be related to a potential cause of repetitive stress injuries occurrence of which depends on many factors such as a general medical and physical condition, body positioning during work, etc. Some studies indicate that the amount of time a person uses a keyboard may also be a factor causing discomfort in hands, arms, neck, etc.
- Page 17 connect via indicator lights up, but the keyboard Bluetooth does not connect to the chosen channel device - the keyboard is connected via this channel to another device, you must reconnect the keyboard to the device via the selected Bluetooth channel.
- Page 18 repair it via a mobile app. The LED - The keyboard has been updated indicator blinks incorrectly – update again via the red after the application. If LED-indicator continues keyboard is ON to flash red after re-updating, contact the service center. Keyboard setting and software update The device can be set up and updated via a free mobile application, available for download from Apple Store and...
- Page 19 1. The keyboard is not intended for use in residential, business, or industrial zones with a hazard risk. 2. It is recommended to operate and store the device at a temperature from -20°C up to +60°C and at a relative humidity of up to 65%.
