Prestigio PBKB01 Manual

Package Contents
1. Bluetooth Keyboard
2. Quick Guide
Product Overview
No. 1 to 15 are special hot keys, please refer to "Hot key function" introduction;
16. LED indicator/ Connect button; 17. Micro USB 5V DC in; 18. ON/OFF Switch
LED indicator
There is an LED light on top of the Bluetooth keyboard.
1. The LED indicates the status of the keyboard:
‧Power off –LED Off
‧Bluetooth pairing mode - Flashing
blue
2. When Bluetooth keyboard connect with micro USB charging cable the LED will
become red, and will be off after battery fully charged.
Quick Start
1. Make sure the Bluetooth keyboard has electricity.
2. Turn the power switch to 'ON' and you will see the blue LED lights on 3 seconds
then off.
3. After turning the keyboard on, press the "CONNECT" button and the blue LED
indicator should flash every 1 second, it is in "pairing mode."
4. The keyboard is now ready to connect to your Bluetooth enabled device.
Please refer to your Bluetooth enabled device's instruction manual for pairing
instructions if you are unsure how to do this.
Bluetooth keyboard
3. Micro USB charging cable
‧Power on - Blue lights on 3 seconds
then off
EN - 1
