Technics RP-9024 Service Manual

ORDER NO. ARD 81100093C2-1 1
dbx Noise Reduction Unit
; RP-9024
( Silver 2)
Black Face
dbx Noise Reduction Unit with
3-Head Deck Compatibility
This is the Service Manual for the
following areas.
(D) .-+---++ For all European areas.
Specifications
Dynamic range: More than 110dB (at 1kHz, CrOz type tape)
Linearity : 10dB or more improved (at 1 kHz, tape)
Noise level improvement: More than 30 B (tape)
Input level: 300 mV (standard), 6 V (max.)
Input impedance: 36kQ
Output level: Max. 5.5V, load impedance 22 kQ
Output impedance: 2.5kQ
Frequency response: 40—20,000Hz +1dB
Compression/expansion ratio: 2:1, 1: 2 (constant linear decibel)
Power requirement: 110/125/220/240V, 50-60 Hz
Power consumption: 8W
Dimensions: 43.0cm(W) X 5.3em(H) xX 28.0cm(D)
Weight: 3.0kg
Specifications are subject to change without notice.
* The term dbx is registered trademark of dbx Inc.
