dji OM User Manual

dji OM User Manual

Multifunctional module
Hide thumbs Also See for OM:

Advertisement

Quick Links

Download this manual
User Manual
v1.0 2025.02

Advertisement

loading
Need help?

Need help?

Do you have a question about the OM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji OM

Summary of Contents for dji OM

  • Page 1 User Manual v1.0 2025.02...
  • Page 2 This document is copyrighted by DJI with all rights reserved. Unless otherwise authorized by DJI, you are not eligible to use or allow others to use the document or any part of the document by reproducing, transferring or selling the document. Only refer to this document and the content thereof as instructions to operate DJI products.

  • Page 3: Using This Manual

    DJI OM Multifunctional Module User Manual Using this Manual Legend Important Reference Hints and Tips Read Before Use ™ provides you with tutorial videos and the following documents: 1. Safety Guidelines 2. Quick Start Guide 3. User Manual It is recommended to watch all the tutorial videos and read the Safety Guidelines before using for the first time.

  • Page 4: Table Of Contents

    DJI OM Multifunctional Module User Manual Contents Using this Manual Legend Read Before Use Video Tutorials Product Profile Using the Product Installing and Removing Tracking and Shooting Tracking Shooting Fill Light Connecting to Wireless Microphones Phone Charging Firmware Update Indicators Specifications ©...

  • Page 5: Product Profile

    DJI OM Multifunctional Module User Manual Product Profile 1. Tracking Camera 6. Audio Data/Phone Charging Port (USB- 2. Camera Status Indicator 7. Release Button 3. Fill Light 8. Wireless Microphone Status Indicator 4. Brightness Control Button 5. Color Temperature Control/Bluetooth Pairing Button ©...

  • Page 6: Using The Product

    DJI OM Multifunctional Module User Manual Using the Product • DJI OM Multifunctional Module is hereinafter referred to as “Multifunctional Module”. 2.1 Installing and Removing Example ① Example ② Capture photos or videos of yourself Capture photos or videos of others •...

  • Page 7: Tracking And Shooting

    DJI Mimo. • Multifunctional Module supports tracking people only. • The tracking and shooting features of Multifunctional Module are disabled in DJI Mimo. • Position the tracking camera of Multifunctional Module and the phone camera towards the subject.
  • Page 8 DJI OM Multifunctional Module User Manual • To achieve optimal gesture recognition, keep the subject 0.5m to 3m away from the tracking camera. • During tracking, keep the subject 0.5m to 8m away from the tracking camera. © 2025 DJI All Rights Reserved.

  • Page 9: Tracking

    DJI OM Multifunctional Module User Manual Tracking 1. Enable Bluetooth on the phone and connect to the gimbal. 2. Enable tracking: Show the gesture to the camera or press the trigger. The indicator turns solid green. 3. Adjust the composition as needed during tracking.
  • Page 10 DJI OM Multifunctional Module User Manual • Method 1: Use the joystick. • Method 2: Use hand gestures. Show the gesture to the camera. The indicator turns solid yellow and tracking is automatically paused. The subject can move to the desired position in the frame.

  • Page 11: Shooting

    DJI OM Multifunctional Module User Manual Shooting Whether tracking is enabled or not, you can use the gesture to start a countdown for taking a photo or starting/stopping recording. The indicator pulses yellow during the countdown. 2.3 Fill Light Make sure that Multifunctional Module is properly installed.

  • Page 12: Connecting To Wireless Microphones

    DJI OM Multifunctional Module User Manual ×1 2.4 Connecting to Wireless Microphones Multifunctional Module can connect to two wireless microphone transmitters (hereinafter referred to as “transmitters”). Supported transmitters: • DJI Mic Mini © 2025 DJI All Rights Reserved.
  • Page 13 DJI OM Multifunctional Module User Manual 1. Connect Multifunctional Module to the 2. Enable Bluetooth pairing for Multifunc- phone. tional Module. 15 cm 3. Power on the transmitter. 4. Enable Bluetooth pairing for the trans- mitter. 5. Once paired, both indicators of Multifunctional Module and the transmitter turn solid green.

  • Page 14: Phone Charging

    ×2 2.6 Firmware Update Make sure that Multifunctional Module is properly installed. When using DJI Mimo to update the gimbal firmware, the module firmware is updated together. Please wait for the upgrade to complete. © 2025 DJI All Rights Reserved.

  • Page 15: Indicators

    DJI OM Multifunctional Module User Manual Indicators 1. Camera Status Indicator Solid red Tracking disabled or subject lost Solid green Subject being tracked Blinks green Subject lost temporarily Solid yellow Composition being adjusted Blinks yellow Countdown for photo shooting or video recording 2.

  • Page 16: Specifications

    DJI OM Multifunctional Module User Manual Specifications Visit https://www.dji.com/osmo-mobile-7-series/specs for more information. © 2025 DJI All Rights Reserved.
  • Page 17 This content is subject to change without notice. Download the latest version from https://www.dji.com/osmo-mobile-7-series/downloads If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. DJI and OSMO are trademarks of DJI. Copyright © 2025 DJI All Rights Reserved.
