SERVICE MANUAL

VIDEO CASSETTE RECORDER

HR-P57AG, HR-P58AG,

HR-V200AG, HR-V207AG, HR-V400AG

For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY).

SPECIFICATIONS

GENERAL

Power requirement

Rating

Operating

Power consumption

Temperature

Operating

Storage

Operating position

Dimensions (WxHxD)

Weight

Format

Maximum recording time

(SP)

(LP)

(EP)

VIDEO/AUDIO

Signal system

Recording system

Signal-to-noise ratio

Horizontal resolution

Frequency range

Input/Output

(The specifications shown pertain specifically to the model HR-V200AA, HR-V200AG, HR-V201AS, HR-V207AG, HR-V400AG, HR-V401AS.)

: AC110 V–240 V

, 50 Hz/60Hz

: AC90 V–260 V

, 50 Hz/60Hz

: 14 W

: 5 °C to 40 °C

: –20 °C to 60 °C

: Horizontal only

: 360 mm x 94 mm x 265 mm

: 2.7 kg

: VHS standard

: 240 min. with E-240 video cassette

(PAL/MESECAM)

: 160 min. with T-160 video cassette

(NTSC)

: 480 min. with E-240 video cassette

(PAL/MESECAM)

: 480 min. with T-160 video cassette

(NTSC)

: PAL-type colour signal and CCIR

monochrome signal, 625lines

50 fields

: NTSC colour and EIA monochrome

signals, 525 lines/60 fields

: HR-V400AG/V401AS

DA-4 (Double Azimuth) head helical

scan system

: HR-V207AG/V200AG/V201AS/V200AA

Rotary 2 head helical scan system

: 45dB

: 250 lines (PAL/MESECAM)

: 220lines (NTSC)

: 70Hz to 10,000 Hz

: HR-V400AG/V401AS

RCA connectors (IN x2, OUTx1)

: HR-V207AG/V200AG/V201AS/V200AA

RCA connectors (IN x1, OUTx1)

HR-P57AG, HR-P58AG, HR-V200AG, HR-V207AG, HR-V400AG V16A1, V16A2, V16C1, V16P1, V16P11

TUNER/TIMER

TV channel storage

: 99 positions (+AUX position)

capacity

Tuning system

:Frequency synthesized tuner

Channel coverage

VHF

: (Low) 42 MHz – 175 MHz

(High)175 MHz – 470 MHz

UHF

: 470 MHz – 870 MHz

Aerial output

: UHF channels (Adjustable E28 – E60)

Memory backup time

: Approx. 10 min.

ACCESSORIES

Provided accessories

: RF cable,

Lithium battery CR2032,

Infrared remote control unit,

Conversion plug*

*Not provided in certain areas.

Specifications shown are for SP mode unless specified otherwise.

E. & O.E. Design and specifications subject to change without

notice.

No.82993

2003/10
